LITHIUM-ION
DUB362Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Front Nozzle (455914-2), Long Nozzle (455915-0)
Our Most Powerful Cordless Blower Yet!
Amazing 120 MPH and 473 CFM Operation
• Powered by two 18V Li-ion batteries in series to supply energy to the powerful 36V DC motor drive system
• 6-stage air volume/velocity settings by dial with variable speed control by trigger
• The trigger also has a lock on function, with button operable from either side of handle
• 3-stage telescopic long nozzle with adjustment range of 100 mm (4")
• Dual battery fuel gauges
• Best grip to frame angle provides optimum
nozzle to ground angle for efficient
sweeping operation
• Lightweight & compact for single
handed operation
• Longer run time thanks to
brushless motor
Turbo Blower
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Max. Air Volume 473 CFM (13.4 m
3
/min)
Max. Air Velocity 120 MPH (54 m/sec)
No Load Speed
22,000 RPM
Overall Length 32-3/4˝, 34-3/4˝, 36-5/8˝
(830 mm, 880 mm, 930 mm)
Net Weight
6.0 lbs (2.7 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (Floor Nozzle) (122512-4), Hose Complete 38-2.5M (195434-1),
Hose Complete 28-3.5M (195433-3), Poly Bag 10Pc/Set (195432-5), Straight Pipe (192563-1), Bending Pipe (192562-3),
Corner Nozzle (410306-2), HEPAFilter Set (197166-6), Damper Set (195552-5), Prefilter Set (195553-3),AccessoryTool Box (455732-8)
Operates With AC (120V) Or DC (18Vx2 Li-Ion) Power Sources
For Maximum Jobsite Efficiency And Versatility
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing
18V Li-ion battery platform
• Variable suction power enables operator to adjust the suction power to the application
• Large on/off switch enables easy operation
• HEPA Filter suitable for use
with dry L Class materials only
• Battery cover protects
batteries against water
penetration
• Caster stoppers protects
vacuum cleaner against
unintentional movement
during operation
Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Maximum Air Flow
74 CFM (2.1 m
3
/min) on DC power
127 CFM (3.6 m
3
/min) on AC power
Tank Capacity
8.0 L
AMPS (120V)
9.2 A
Power Cord Length
19.7 ft (6.0 m)
Overall Dimensions (L x W x H)
14-3/8˝ x 13-1/8˝ x 14-1/2˝
(366 mm x 334 mm x 368 mm)
Net Weight
19.2 lbs (8.7 kg)
DVC861LZ
L Class Vacuum Cleaner
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
HEPAFilterAssembly (123636-9), Hose Complete 28-1.0M (14377-28),
Hose Band (166116-2), Paper Filter Bag Set (197902-0), Flexible Rubber Nozzle Set (197900-4), NozzleAssembly (Floor Nozzle) (123486-2),
Telescopic PipeAssembly (123584-2), Bent PipeAssembly (123677-5), Backpack Shoulder Harness (161479-1)
Makita's FIRST Backpack Style Vacuum Cleaner
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing
18V Li-Ion battery platform
• Brushless DC motor with high power
to weight and size ratio
• Standard equipment HEPA filter
offers 99.97% efficiency greater
than or equal to 3 microns
• Backpack design offers
unparalleled maneuverability
and versatility
Backpack Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Maximum Air Flow 53 CFM (1.5 m
3
/min)
Maxiumum Sealed Suction
7.1 kPa (710 mm H
2
O)
Maximum Bag Capacity
2.0 L
Suction Power (high mode)
45 W
Overall Dimensions (L x W x H) (no battery)
9˝ x 6˝ x 14-3/4˝
(230 mm x 152 mm x 373 mm)
Net Weight
6.9 lbs (3.1 kg)
DVC260Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Wireless Remote Controller (SH00000238), Side Brush (SH00000065),
BoundaryTape 15m (SH00000240)
19 Sensors Enable Optimal Vacuuming Performance
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing
18V Li-Ion battery platform
• Brushless DC motor with high power to weight and size ratio
• Brushless DC motor generates less heat buildup and is ideal for periods of prolonged use
• Operates in random or pattern mode for maximum vacuuming efficiency
• Two dust collection modes, vacuum plus power brush for small and large debris and power brush only for
large debris, suitable for a wide range of vacuuming applications
• 19 sensors (bumper sensor, gyro sensor, 2 x IR sensors, 4 x IR cliff sensors, magnetic field sensor,
2 x wheel sensors and 8 x ultrasonic sensors) enable optimal vacuuming performance through
automatic operation and obstacle detection
Robotic Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Continuous Use
Approx. 200 min (with BL1850B x 2)
Maximum Cleaning Area
5382
sq.ft.(500 m
2
) (with BL1850B x 2)
Running Mode
Random / Pattern
Dust Box Capacity
2.5 L
Dimensions (L x W x H)
18-1/8˝ x 18-1/8˝ x 7-1/8˝
(460 mm x 460 mm x 180 mm)
Net Weight
14.6 lbs (6.6 kg)
DRC200Z
High / Low Suction Control
Makita’s
Intelligent
Robotic
Cleaner
Makita offers a wide variety of
ACCESSORIES!
DRC200Z
For
ACCESSORIES
see pages 28 & 51
For
ACCESSORIES
see pages 28 & 51
HEPA
filter
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
HEPAFilterAssembly (123636-9), Hose Complete 28-1.5M (A-34235), Hose Band
(166116-2), Paper Filter Bag Set (197902-0), Front Cuff 22 (417765-1), Front Cuff 24 (195546-0), Backpack Shoulder Harness (161479-1)
Makita's FIRST Backpack Style Vacuum Cleaner
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing
18V Li-Ion battery platform
• Brushless DC motor with high power to weight
and size ratio
• Standard equipment HEPA filter offers 99.97%
efficiency greater than or equal to 3 microns
• Backpack design offers
unparalleled maneuverability
and versatility
Backpack Vacuum Cleaner
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Maximum Air Flow 53 CFM (1.5 m
3
/min)
Maxiumum Sealed Suction
7.1 kPa (710 mm H
2
O)
Maximum Bag Capacity
2.0 L
Suction Power (high mode)
45 W
Overall Dimensions (L x W x H) (no battery)
9˝ x 6˝ x 14-3/4˝
(230 mm x 152 mm x 373 mm)
Net Weight
6.9 lbs (3.1 kg)
DVC260ZX
High / Low Suction Control
For
ACCESSORIES
see pages 28 & 51
HEPA
filter
HEPA
filter
