LCT209
INCLUDES:
• 1/4˝ Cordless Impact Driver (DT01Z)
• 3/8˝ Cordless Driver Drill (FD02Z)
•
Two 12V MAX (1.3 Ah) Li-Ion Batteries
BL1014 (195332-9)
• Charger (DC10WB)
• Aluminum Carrying Case (823308-3)
2 Piece Cordless Combo Kit
LCT207
INCLUDES:
• 1/4˝ Cordless Impact Driver (DT01Z)
• 1/4˝ Cordless Driver Drill (FD01Z)
•
Two 12V MAX (1.3 Ah) Li-Ion Batteries
BL1014 (195332-9)
• Charger (DC10WB)
• Aluminum Carrying Case (823304-1)
2 Piece Cordless Combo Kit
FD02
STANDARD EQUIPMENT INCLUDES:
FD02:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Charger (DC10WB), Battery Plastic Case (824781-0),
PhillipsBit2-50(784244-7),Holster(168467-9),3/8˝KeylessDrillChuck(766007-3),PlasticCarryingCase(824842-6)orToolBag(831325-9)
FD02Z:
ToolOnly.BatteriesandChargerSoldSeparately.
PhillipsBit2-50(784244-7),3/8"KeylessDrillChuck(766007-3)
Lightweight & Compact With High Operational Efficiency
• 18 Clutch Settings deliver up to 200 in. lbs. of torque
• Two Speed Gearing for more efficiency
• Lightweight and Compact Design
• LED Job Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Variable 2-Speed, Reversible
3/8˝ Cordless Driver Drill
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Capacities:
Steel
3/8˝ (10 mm)
Wood
13/16˝ (21 mm)
Maximum Torque 200 in. lbs. (22 Nm)
No Load Speed:
Low
0 - 350 RPM
High
0 - 1,300 RPM
Overall Length
7-7/16˝ (189 mm)
Net Weight
2.2 lbs (1.0 kg)
FD02Z
FD01
STANDARD EQUIPMENT INCLUDES:
FD01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Charger (DC10WB), Battery Plastic Case (824781-0),
Phillips Bit 2-50 (784244-7), Holster (168467-9), Plastic Carrying Case (824842-6)
FD01Z:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7)
Lightweight & Compact With High Operational Efficiency
• 18 Clutch Settings deliver up to 200 in. lbs. of torque
• Two Speed Gearing for more efficiency
• Lightweight and Compact Design
• LED Job Light with Afterglow feature
Variable 2-Speed, Reversible
1/4˝ Hex Cordless Driver Drill
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Hex Shank
1/4˝ Hex
Capacities:
Steel
3/8˝ (10 mm)
Wood
13/16˝ (21 mm)
No Load Speed:
Low
0 - 350 RPM
High
0 - 1,300 RPM
Maximum Torque 200 in. lbs. (22 Nm)
Overall Length
6-3/16˝ (157 mm)
Net Weight
2.0 lbs (0.9 kg)
FD01Z
CC01
STANDARD EQUIPMENT INCLUDES:
CC01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9),Charger(DC10WB),3-3/8˝DiamondBlade(A-95722),
HexWrench4(783202-0)
CC01Z:
ToolOnly. BatteriesandChargerSoldSeparately.
3-3/8˝DiamondBlade(A-95722),HexWrench4(783202-0)
Specifically Designed For Cutting Glass and Ceramic Tile
• Battery Protection System shuts tool off when overloaded or when battery capacity is low
• Left and Right Hand Lock-Off Lever for maximum operator safety
• Water Supply Tank (500 mL) features large cap for quick and easy refilling
• Nickel-Plated Base Plate prevents staining and corrosion
• Bevel Capacity of 45°
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
3-3/8˝ Cordless Glass & Tile Circular Saw
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Blade Diameter
3-3/8˝ (85 mm)
Arbor
9/16˝ (15 mm)
Maximum Cutting Depths:
0°
1˝ (25.5 mm)
45°
5/8˝ (16.5 mm)
No Load Speed
1,400 RPM
Overall Length
11-3/4˝ (300 mm)
Net Weight
3.7 lbs. (1.7 kg)
CC01Z
SH01
STANDARD EQUIPMENT INCLUDES:
SH01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Charger (DC10WB), 3-3/8˝ Circular Saw Blade 20CT(A-95021),
Hex Wrench (783202-0), Plastic Carrying Case (824961-8)
SH01Z:
Tool Only. Batteries and Charger Sold Separately.
3-3/8˝ Circular Saw Blade 20CT(A-95021), Hex Wrench (783202-0)
Compact And Versatile Design For Flooring, Panelling, Trim And More!
• Battery Protection System shuts tool off when overloaded or when battery capacity is low
• Left and Right Side Lock-Out Button for operator safety
• Blower feature keeps cutting line free of sawdust
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Dust Blower
3-3/8˝ Cordless Circular Saw
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Blade Diameter
3-3/8˝ (85 mm)
Arbor
9/16˝ (15 mm)
Maximum Cutting Capacities:
0°
1˝ (25.5 mm)
45°
5/8˝ (16.5 mm)
No Load Speed
1,400 RPM
Overall Length
11-3/4˝ (300 mm)
Net Weight
3.3 lbs. (1.5 kg)
SH01Z
