WOODWORKING
makita.ca
70
Straight – 2 Flute 1/4" Shank
For general purpose routing and grooving where
smoothness of cut and minimal vibration are desired
TYPE
A
B
C
D E PART NO.
SOLID CARBIDE*
1/8"
7/16"
1-3/8"
1/4"
2"
733003-1A
1/16"
1/4"
1-1/8"
1/4" 1-5/8"
733250-A
3/16"
7/16"
1-3/8"
1/4"
2"
733003-2A
1/4"
3/4"
1-3/16"
1/4"
2"
733003-4A
1/4"
1"
1-3/16"
1/4"
2"
733003-6A
5/16"
1"
1-1/8"
1/4"
2"
733003-8A
3/8"
1"
1-1/8"
1/4" 2-1/4"
733004-0A
7/16"
1"
1"
1/4" 2-1/8"
733004-1A
1/2"
1"
1-1/8"
1/4" 2-1/8"
733004-2A
5/8"
3/4"
1-1/8"
1/4"
2"
733004-4A
3/4"
3/4"
1-1/8"
1/4"
2"
733004-6A
CARBIDE
TIPPED
C
B
E
D
A
2 Flute Flush Trimmer
For fast, smooth and accurate 90° flush trimming applications.
Non marring ball bearing pilot. 1/4" (REPLACEMENT BEARING
NO. 733132-1A) (3/8" REPLACEMENT BEARING NO. 733132-2B)
(1/2" REPLACEMENT BEARING NO. 733132-4A)
TYPE
A
B
C
D E PART NO.
1/4"
1/2"
1"
1/4" 2-1/2"
733128-1A
3/8"
1/2"
1"
1/4"
2"
733128-7A
3/8"
1"
1-1/4"
1/4" 2-1/2"
733128-8A
1/2"
1/2"
1-1/4"
1/4"
2"
733128-9A
1/2"
1"
1-1/4"
1/4" 2-1/2"
733129-0A
1/2"
1"
1-1/4"
1/2"
3"
733129-1A
1/2"
2"
1-1/4"
1/2"
4"
733274-A
CARBIDE
TIPPED
C
B
E
D
A
Straight – Single Flute
For rough routing, grooving and general stock removal
Single flute gives more efficient chip clearance for improved feed rates.
1/2" shank bits are for maximum strength production use.
TYPE
A
B
C
D E PART NO.
1/4"
1"
1-3/16"
1/4"
2"
733001-0A
1/2"
2"
2-1/16"
1/2" 4-1/4"
733002-6A
CARBIDE TIPPED
C
B
E
D
A
Straight – 2 Flute, 1/2" Shank
Larger 1/2" shank is stronger for production use situations
TYPE
A
B
C
D E PART NO.
3/8"
1"
1-1/4"
1/2" 2-3/4"
733005-4A
1/2"
1"
1-5/16"
1/2" 2-5/8"
733252-A
1/2"
1-1/4" 1-7/16"
1/2" 2-7/8"
733005-6A
1/2"
1-1/2" 1-1/4"
1/2" 3-1/8"
733005-8A
1/2"
2"
2"
1/2" 4-1/4"
733005-9A
1/2"
2-1/2" 1-1/16"
1/2" 4-1/2"
733254-A
3/4"
1-1/4" 1-1/4"
1/2" 2-7/8"
733006-4A
7/8"
1-1/4" 1-3/16"
1/2" 2-7/8"
733006-6A
1"
1-1/4" 1-3/16"
1/2" 2-7/8"
733006-8A
CARBIDE TIPPED
C
B
E
D
A
Core Box
For high quality radius cuts, rounded grooves, letter cutting,
reeding, fluting and general ornamentation.
TYPE RADIUS A
B
C
D E PART NO.
1/8"
1/4"
15/32" 1-1/4" 1/4" 1-1/2" 733008-2A
3/16"
3/8"
9/16"
1-1/4" 1/4" 1-1/2" 733008-4A
1/4"
1-2"
11/16" 1-1/4" 1/4" 1-1/2" 733008-6A
5/16"
5/8"
11/16" 1-1/4" 1/4" 1-1/2" 733008-8A
3/8"
3/4"
13/16" 1-1/4" 1/4" 1-1/2" 733009-0A
1/2"
1"
5/8"
15/16" 1/4" 1-3/4"
733270-A
CARBIDE
TIPPED
C
B
E
D
A
Panel Pilot
For fast door and window cutouts through covering sheets.
Drill-thru pilot point allows fast plunging and acts as pilot for guiding on
framing after panels have been mounted.
TYPE
A
B
C
D E PART NO.
1/4"
3/4"
1"
1/4" 2-1/2"
733030-2A
1/2"
1-1/8" 1-1/2"
1/2" 3-1/2"
733030-6A
CARBIDE TIPPED
C
B E
D
A
Top Bearing Straight – 2 Flute
For cutting grooves, dadoes and rabbets. Cuts flush with bearing
to give exact duplication of template.
REPLACEMENT BALL BEARING NO. 733132-5A
TYPE
A
B
C
D E PART NO.
1/2"
1/2"
1"
1/4" 1-5/8"
733325-A
1/2"
1"
1-1/4"
1/4"
2"
733012-1A
5/8"
1"
7/8"
1/4" 2-1/8"
733258-A
3/4"
1"
13/16"
1/4" 2-1/4"
733259-A
1"
1"
1-1/8"
3/8" 2-3/4"
733260-A
CARBIDE TIPPED
C
B
E
D
A
Top Bearing Round Nose & V Grooving–2 Flute
For cutting decorative grooves where template is on top of the workpiece. Gives
exact duplication of template. REPLACEMENT BALL BEARING NO. 733132-5A
TYPE A
B
C
D E PART NO.
1/2"
1/2"
1-1/2"
1/4"
2"
733013-1A
1/2"
1/2"
1-1/2"
1/4"
2"
733014-1A
CARBIDE
TIPPED
C
B
E
A
Beading
For decorative molding or edging. Rounds corners and produces small
edge beads. Shallower depth setting eliminates top edge bead.
REPLACEMENT BEARING NO. 733132-2B
TYPE
A
B
C
D E PART NO.
3-1/16"
3/8"
1-1/4"
1/4" 1-3/4"
733121-4A
1/4"
1/2"
1-1/4"
1/4" 1-3/4"
733121-6A
5/16"
1/2"
1-1/4"
1/4" 1-7/8"
733121-8A
3/8"
5/8"
1-1/4"
1/4" 1-7/8"
733122-0A
1/2"
3/4"
1-1/4"
1/4"
2"
733122-2A
C.T. BALL
BEARING
PILOT
C
B
E
D
A
V Grooving
For sign lettering, decorative work, plank simulation on panels, and
cabinet door grooving. Recommended maximum depth of cut is not
greater than half of the cutting diameter, F.
TYPE
A
B
C
D E
F PART NO.
1/8"
1/2"
1-3/16"
1/4" 1-3/4"
3/8" 733009-2A
7/16"
3/4"
1-5/16"
1/4" 1-7/8"
5/8" 733009-4A
9/16"
7/8"
1"
1/4"
2"
7/8" 733009-5A
C
B
E
D
F
A
CARBIDE
TIPPED
Dovetail
For smooth dovetail joints and drawer fingers
TYPE
A
B
C
D E DEGREE PART NO.
9/16"
25/64" 1-49/64" 1/4" 2-5/32" 35˚
793372-7
9/16"
25/64" 1-49/64" 1/4" 2-5/32" 35˚
793373-5
9/16"
9/16" 1-19/32" 1/4" 2-5/32" 23˚
793374-3
1/2"
1/2"
1-3/8"
1/2" 2-1/8"
14˚
733265-A
CARBIDE
TIPPED
C
B
E
D
F
A
Keyhole Slot
Plunge cut followed by a side movement of router produces the slot for
screw and nail heads for mounting picture frames, plaques.
TYPE
A
B
C
D E PART NO.
3/8"
3/8"
1"
1/4" 1-1/2"
733010-1A
CARBIDE TIPPED
C
B
E
D
A
Corner Rounding
For smooth decorative edge rounding or molding. Lower depth setting
produces a rounded corner with a decorative bead.
REPLACEMENT BEARING NO. 733132-4A NO. 733132-2A
TYPE
A
B C
D E LRG. DIAM. PART NO.
1/8"
1/2"
1-1/4"
1/4"
2-1/4"
-
733120-1A
3/16"
3/8"
1-1/4"
1/4"
1-3/4"
-
733120-0A
1/4"
1/2"
1-1/4"
1/4"
1-3/4"
-
733120-2A
1/4"
1/2"
1-5/16" 1/2"
2-1/8"
1"
733291-A
5/16"
1/2"
1-1/4"
1/4"
1-7/8"
-
733120-4A
3/8"
5/8"
1-1/4"
1/4"
1-7/8"
-
733120-6A
1/2"
3/4"
1-1/4"
1/4"
2"
-
733120-8A
3/8"
5/8"
1-1/2"
1/2"
2-1/4"
-
733121-0A
1/2"
3/4"
1-1/2"
1/2"
2-3/8"
-
733121-2A
(1)* 5/8" 7/8"
1-5/16" 1/2"
2-3/8" 1-3/4"
733292-A
(2)* 3/4"
1"
1-5/16" 1/2"
2-3/8"
2"
733293-A
(3)* 1" 1-1/4" 1-3/8"
1/2" 3-3/16" 2-1/2"
733329-A
C.T. BALL
BEARING
PILOT
C
B
E
D
A
MAX. RPM:
(1)–14,000
(2)–14,000
(3)–12,000
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Supertrim Flush Trim
Upshear trim bits for exceptional speed and super-fine finish.
Furnished with steel bearing.
TYPE
A
B
C
D E PART NO.
3/4"
1-1/2" 1-1/4"
1/2" 3-7/8"
733326-A
CARBIDE
TIPPED
C
B
E
D
A
RP2301FC
ROUTER
BITS
