Electric
Power Tools
makita.ca
73
STANDARD EQUIPMENT INCLUDES:
2 Ea.Abrasive Belt 80G (A-34469)
Power File/Sander Ideal For Use In Confined Spaces
• 1/4" (125157-7), 3/8" and 1/2" (125159-3) width Sanding Arms available for use in a variety of applications
• Variable Speed Dial adjusts cutting speed based on materials or application
• Precision Belt Tracking Knob for easy adjustment of belt position
• Quick and Easy Belt Changes using Belt Tensioning Lever
• Sanding Arms can be swiveled up to 90° downwards or 10° upwards for maximum operational versatility
• Slim Tension Roller enables sanding and filing in confined areas
Variable Speed
3/8˝ x 21˝ Belt Sander
SPECIFICATIONS
Belt Size
3/8˝ x 21˝
(9 mm x 533 mm)
Belt Speed
980 - 5,600 ft./min.
(300 - 1,700 m/min.)
Maximum Sanding Depth 4-5/16˝ (110 mm)
AMPS (120V)
4.4 A
Overall Length
16-1/2˝ (420 mm)
Cord Length
8.2 ft. (2.5 m)
Net Weight
3.5 lbs. (1.6 kg)
OPTIONAL ACCESSORIES
1/4˝ Arm Assembly (125157-7)
1/2˝ Arm Assembly (125159-3)
9032
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
BELT SANDER ABRASIVE PAPER
Size
Application For
Model(s) Grit
Qty / 2
Qty / 10
1/4" x 21"
(with Arm
Assembly
125157-7)
Aluminum
Oxide for
Wood, Iron
& Metal
9032
#40
-
A-34512
#60
-
A-34528
#80
-
A-34534
#100
-
A-34540
#120
-
A-34556
3/8" x 21"
(with Arm
Assembly
125158-5)
Aluminum
Oxide for
Wood, Iron
& Metal
#40
-
A-34447
#60
-
A-34453
#80
-
A-34469
#100
-
A-34475
#120
-
A-34481
1/2" x 21"
(with Arm
Assembly
125159-3)
Aluminum
Oxide for
Wood, Iron
& Metal
#40
-
A-34562
#60
-
A-34578
#80
-
A-34584
#100
-
A-34590
#120
-
A-34609
1-1/8" x 21"
Silicon
Carbide for
Glass
9031
#60
-
742301-B
#80
-
742301-C
#120
-
742301-D
#180
-
742301-F
#240
-
742301-G
#320
-
742301-I
Aluminum
Oxide for
Wood, Iron
& Metal
#40
-
742301-7
#60
-
742302-5
#80
-
742303-3
#100
-
742304-1
#120
-
742305-9
#150
-
742334-2
#180
-
742336-A
#220
-
742337-A
#240
-
742335-A
3" x 18
Aluminum
Oxide for
Wood, Iron
& Metal
9911KX1
#40 794552-A-2 794552-A
#60 794553-A-2 794553-A
#80 794551-A-2 794551-A
#100 794554-A-2 794554-A
#120 742313-A-2 742313-A
3" x 21"
Aluminum
Oxide for
Wood, Iron
& Metal
9903
#40 794119-F-2 742306-7
#60 794119-A-2 742307-5
#80 794119-B-2 742308-3
#100 794119-C-2 742309-1
#120 794119-D-2 742310-6
#150 794119-E-2 742311-4
3" X 24"
Aluminum
Oxide for
Wood, Iron
& Metal
9920
9924DB
#40 794237-A-2 742312-8A
#60 794237-B-2 742312-8B
#80 794237-C-2 742312-8C
#100 794237-D-2 742312-8D
#120 794237-E-2 742312-8E
#150 794237-F-2 742312-8F
4" X 24"
Aluminum
Oxide for
Wood, Iron
& Metal
9403
9404
#40 794133-A-2 742320-3
#60 794133-B-2 742321-1
#80 794133-C-2 742322-9
#100 794133-D-2 742323-7
#120 794133-E-2 742324-5
#150 794133-F-2 742325-3
BELT SANDER STANDS
Model No.
Description
Part No.
9032
Belt Sander
Stand
193618-5
9903, 9904, 9920
193055-3
9924DB
122299-8
BELT SANDER SANDING SHOES
Model No.
Description
Part No.
9404
Belt Sander Sanding
Shoe Assembly
193072-3
9903
193070-7
9920
193071-5
BELT SANDER CLAMPS
Part No.
Description
For Model
192694-6 Belt Sander Clamps
(Set of 2)
9911KX1
BELT SANDER PLATES
Model
Steel Plate
Cork Plate
Graphite Plate
9403
344620-3
421646-3
421648-9
9404
151751-9
423314-4
423317-8
9903
151749-6
423312-8
423315-2
9911KX1
344586-7
-
-
9920
151750-1
423313-6
423316-0
9924DB
341705-6
423035-8
423036-6
Steel Plate may be used as optional replacement for Graphite Plate
