WOODWORKING
makita.ca
68
STANDARD EQUIPMENT INCLUDES:
1/4˝ Collet Cone (763663-0),Trimmer Guide (122703-7), Straight Guide (122704-5), Straight Bit 6E (733238-9),Template Guide 10 (343577-5),
Wrench 10 (781036-5), Wrench 17 (781037-3), Chip Deflector (418647-0)
• Rack and Pinion Mechanism for fine depth adjustment
• Adjustable Guide for trimming laminates
• Ergonomic Slim Body style for maximum operator comfort and control
• Soft Rubber Grip design for vibration absorption and comfortable operation
1/4˝ Trimmer
SPECIFICATIONS
Base Type
Transparent Base
Collet Capacity
1/4˝ (6.4 mm)
AMPS (120V)
4.0 A
No Load Speed
30,000 RPM
Overall Height
7-7/8˝ (199 mm)
Net Weight
3.3 lbs. (1.5 kg)
3709
Flush Trimmer – Self-Piloting
For flush, square edges on plastic laminates.
Small diameter allows intricate and close quarter cuts.
No router guides are necessary.
TYPE
A
B
C
D E PART NO.
1/4"
1/4"
1-1/16"
1/4" 1-1/2"
733128-0A
SOLID
CARBIDE
C
B
E
D
A
7° Bevel Trimmer – Self-Piloting
For 7° bevel edging on plastic laminates.
Small diameter allows intricate and close quarter
cuts. No router guides are necessary.
TYPE
A
B
C
D E PART NO.
3/16"
1/4"
1-1/16"
1/4" 1-1/2"
733128-2A
SOLID
CARBIDE
C
B
E
D
A
2 Flute Flush Trimmer
For fast, smooth and accurate 90° flush trimming applications.
Non marring ball bearing pilot.
TYPE
A
B
C
D E PART NO.
1/4"
1/2"
1"
1/4" 2-1/2"
733128-1A
3/8"
1/2"
1"
1/4"
2"
733128-7A
3/8"
1"
1-1/4"
1/4" 2-1/2"
733128-8A
1/2"
1/2"
1-1/4"
1/4"
2"
733128-9A
1/2"
1"
1-1/4"
1/4" 2-1/2"
733129-0A
CARBIDE
TIPPED
C
B
E
D
A
Combination Flush / 10° Bevel Trimmer
Gives both 90° flush or 10° bevel cut depending on depth setting.
Used with guide assembly.
TYPE
A
B
C
D E PART NO.
1/4"
3/8"
1"
1/4" 1-1/2"
733128-5A
SOLID
CARBIDE
C
B
E
D
A
No File Trimmer
Eliminates hand filing of laminates that normally follows trimming.
These specially designed tools will flush trim the laminate and
break the sharp edge all in one pass.
TYPE
A
B
C
D E PART NO.
1/8"
3/8"
1"
1/4" 1-7/8"
733327-A
CARBIDE
TIPPED
B
C
A
D
2 Flute 15° Bevel Trimmer
For smooth 15° bevel cuts.
REPLACEMENT BEARING NO. 733132-4A
TYPE
A
B
C
D E PART NO.
1/2"
9/32"
1"
1/4" 1-7/8"
733128-3A
CARBIDE
TIPPED
2 Flute 25° Bevel Trimmer
For smooth 25° bevel cuts.
REPLACEMENT BEARING NO. 733132-4A
TYPE
A
B
C
D E PART NO.
1/2"
9/32"
1"
1/4" 1-7/8"
733128-4A
SOLID
CARBIDE
C
B
E
D
A
C
B
E
D
A
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
TRIMMER ACCESSORIES
Model
No.
Template
Guide
Straight
Guide
Trimmer
Guide
Trimmer
Base
Trimmer
Shoe
1/4" Collet
Cone
3709 /
3709X 343577-5 122704-5 122703-7 194267-1 155263-4 763663-0
• Rack and Pinion Mechanism for fine depth adjustment
• Adjustable Guide for trimming laminates
• Ergonomic Slim Body style for maximum operator comfort and control
• Soft Rubber Grip design for vibration absorption and comfortable operation
SPECIFICATIONS
Base Type
Transparent Base
Collet Capacity
1/4˝ (6.4 mm)
AMPS (120V)
4.0 A
No Load Speed
30,000 RPM
Overall Height
7-7/8˝ (199 mm)
Net Weight
3.3 lbs. (1.5 kg)
3709X
1/4˝ Trimmer
STANDARD EQUIPMENT INCLUDES:
1/4˝ Collet Cone (763663-0),Trimmer Guide (122703-7), Straight Guide (122704-5),
Straight Bit 6E (733238-9),Template Guide 10 (343577-5), Wrench 10 (781036-5),
Wrench 17 (781037-3), Chip Deflector (418647-0),Aluminum Carrying Case (823293-0)
RT0700CX3
LAMINATE TRIMMING BITS
