STANDARD EQUIPMENT INCLUDES:
1/4˝ Collet Cone (193214-9), 1/2˝ Collet Cone (193215-7), 2 Ea. Wrench 27 (781031-5), Wrench 8 (781213-9)
• Electronic Speed Control maintains constant speed under heavy load
• Variable Speed Dial adjusts motor speed based on materials or application
• Soft Start feature gradually increases speed to eliminate start up shock
• 3 Stage Depth Adjustments ideal for use when performing deep or repetitive cutting operations
• Flat Top Design for increased stability when changing bits
• Industrial Cam-Lock enables fast and easy depth adjustment and removal of motor
• Sub-Base accepts industry standard template guides
Electronic Speed Control, Variable Speed,
Soft Start
2-1/4 H.P. Plunge Router
SPECIFICATIONS
Collet Capacities
1/4˝ & 1/2˝
(6.4 mm & 12.7 mm)
Plunge Capacity
2-19/32˝ (66 mm)
No Load Speed
8,000 - 24,000 RPM
AMPS (120V)
11.0 A
Overall Height
11-1/2˝ (291mm)
Net Weight
9.3 lbs. (4.2 kg)
RP1101
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
1/4˝ Collet Cone (763637-1), Wrench 13 (781006-4), Wrench 22 (781011-1), Straight Guide (164834-6), Plastic Carrying Case (824880-8)
Compact And Lightweight Plunge Router With Enhanced Durability
• Large Ball Bearing on fan end and Dust Proof Bearing on commutator end of armature for
enhanced durability of tool
• 3 Stage Depth Adjustments ideal for use when performing deep or repetitive cutting operations
• Trigger Switch located on handle for operator convenience
• Convenienty located Plunge Locking Lever for easy engagement during operation
• Four Raised Ribs on top of Motor Housing provide a stable platform during bit changes
• Can be used with 55˝ (194368-5) or 118˝ (194367-7) Guide Rails and Router Guide Rail Adapter (194579-2)
for precision routing applications
1-1/4 H.P. Plunge Router
SPECIFICATIONS
Collet Capacities:
1/4˝, 3/8˝
(6.4 mm, 9.5 mm)
Plunge Capacity
1-3/8˝ (35 mm)
No Load Speed
27,000 RPM
AMPS (120V)
8.0 A
Overall Height
8-17/32˝ (217 mm)
Net weight
6.0 lbs. (2.7 kg)
RP0900K
STANDARD EQUIPMENT INCLUDES:
1/4˝ Collet Sleeve (763803-0), Wrench 23 (781012-9), Wrench 21 (781029-2)
(Shown with Optional Guide Plate)
• Large Calibrated Depth Control Ring for easy depth adjustment
• D-Handle Design with Locking Trigger Switch for maximum operator control and comfort during
continuous use applications
1-3/8 H.P. Router
SPECIFICATIONS
Collet Capacities:
1/4˝, 3/8˝, 1/2˝
(6.4 mm, 9.5 mm, 12.7 mm)
Base Plate Diameter
6-1/4˝ (160 mm)
No Load Speed
23,000 RPM
AMP (120V)
8.5 A
Overall Height
7-1/2˝ (190 mm)
Net Weight
7.9 lbs. (3.6 kg)
3601B
STANDARD EQUIPMENT INCLUDES:
1/4˝ Collet Cone (763608-8), Wrench 17 (781008-0)
Affordable Lightweight Router
• Large Calibrated Depth Control Ring for easy depth adjustment
• Shaft Lock enables quick changing of bits with just one wrench
• Ergonomic Handles for operator comfort and control
1 H.P. Router
SPECIFICATIONS
Collet Capacity
1/4˝ (6.4 mm)
No Load Speed
30,000 RPM
AMPS (120V)
7.0 A
Overall Height
7-1/8˝ (181 mm)
Net Weight
5.1 lbs. (2.3 kg)
3606
Compact and Versatile Trimmer with 4 Base
Options for Maximum Versatility
• Soft Start Motor with Constant Speed Control eliminates start up shock and maintains cutting speed
under heavy loads
• Variable Speed Dial allows operator to adjust speed based on materials or application
• Trimmer Base Assembly provides smooth, fast cutting and easy handling
• Plunge Base Assembly with precision cutting depth adjustment for accurate plunge cutting applications
• Tilt Base Assembly enables quick and accurate angled cuts
• Offset Base Assembly allows operator to make close to wall cuts of just 3/4
˝
SPECIFICATIONS
Collet Capacities:
1/4˝, 3/8˝
(6.4 mm , 9.4 mm)
No Load Speed
10,000 - 30,000 RPM
AMPS (120V)
6.5 A
Overall Height
7-7/8˝ (200 mm)
Net Weight
3.9 lbs. (1.8 kg)
RT0700CX3
1/4˝ - 3/8˝ Trimmer
STANDARD EQUIPMENT INCLUDES:
1/4˝ColletCone(763637-1),3/8˝ColletCone(763619-3),TrimmerGuide(122703-7),Straight
Guide(122965-7),TemplateGuide10(343577-5),TemplateGuide16(193043-0), Wrench13
(781039-9),Wrench22(781011-1),PlungeBaseSet(196094-2),TiltBaseSet(196092-6),Guide
HolderSet(195564-8),OffsetBaseSet(196093-4),DustNozzleSet-PlungeBase(P-80011),Dust
NozzleSet-TrimmerBase(195559-1),SideHandle(153489-2),ToolBag(831327-5)
