LXRM01
• Pivoting Head features 6 Positive Stops at
90°, 60°, 30°, 0°, -30°, -60°
• Features 3 LED Lights for high illumination
• 3 Stage Battery Fuel Gauge indicates remaining
battery power
• LCD Digital Display indicates AM / FM Band,
Presets, Volume Level, Radio Station Frequency
and Battery Level
• BATTERY NOT INCLUDED
18V / 14.4V Li-Ion LED Flashlight Radio
SPECIFICATIONS
Battery Capacities:
18V Li-ion
14.4 V Li-ion
Continuous Run Time:
Radio Only
Approx. 25 Hours
(with Battery BL1430 / BL1830)
Light Only
Approx. 8.5 Hours
(with Battery BL1430 / BL1830)
Radio and Light
Approx. 6 Hours
(with Battery BL1430 / BL1830)
Overall Length
10-3/8˝ (263 mm)
Net Weight (no battery)
1.3 lbs. (0.6 kg)
BML184
• New fluorescent bulb fo
extra brightness
• Retractable Sky Hook for
added convenience
• Flashlight feature located
above fluorescent light
• BATTERY NOT INCLUDED
18V / 14.4V Li-Ion Fluorescent Flashlight
SPECIFICATIONS
Battery Capacities:
18V Li-ion
14.4V Li-ion
Continuous Use:
Fluorescent
up to 15 hours
Flashlight
up to 3.3 hours
Overall Length
17-3/4˝ ( 450 mm)
Net Weight (no battery) 0.88 lbs. (0.40 kg)
BML185
• 4-Position Pivoting Head for greater versatility
• High illumination emits high power at 4,500 Lux
• New Xenon bulb for extra brightness
• BATTERY NOT INCLUDED
18V Li-Ion Flashlight
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Continuous Use
up to 4 hours
Overall Length
11-1/8˝ (284 mm)
Net Weight (no battery)
0.9 lbs. (0.4 kg)
LM02
• Super Bright LED illuminates work area
• Belt Clip for operator convenience
• Light Weight and Portable Size
• Flexible Legs wrap around cylindrical surfaces or bend to form convenient stand for
illuminating hard to reach locations
• BATTERY NOT INCLUDED
12V Li-Ion LED Flashlight
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Continuous Use
Up to 9 hours
Overall Dimensions (L x W x H) (Light Only)
4-11/16˝ x 2-1/16˝ x 2-3/16˝
(119 mm x 52 mm x 55 mm)
Net Weight (no battery) 0.4 lbs. (0.2 Kg)
LXLM03
• Rotatable (Left or Right) and Foldable Head Design enables flashlight to be positioned in numerous
configurations for maximum versatility in a variety of applications
• Foldable Head features 7 Positive
Stops at 0
°
, 30
°
, 60
°
, 90
°
,
120
°
, 150
°
, 180
°
• Features 12 LED's for
maximum illumination
• 2 Stage Push Button Control
for Half Brightness (6 LED's)
or Full Brightness (12 LED's)
• Over-Discharge Circuit
Protection prevents
damage to battery
caused by
over-discharge of cells
• Retractable Sky Hook
for added convenience
• BATTERY NOT INCLUDED
18V / 14.4V Li-Ion LED Flashlight
SPECIFICATIONS
Battery Capacities:
18V Li-ion
14.4V Li-ion
Continuous Use:
Full Brightness
Approx. 9 Hours
(with Battery BL1830)
Half Brightness Approx. 22 Hours
(with Battery BL1830)
Overall Dimensions (L x W x H) (with BL1830)
5˝ x 3-1/8˝ x 4-1/2˝
(380 x 79 x 115 mm)
Net Weight (no battery)
0.7 lbs. (0.3 kg)
LXLM04
• Compact Aluminum Head
for increased durability
and versatility in
small areas
• Pivoting Head features
12 Positive Stops at 110
°
,
90
°
, 75
°
, 60
°
, 45
°
, 30
°
, 15
°
,
0
°
, -15
°
, -30
°
, -45
°
, -60
°
• High Luminance Single
LED Light
• Multi-Faceted Reflector
provides clear round spot
light with uniform brightness
• Retractable Sky Hook for
added convenience
• Ergonomic Soft Rubber
Grip design for
comfortable operation
• BATTERY NOT INCLUDED
18V / 14.4V Li-Ion LED Flashlight
SPECIFICATIONS
Battery Capacities:
18V Li-Ion
14.4V Li-Ion
Continuous Use
up to 12 Hours
(with Battery BL1830)
Overall Dimensions (L x W x H) (with BL1830)
10-3/4˝ x 3-1/8˝ x 4-3/4˝
(272 mm x 79 mm x 121 mm)
Net Weight (no battery)
0.9 lbs. (0.4 kg)
LXLM01
18V Li-Ion LED Flashlight
• Wide and Bright Illumination on the Jobsite
• 6 LED Lights provide maximum illumination
• Convenient Hook & Loop Carrying Strap
• BATTERY NOT INCLUDED
18V Li-Ion LED Flashlight
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Continuous Use
Approx. 50 Hours (with Battery BL1830)
Approx. 15 Hours (with Battery BL1815)
Overall Dimensions
(L x W x H) (with BL1830)
5-7/8˝ x 3-3/16˝ x 3-1/16˝
(151 mm x 81 mm x 78 mm)
Net Weight (no battery)
0.4 lbs. (0.2 kg)
ML102
• Can be operated in flashlight
(spot or area illumination)
or lantern mode
(360
°
illumination)
• Top and bottom
hanging hook allows
lantern to be hung in
multiple positions
• Over-discharge circuit
protection prevents
damage to battery caused
by over-discharge of cells
• IP54 rated for protection
against water, dust, dirt
and debris when used in
outdoor applications
or harsh environments
• BATTERY NOT INCLUDED
12V / 7.2V Li-Ion LED Lantern
SPECIFICATIONS
Battery Capacities: 12V MAX (1.3 Ah) Li-Ion
7.2V (1.0 Ah) Li-Ion
Continuous Use
up to 5 hours (with battery BL7010)
up to 9 hours (with battery BL1014)
Overall Dimensions (D x H)
2-9/16˝ x 7-1/8˝
Net Weight (no battery) 0.46 lbs (0.2 kg)
