6281DWPE
STANDARD EQUIPMENT INCLUDES:
Two 14.4V (1.3Ah) Ni-Cad Batteries
PA14 (193987-4), Charger (DC1414), 2 Ea. Battery Covers (414938-7),
3/8˝ Keyless Drill Chuck (766002-3), Phillips Bit 2-65 (784636-0), Plastic Carrying Case (824852-3)
Versatile, General Purpose Drive Drill
• 16 Clutch Settings deliver up to 260 in. lbs. of torque
• All Metal Gears for more efficient power transmission
• Compact Design with a reduced body length of only 7-9/16˝
• Single Sleeve Keyless Drill Chuck for easy bit installation and removal
Variable 2-Speed, Reversible
3/8˝ Cordless Driver Drill
SPECIFICATIONS
Battery
14.4V (1.3 Ah) Ni-Cad
Capacities:
Steel
3/8˝ (10 mm)
Wood
1˝ (25 mm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,300 RPM
Maximum Torque 260 in. lbs. (30 Nm)
Overall Length
7-9/16˝ (192 mm)
Net Weight
3.3 lbs. (1.5 kg)
6271DWPE
STANDARD EQUIPMENT INCLUDES:
Two 12V (1.3Ah) Ni-Cad Batteries
PA12 (638347-8-2, 2 / Pk), Charger (DC1414), 2 Ea. Battery Covers (414938-7),
3/8˝ Keyless Drill Chuck (766002-3), Phillips Bit 2-65 (784636-0), Plastic Carrying Case (824852-3)
Versatile, General Purpose Driver Drill
• 16 Clutch Settings deliver up to 250 in. lbs. of torque
• All Metal Gears for more efficient power transmission
• Compact Design with a reduced body length of only 7-9/16˝
• Single Sleeve Keyless Drill Chuck for easy bit installation and removal
Variable 2-Speed, Reversible
3/8˝ Cordless Driver Drill
SPECIFICATIONS
Battery
12V (1.3 Ah) Ni-Cad
Capacities:
Steel
3/8˝ (10 mm)
Wood
1˝ (25 mm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,300 RPM
Maximum Torque 250 in. lbs. (28 Nm)
Overall Length
7-9/16˝ (192 mm)
Net Weight
3.3 lbs. (1.5 kg)
6261DWPE
STANDARD EQUIPMENT INCLUDES:
Two 9.6V (1.3Ah) Ni-Cad Batteries
PA09 (638344-4-2), Charger (DC1414), 2 Ea. Battery Covers (414938-7),
3/8˝ Keyless Drill Chuck (766002-3), Phillips Bit 2- 65 (784636-0), Plastic Carrying Case (824852-3)
Versatile, General Purpose Driver Drill
• 16 Clutch Settings deliver up to 200 in. lbs. of torque
• All Metal Gears for more efficient power transmission
• Compact Design with a reduced body length of only 7-9/16˝
• Single Sleeve Keyless Drill Chuck for easy bit installation and removal
Variable 2-Speed, Reversible
3/8˝ Cordless Driver Drill
SPECIFICATIONS
Battery
9.6V (1.3 Ah) Ni-Cad
Capacities:
Steel
3/8˝ (10 mm)
Wood
13/16˝ (21 mm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,300 RPM
Maximum Torque 200 in. lbs. (23 Nm)
Overall Length
7-9/16˝ (192 mm)
Net Weight
3.3 lbs. (1.5 kg)
6723DW
STANDARD EQUIPMENT INCLUDES:
Charger (TP00000188), 80 Pc. Bit Set, Plastic Carrying Case
Includes 80 Piece Bit Set
• LED Job Light with Indepedent On / Off Switch
• On / Off switch with Forward and Reverse Modes
• Adjustable Hinged Handle
• Soft Grip for operator comfort
• Built in Battery
Built-in LED Light
4.8V Cordless Screwdriver
SPECIFICATIONS
Battery
4.8V (0.6 Ah) Ni-Cad
No Load Speed
220 RPM
Maximum Torque
40 in.lbs. (4.5 Nm)
Overall Length (Straight) 11-1/2˝ (292 mm)
Net Weight
0.9 lbs. (0.4 kg)
Kit shown includes one
4.8V Cordless Screwdriver
8391DWPE
STANDARD EQUIPMENT INCLUDES:
Two 18V (1.3Ah) Ni-Cad Batteries
PA18 (194227-3, 2 / Pk), Charger (DC1804), Battery Cover (414938-7),
1/2˝ Keyless Drill Chuck (763193-1), Double Ended Bit (784636-0), Plastic Carrying Case (824853-1)
Single Sleeve 1/2˝ Keyless Chuck With Shaft Lock
• 16 Clutch Settings deliver up to 340 in. lbs. of torque
• All Metal Gears for more efficient power transmission
• Compact Design with a reduced body length of only 9-1/2˝
• Single Sleeve Keyless Drill Chuck for easy bit installation and removal
Variable 2-Speed, Reversible
1/2˝ Cordless Hammer Driver Drill
SPECIFICATIONS
Battery
18V (1.3 Ah) Ni-Cad
Capacities:
Concrete
1/2˝ (13 mm)
Steel
1/2˝ (13 mm)
Wood
1-7/16˝ (36 mm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,300 RPM
Blows Per Minute:
Low
0 - 6,000 BPM
High
0 - 19,500 BPM
Maximum Torque 340 in. lbs. (38 Nm)
Overall Length
9-1/2˝ (241 mm)
Net Weight
4.6 lbs. (2.1 kg)
6391DWPE
STANDARD EQUIPMENT INCLUDES:
Two 18V (1.3Ah) Ni-Cad Batteries
PA18 (194227-3, 2 / Pk), Charger (DC1804), 2 Ea. Battery Covers (414938-7),
1/2" Keyless Drill Chuck(763193-1), Phillips Bit 2-65 (784636-0), Plastic Carrying Case (824853-1)
Versatile, General Purpose Driver Drill
• 16 Clutch Settings deliver up to 340 in. lbs. of torque
• All Metal Gears for more efficient power transmission
• Compact design with a reduced body length of only 8-3/8˝
• Single Sleeve Keyless Drill Chuck for easy bit installation and removal
Variable 2-Speed, Reversible
1/2˝ Cordless Driver Drill
SPECIFICATIONS
Battery
18V (1.3 Ah) Ni-Cad
Capacities:
Steel
1/2˝ (13 mm)
Wood
1-7/16˝ (36 mm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,300 RPM
Maximum Torque 340 in. lbs. (38 Nm)
Overall Length
8-3/4˝ (223 mm)
Net Weight
4.4 lbs. (2.0 kg)
