Electric
Power Tools
makita.ca
77
STANDARD EQUIPMENT INCLUDES:
Socket Wrench (782209-3),Triangular Rule (762001-3), High Speed Steel Blades (B-02870)
2-Blade Cutter Head Makes 24,000 CPM
• Unrivaled for power, size and performance
• Larger and sturdy sole plate for added stability
• Front roller for easy moving over rough materials
• Guide rule for accurate and maximum use of planing width
• Poly ˝V˝ belt designed with grooves efficiently transfers power from the motor to the blades
• Large ejection chute provides high rate of chip discharge
12-1/4˝ Planer
SPECIFICATIONS
Maximum Capacities:
Planing Width
12-1/4˝ (312 mm)
Planing Depth
1/8˝ (3.5 mm)
No Load Speed
12,000 RPM
AMPS (120V)
15.0
Cord Length
33 ft. (10 m)
Overall Length
21-3/4˝ (551 mm)
Net Weight
40.6 lbs. (18.4 kg)
KP312
STANDARD EQUIPMENT INCLUDES:
6-3/4˝ HSS Planer Blades (793186-4), Sharpening HolderAssembly (123006-2), Hex Wrench 4 (783202-0),Triangular Rule (762001-3),
Guide Rule (123053-3), Wooden Carrying Case (no replacement)
30,000 Cuts Per Minute
• Unrivaled for power, size and performance
• Large Base Plate for maximum stability
• Machined Aluminum Base for planing accuracy
• Depth Adjustment Knob for precision planing applications
• Lock-On Button enables easy continuous operation
6-3/4˝ Planer
SPECIFICATIONS
Maximum Capacities:
Planing Width
6-3/4˝ (170 mm)
Planing Depth
1/16˝ (2 mm)
No Load Speed
15,000 RPM
AMPS (120V)
10.9 A
Overall Length
20-3/4˝ (529 mm)
Net Weight
19.8 lbs. (9.0 kg)
1806B
STANDARD EQUIPMENT INCLUDES:
4-3/8˝ HSS Planer Blades (793008-8), Blade GaugeAssembly (123010-1), Sharpening HolderAssembly (123055-9),
Socket Wrench 9 (782209-3), Guide Rule Set (191455-1)
32,000 Cuts Per Minute
• Single Chamfering Groove enables quick and easy chamfering of corners
• Depth Adjustment Knob for precision planing applications
• Machined Aluminum Base for planing accuracy
• Lock-On Button enables easy continuous operation
4-3/8˝ Planer
SPECIFICATIONS
Maximum Capacities:
Planing Width
4-3/8˝ (110 mm)
Planing Depth
1/16˝ (2 mm)
No Load Speed
16,000 RPM
AMPS (120V)
7.5 A
Overall Length
14˝ (355 mm)
Net Weight
9.5 lbs. (4.3 kg)
1911B
STANDARD EQUIPMENT INCLUDES:
3-1/4˝DoubleEdgedMiniPlanerBlades(793322-2),BladeGaugeAssembly(123010-1),SocketWrench9(782209-3),GuideRule(122785-9),
Depth Guide (342390-8)
Heavy Duty, Lightweight Design For High Efficiency Surface Planing
• Soft Start feature gradually increases speed to eliminate start up shock
• Base Plate Foot protects materials and blade from damage
• Three Chamfering Grooves enable quick and easy chamfering of corners
• Depth Adjustment Knob with Click Stops for precision planing applications
• Lock-On Button enables easy continuous operation and can be operated from left or right side
• Left or Right Side Chip Ejection
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Soft Start
3-1/4˝ Planer
SPECIFICATIONS
Maximum Capacities:
Planing Width
3-1/4˝ (82 mm)
Planing Depth
0-5/32˝ (0 - 4 mm)
Shiplapping
0 - 1˝ (0 - 25 mm)
No Load Speed
16,000 RPM
AMPS (120V)
7.5 A
Overall Length
11-3/8˝ (290 mm)
Net Weight
7.3 lbs. (3.3 kg)
KP0810
STANDARD EQUIPMENT INCLUDES:
Sharpening HolderAssembly (123055-9), Socket Wrench 9 (782209-3), Blade Gauge (123010-1), 4-3/8˝ Planer Blade (793008-8)
For Even Stock Removal Over Dips & Rises In Wood
• Machined aluminum base for maximum precision and accuracy
• Lock-On button for continuous operation
• Excellent for finishing saddles in log framing applications
4-3/8˝ Curved Planer
SPECIFICATIONS
Maximum Capacities:
Planing Width
4-3/8˝ (110 mm)
Planing Depth
5/32˝ (4 mm)
Curve Radial Cuts 11-3/16˝ (300 mm)
No Load Speed
15,000 RPM
AMPS (120V)
9.6 A
Curved Radius
12-19/32˝ (320 mm)
Overall Length
13-5/16˝ (339 mm)
Net Weight
11.5 lbs. (5.2 kg)
1002BA
STANDARD EQUIPMENT INCLUDES:
KP0800KX:
2Set3-1/4˝ DoubleEdgedMiniPlanerBlades(D-16966),BladeGaugeAssembly(123010-1),SocketWrench9(782209-3),
GuideRule(165581-2),PlasticCarryingCase(824892-1)
KP0800:
3-1/4" Double Edged Mini Planer Blades (D-16966), Blade GaugeAssembly (123010-1), Socket Wrench 9 (782209-3),
Guide Rule (165581-2)
Lightweight Design For Easy Surface Planing
• Base Plate Foot protects materials and blade from damage
• Single Chamfering Groove enables quick and easy chamfering of corners
• Depth Adjustment Knob with Click Stops for precision planing applications
• Lock-On Button enables easy continuous operation and can be operated from left or right side
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
3-1/4˝ Planer
SPECIFICATIONS
Maximum Capacities:
Planing Width
3-1/4˝ (82 mm)
Planing Depth 0 - 3/32˝ (0 - 2.5 mm)
Shiplapping
0 - 11/32˝ (0 - 9 mm)
No Load Speed
17,000 RPM
AMPS (120V)
6.5 A
Overall Length
11-1/4˝ (285 mm)
Net Weight
5.7 lbs. (2.6 kg)
KP0800KX
KP0800
