78
STANDARD EQUIPMENT INCLUDES:
3-1/4˝ Double Edged Mini Planer Blades (D-16966), Blade GauageAssembly (123010-1), Socket Wrench 9 (782209-3)
32,000 Cuts Per Minute
• Single Chamfering Groove enables quick and easy chamfering of corners
• Depth Adjustment Knob for precision planing applications
• Machined Aluminum Base for planing accuracy
• Lock-On Button enables easy continuous operation
3-1/4˝ Planer
SPECIFICATIONS
Maximum Capacities:
Planing Width
3-1/4˝ (82 mm)
Planing Depth
1/32˝ (1 mm)
No Load Speed
16,000 RPM
AMPS (120V)
5.2 A
Overall Length
11-3/8˝ (290 mm)
Net Weight
6.0 lbs. (2.7 kg)
1902
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
PLANER & PLATE JOINER BLADES
Style
Description
For Model(s)
2 / Pk Part No.
3-1/4" Planer
Blades
High Speed Steel - Single Edge
1902
KP0800 / KX
KP0810
DKP180RFE / F / Z
D-17217
Carbide - Single Edge
D-17223
Carbide - Double Edge
Mini Blade
D-16966 (35°)
793322-2 (50°)
A-82921 (65°)
Carbide Mini Blades & Set Plate
D-17239
4-3/8" Planer
Blades
High Speed Steel - Single Edge
1002BA
1911B
793008-8
Carbide - Single Edge
D-17245
6-3/4" Planer
Blades
High Speed Steel - Single Edge
1806B
793186-4
12" Thickness
Planer Blades
High Speed Steel - Double Edge /
Reversible
2012NB
793346-8
12-1/4" Planer
Blades
High Speed Steel - Double Edge /
Reversible
KP312
B-02870
4" Plate Joiner
Blades
4" Diameter / 6 Teeth /
22mm Arbor
3901
DPJ180RFE / Z
PJ7000
A-95118
NOZZLE ASSEMBLY
For non-clogging chip deflection in desired direction
Part No.
Description
For Model(s)
451329-1
Nozzle Assembly
KP0800 / KX, DKP180RFE / F / Z
416368-8
KP0810
122194-2
N1900BK, N1923B
DUST COLLECTION BAGS
Part No.
Description
For Model(s)
122230-4
Dust Collection Bags
N1900BK, 1902, N1923B
122402-1
1911B
122793-0
KP0800 / KX, KP0810
DKP180RFE / F / Z
BEVEL GUIDES
For 0-45° bevel cuts
Part No.
Description
For Model(s)
123053-3
Bevel Guides
1806B
122791-4
KP0810C
123060-6
KP0800K / KX, 1902
STRAIGHT GUIDE RULE
Part No.
Description
For Model(s)
165581-2
Straight Guide Rule
KP0800K / KX, DKP180RFE / F / Z
122785-9
KP0810
191455-1
1902, 1911B
164191-2
3803A
EXTENSION GUIDE SETS
Part No.
Description
For Model(s)
191725-8
Extension
Guide Set
KP0800K / KX, 1902
1911B
BLADE GAUGE ASSEMBLY
For fast accurate blade setting
Part No.
Description
For Model(s)
123006-2 Blade Gauge Assembly
1806B
123010-1
1902, 1911B, KP0800K / KX, KP0810
DKP180RFE / F / Z
SHARPENING HOLDER ASSEMBLY
For honing dull blades with dressing stone
Part No.
Description
For Model(s)
123004-6
Sharpening Holder Assembly
1902, DKP180RFE / F / Z
KP0800K / KX, KP0810
123006-2
1806B
123055-9
1911B, 1002BA
DRESSING STONE
For use with sharpening holder
Part No.
Description
Grit
Size
794060-9 Dressing Stone (Wet)
WA1200
7-1/4" x 2-3/4"
x 3/4"
794061-7
6" x 2-3/4" x 3/4"
Cuts Grooves To A Predetermined Depth Setting
• Fastest and easiest blade change on the market
• Depth adjusting knob for quick adjustments of cutting depth
• Large chip ejection chute allows stock to be removed rapidly
SPECIFICATIONS
Max. Cutter Blade Size 4-3/4˝ x 1-13/16˝
(120 mm x 46 mm)
Max. Cutting Depth
1-7/32˝ (31 mm)
No Load Speed
9,000 RPM
AMPS (120V)
13.0 A
Overall Length
6-3/16˝ (411 mm)
Net Weight
13.7 lbs. (6.2 kg)
4-3/4˝ Groove Cutter
STANDARD EQUIPMENT INCLUDES:
Shiplapping ScaleAssy. (192270-6), Guide Rule (164191-2) Wrench #19 (781206-6) #21(781029-2), Side Plates (414961-2)
and (414963-8) Cutter (793128-8), Flange (224051-1), Wooden Carrying Case (Not replaceable)
GROOVE CUTTER BLADES
Imperial
Diameter
Metric
Diameter
Imperial
Width
Metric
Width
# of Cutting
Teeth Application For
Model
Part No.
4-3/8" 110mm 1-7/16" 39 mm 2
Dados
3803A
793313-3
4-3/4"
120mm
1/2" 12 mm 4
Grooves
793298-3
5/8" 15 mm 4
793129-6
5/8" 15 mm 2
793039-7
3/4" 18 mm 4
793130-1
7/8" 21 mm 4
793128-8
1-1/8" 30 mm 4
793131-9
1-1/8" 30 mm 2
793043-6
1-5/16" 33 mm 4
793132-7
3803A
