LITHIUM-ION
makita.ca
16
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
1/2˝ Square Drive,
Variable Speed, Reversible
Compact And
Lightweight
Design With High
Maximum Fastening Torque
• Same Fastening Torque in forward and reverse rotation
• Rubber Joint Construction suppresses transmission
of vibration to battery, minimizing battery failures due
to terminal breakage or poor electrical contact
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Square Drive
1/2˝ Square
No Load Speed
1,600 RPM
Impacts Per Minute
2,200 IPM
Maximum Torque 325 ft. lbs. (440 Nm)
Overall Length
10-1/2˝ ( 266 mm)
Net Weight
7.5 lbs. (3.4 kg)
STANDARD EQUIPMENT INCLUDES:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830
(194205-3), Charger (DC18RC), Hook
(345736-7), Battery Cover (450128-8),
Plastic Carrying Case (824777-1)
STANDARD EQUIPMENT INCLUDES:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3),
Hook (345736-7)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger
Sold Separately.
Hook (345736-7)
Round
Head Pin
Flat
Head Pin
STANDARD EQUIPMENT INCLUDES:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830
(194205-3), Charger (DC18RC), Hook
(345736-7), Battery Cover (450128-8),
Plastic Carrying Case (824777-1)
STANDARD EQUIPMENT INCLUDES:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3),
Hook (345736-7)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger
Sold Separately.
Hook (345736-7)
DTW450RFE, DTW450F, DTW450Z, DTW450XRFE, DTW450FX1, DTW450XZ
1/2˝ Cordless Impact Wrenches
DTW450RFE
DTW450F
DTW450Z
DTW450XRFE
DTW450FX1
DTW450XZ
STANDARD EQUIPMENT INCLUDES:
DTD145RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Battery Cover (450128-8), Hook (346449-3),
Plastic Carrying Case (824812-5)
DTD145F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), Hook (346449-3)
DTD145Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
1/4˝ Cordless Impact Driver with Brushless Motor
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed:
0 - 2,600 / 0 - 2,000 / 0 - 1,300 RPM
Impacts Per Minute:
0 - 3,400 / 0 - 2,800 / 0 - 1,300 IPM
Maximum Torque: 200 / 490 / 1,460 in.lbs.
(22.6 / 55.4 / 165 Nm)
Overall Length
5-1/2˝ (139 mm)
Net Weight
3.3 lbs. (1.5 kg)
DTD145RFE
DTD145F
DTD145Z
DTD129RFE
STANDARD EQUIPMENT INCLUDES:
DTD129RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Battery Cover (450128-8), Hook (346449-3),
Plastic Carrying Case (821532-2)
DTD129Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Compact and Lightweight Design with Brushless DC Motor
• Brushless DC Motor with high power to weight and size ratio
• Brushless DC Motor generates less heat buildup and is ideal for prolonged use in
manufacturing / production applications
• Battery Protection System provides Over-Discharge, Temperature and Circuit Protection for
enhanced performance, battery cycle life and overall battery life
• LED Job Light
• Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation
1/4˝ Cordless Impact Driver with Brushless Motor
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed
0 - 2,500 RPM
Impacts Per Minute
0 - 3,200 IPM
Maximum Torque
1,420 in. lbs. (160 Nm)
Overall Length
5-7/8˝ (147 mm)
Net Weight
3.4 lbs. (1.5 kg)
Variable Speed,
Reversible
DTD129Z
Compact Design And Brushless DC Motor
• 3 Stage Impact Power Selection prevents over tightening of fasteners
• Battery Power Warning Light indicates when low battery capacity has been reached
• Brushless DC Motor with high power to weight and size ratio
• Brushless DC Motor generates less heat buildup and is ideal for prolonged use in manufacturing /
production applications
• LED Job Light with Afterglow feature and independent On / Off switch
• Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation
Variable 3 - Speed,
Reversible
DTD146RFE
STANDARD EQUIPMENT INCLUDES:
DTD146RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3),Charger(DC18RC),Hook(346449-3),PlasticCarryingCase(824812-5)
DTD146SYE:
Two18V(Compact)Li-IonBatteries
BL1815N(196235-0),Charger(DC18SD),Hook(346449-3),PlasticCarryingCase(824812-5)
DTD146F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), Hook (346449-3)
DTD146Z
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Compact and Lightweight Design with Overall Length of 5-7/16˝
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Battery Protection System provides Over-Discharge, Temperature and Circuit Protection for
enhanced performance, battery cycle life and overall battery life
• Increased Max. Torque of 1,420 in. lbs.
• One-Touch Bit Holder enables quick and easy bit installation
Variable Speed, Reversible
1/4˝ Cordless Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed
0 - 2,300 RPM
Impacts Per Minute
0 - 3,200 IPM
Maximum Torque 1,420 in. lbs. (160 Nm)
Overall Length
5-7/16˝ (138 mm)
Net Weight
3.3 lbs. (1.5 kg)
DTD146SYE
DTD146F
DTD146Z
DTW281RFE
STANDARD EQUIPMENT INCLUDES:
DTW281RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Hook (346449-3), Battery Cover (450128-8),
Plastic Carrying Case (142793-4)
DTW281Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Features Increased Maximum Fastening Torque And Ultra-Compact Design
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 3 stage impact power selection prevents over-tightening of fasteners
• Battery fuel gauge indicates approximate remaining battery power
• Brushless DC motor with high power to weight and size ration
1/2˝ Cordless Impact Wrench with Brushless Motor
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Square Drive
1/2˝
No Load Speed
0 - 1,300/2,100/2,800 RPM
Impacts Per Minute
0 - 1,800/2,800/3,500 IPM
Maximum Torque
207 ft.lbs (280 Nm)
Overall Length
5-3/4˝ (147 mm)
Net Weight
4.0 lbs (1.8 kg)
DTW281Z
1/2˝ Square Drive,
Variable 3-Speed,
Reversible
