SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ Hex
No Load Speed
0 - 2,800 / 2,300 / 1,400 RPM
Impacts Per Minute
0 - 3,400 / 2,800 / 1,300 IPM
Maximum Torque
220 / 490 / 1,500 in.lbs (25 / 55 / 170 Nm)
Overall Length
5-1/8˝ (129 mm)
Net Weight
3.3 lbs (1.5 kg)
DTD147RME
DTD147Z
STANDARD EQUIPMENT INCLUDES:
DTD147RME:
Two 18V (4.0Ah) Li-Ion Batteries
BL1840
(196401-9), Charger (DC18RC), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case (821521-7)
DTD147Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Variable 3-Speed, Reversible
Improved Heavy Duty Design and Brushless DC Motor
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• 3 Stage Impact Power Selection + TEK Mode prevents over tightening of fasteners
• TEK mode reduces impact power during final stages of fastener seating
• Battery Fuel Gauge indicates approximate remaining battery power
• Brushless DC Motor with high power to weight and size ratio
• Brushless DC Motor generates less heat buildup and is ideal for prolonged use in manufacturing /
production applications
• Battery Protection System provides Over-Discharge, Temperature and Current Protection for
enhanced performance, battery cycle life and overall battery life
• LED Job Light with Pre-Glow and Afterglow features
• Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation
DTD147RME, DTD147Z
1/4˝ Cordless Impact Drivers with Brushless Motor
PICTURED: DTD147RME
Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
1/2˝ (13 mm)
Steel
1/2˝ (13 mm)
Wood
1-7/16˝ (36 mm)
Blows Per Minute:
Low
0 - 6,000 BPM
High
0 - 19,500 BPM
Maximum Torque 340 in. lbs. (38 Nm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,300 RPM
Overall Length
9-7/16˝ (240 mm)
Net Weight
2.9 lbs. (1.3 kg)
BHP453H
Hammer Driver Drill
STANDARD EQUIPMENT INCLUDES:
Two 18V (Compact) Li-Ion Batteries
BL1815N (196235-0),Charger
(DC18SD),BatteryCover(450128-8),DoubleEndedBit(784636-0),Hook
(346034-2),KeylessDrillChuck(763193-1),PlasticCarryingCase(158777-2)
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
1/2˝ (13 mm)
Wood
1-7/16˝ (36 mm)
Maximum Torque 340 in. lbs. (38 Nm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,300 RPM
Overall Length
8-3/4˝ (222 mm)
Net Weight
2.6 lbs. (1.2 kg)
DDF453SYE
Driver Drill
STANDARD EQUIPMENT INCLUDES:
Two 18V (Compact) Li-Ion Batteries
BL1815N (196235-0),
Charger (DC18SD), Double Ended Bit 2-65 (784636-0),
Battery Cover (450128-8), 1/2˝ Keyless Drill Chunk (763193-1),
Hook (346034-2), Plastic Carrying Case (158777-2)
Compact And Lightweight Design
• 16 Clutch Settings deliver up to 340 in. lbs. of torque
• Single Sleeve Keyless Drill Chuck for easy bit
installation and removal
• Compact and lightweight design (Only 8-15/16˝ length)
• All Metal Gears for more efficient power transmission
• Ergonomic Soft Rubber Grip design for vibration
absorption and comfortable operation
BHP453H, DDF453SYE
1/2˝ Cordless Hammer / Driver Drills
Variable 2-Speed, Reversible
PICTURED: BHP453H
Hammer Driver Drill
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
1/2˝ (13 mm)
Wood
1-1/2˝ (38 mm)
No Load Speed:
Low
0 - 400 RPM
High
0 - 1,500 RPM
Maximum Torque
480 in. lbs. (54 Nm)
Overall Length
7-9/16˝ (192 mm)
Net Weight
3.7 lbs. (1.7 kg)
DDF456RFE
DDF456SYE
DDF456Z
STANDARD EQUIPMENT INCLUDES:
DDF456RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Battery Cover (450128-8), Double Ended
Bit 2-45 (784637-8), 1/2˝ Keyless Chuck (766008-1), Hook (346449-3), Plastic Carrying Case (821521-7)
DDF456SYE:
Two 18V (Compact) Li-Ion Batteries
BL1815N (196235-0), Charger (DC18SD), Battery Cover (450128-8),
Double Ended Bit 2-45 (784637-8), 1/2˝ Keyless Chuck (766008-1), Hook (364449-3), Plastic Carrying Case (821521-7)
DDF456Z:
Tool Only. Batteries and Charger Sold Separately.
Double Ended Bit 2-45 (784637-8), 1/2" Keyless Chuck (766008-1), Hook (346449-3)
Incorporates Makita's Battery
Protection System, High Power
And Ultra-Compact Design
• Battery Protection System provides Over-Discharge,
Temperature and Current Protection for enhanced performance,
battery cycle life and overall battery life
• 16 Clutch Settings deliver up to 480 in. lbs. of torque
• All Metal Gears for more efficient power transmission
• Ultra-Compact Design (Only 8-1/8
˝
Long)
• LED Job Light with Afterglow feature
• Improved Ergonomic Soft Rubber Grip for vibration
absorption and comfortable operation features
re-contoured rear grip portion and ribbed grip for
improved hold
DDF456RFE, DDF456SYE, DDF456Z
1/2˝ Cordless Driver Drills
PICTURED: DDF456RFE
Driver Drill
Variable 2-Speed,
Reversible
