Cordless
Power Tools
makita.ca
25
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DUH523Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Blade Cover (453723-3), Shear Blade Complete Set (195846-8)
Designed for Maximum Versatility and Ease of Operation
• Battery Protection System provides Over-Discharge, Temperature and Current Protection
for enhanced performance, battery cycle life and overall battery life
• Battery Capacity Warning Light indicates approximate remaining battery power
• Anti-Vibration Structure features five cushions linking handle and motor sections for significantly
reduced vibration transmission to operator
• Two Grip Switch System prevents accidental engagement of trigger for maximum operator safety
• Dual Blade action cuts quickly with shearing effect
• Chip Receiver prevents material from falling onto blade
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Tool-less Blade Changing System enables simple and easy blade changes
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
20-1/2˝ Cordless Hedge Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Strokes Per Minute (min-1)
1,350 SPM
Cutting Width
20-1/2˝ (520 mm)
Maximum Cutting Thickness
15/32˝ (12 mm)
Overall Length
38˝ (963 mm)
Net Weight
6.0 lbs (2.7 kg)
Dual Blade Action
DUM168Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Base Frame (326146-7), Change Lever (451813-6), Blade Cover (452055-5)
Compact Design For Added Versatility
• Battery Protection System provides Over-Discharge, Temperature and Current Protection
for enhanced performance, battery cycle life and overall battery life
• Battery Capacity Warning Light indicates low battery capacity
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Wire Toboggan Style Base Frame enables quick and easy depth adjustment
• Tool-less Blade Changing System enables simple and easy blade changes
• Left and Right Hand Lock-Off Button for operator safety
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
6-5/16˝ Cordless Grass Shear
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed
1,250 SPM
Cutting Width
6-5/16˝ (160 mm)
Depth Adjustment
3/8˝ / 13/16˝ / 1-3/16˝
(10 mm / 20 mm / 30 mm)
Overall Length
13-7/8˝ (353 mm)
Net Weight
2.9 lbs. (1.1 kg)
Dual Blade Action
DUR181Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Nylon Cord (196148-5), Bump & Feed Spool Set (196146-9), BandAssembly
(125516-5), Safety Cover (453353-0), Front Grip (453340-9), Safety Goggles (195246-2)
Well Balanced Design With Fully Adjustable Features To Suit Any Operator
• Adjustable Trimmer Head features 5 angled cutting positions for maximum versatility and ease
of operation when trimming around obstacles
• Trimmer Head Rotates 180° to enable easy edge trimming
• Telescopic Shaft adjusts quickly and easily to suit any operator
• Lock-Off Safety Lever prevents accidental start up
• Battery Capacity Warning Light indicates low battery capacity
10-1/4˝ Cordless Line Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed
7,800 RPM
Cutting Width
10-1/4˝ (260 mm)
Overall Length
56-1/2˝ (1,433 mm)
Net Weight
4.4 lbs (2.0 kg)
Replacement Nylon Cutting Line
196148-5 (49') or 195861-2 (98')
DUC122Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
4-1/2" Chain, 4-1/2" Guide Bar (158476-6), Chain Cover (416311-7),
Chain File (744003-1), Oil Supply
Ideal For Cutting Small Diameter
Firewood Or Brush, Pruning
Applications And More
• Top handle design enables greater force to be
applied during cutting operations and creates
more compact design
• Hand guard protects operators hand
during operation
• Lock-off button prevents accidental startup
• Electric brake stops chain within
0.5 seconds for added safety
4-1/2˝ Cordless Chainsaw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Guide Bar Length
4-1/2˝ (115 mm)
Chain Pitch / Gauge
1/4˝ / .050”
Chain Speed
980 FPM (300 m/min)
Overall Length
16-5/8˝ (422 mm)
Net Weight
4.2 lbs (1.9 kg)
Electric Brake
Ideally Suited For Concrete Footings And Wall Construction
• Multi-Directional Trigger enables operation from two directions for increased maneuverability
• Protective Battery and Switch Covers prevent damage due to contamination
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Vibrations Per Minute
12,500 VPM
Vibrator Diameter
1˝ (2.5 cm)
Shaft Length 96˝ (240 cm)
Overall Length
105-1/2˝ (268 cm)
Net Weight
11.5 lbs (5.2 kg)
DVR850RFE, DVR850F, DVR850Z, DVR450RFE, DVR450F, DVR450Z, DVR350RFE, DVR350F, DVR350Z
Cordless Concrete Vibrators
DVR850RFE
STANDARD EQUIPMENT INCLUDES:
DVR850RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RA),
Carrying Case for Battery/ Charger (824768-2)
DVR850F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3)
DVR850Z:
Tool Only. Batteries and Charger Sold Separately.
DVR850F
DVR850Z
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Vibrations Per Minute
13,000 VPM
Vibrator Diameter
1˝ (2.5 cm)
Shaft Length 48˝ (120 cm)
Overall Length
58-1/2˝ (148 cm)
Net Weight
7.7 lbs. (3.5 kg)
DVR450RFE
STANDARD EQUIPMENT INCLUDES:
DVR450RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC),
Carrying Case for Battery / Charger (824768-2)
DVR450F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3)
DVR450Z:
Tool Only. Batteries and Charger Sold Separately.
DVR450F
DVR450Z
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Vibrations Per Minute
13,000 VPM
Vibrator Diameter
1˝ (2.5 cm)
Shaft Length 31-3/16˝ (80 cm)
Overall Length
42-3/4˝ (108 cm)
Net Weight
6.6 lbs (3.0 kg)
DVR350RFE
STANDARD EQUIPMENT INCLUDES:
DVR350RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RA),
Carrying Case for Battery / Charger (824768-2)
DVR350F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3)
DVR350Z:
Tool Only. Batteries and Charger Sold Separately.
DVR350F
DVR350Z
