STANDARD EQUIPMENT INCLUDES:
DHR263PF2: Two 18V (3.0Ah) Li-Ion Batteries BL1830B (194205-3), Dual Port Rapid Charger (DC18RD), Battery Cover (450128-8),
Side Handle (158057-6), Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (324219-0),Tool Bag (831278-2)
DHR263Z: Tool Only. Batteries and Charger Sold Separately.Side Handle(158057-6), Cleaning Cloth (443122-7),
Bit Grease (194683-7), Depth Gauge (324219-0)
Makita's FIRST 18Vx2 Direct 1˝ Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-Ion battery platform
• Center of gravity located close to rear handle resulting in ideal tool balance during operation
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• 40 angle bit positions enable chisels to be positioned at optimum angle of operation
• Rubber housing bumper protects mode selector
switch and gear housing from damage
• LED job light with afterglow feature
• One touch sliding chuck enables quick
and easy bit changes
1˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Capacities:
Concrete 1˝ (26 mm)
Steel 1/2˝ (13 mm)
Wood 1-1/4˝ (32 mm)
No Load Speed 0 - 1,250 RPM
Blows Per Minute 0 - 5,000 BPM
Impact Energy 2.5 J (1.8 ft. lbs)
Overall Length 13-3/4˝ (363 mm)
Net Weight 7.5 lbs (3.4 kg)
DHR263PF2
Variable
Speed,
Reversible
Makita's FIRST 18Vx2 7-1/4˝ Circular Saw!
• Offers the power of electric saws with the convenience and versatility of cordless saws!
• Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
• Large lock-off safety lever prevents accidental start up
• High performance and lightweight design with magnesium blade case and base plate
• Blower feature keeps cutting line free of sawdust
• Bevel capacity of 50° with positive stop at 45°
7-1/4˝ Circular Saw
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Blade Diameter 7-1/4˝ (185 mm)
Arbor 5/8˝ (15.88 mm)
Maximum Cutting Depth:
0° 2-5/8˝ (66 mm)
45° 1-7/8˝ (47.5 mm)
50° 1-11/16˝ (42.5 mm)
No Load Speed 4,800 RPM
Overall Length 14˝ (356 mm)
Net Weight 7.5 lbs (3.4 kg)
DHS711Z DHS711PF2
STANDARD EQUIPMENT INCLUDES:
DHS711PF2: Two 18V (3.0Ah) Li-Ion Batteries BL1830B (194205-3), Dual Port Rapid Charger (DC18RD), Battery Cover (450128-8),
7-1/4˝ C.T. Blade 24T(1 Ea.A-94530-10), Hex Wrench 5 (783217-7), Guide Rule (164095-8),Tool Bag (831278-2)
DHS711Z: Tool Only. Batteries and Charger Sold Separately.7-1/4˝ C.T. Blade 24T(1 Ea.A-94530-10), Hex Wrench (783217-7),
Guide Rule (164095-8)
DHR263Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (324219-0), Quick Change Drill Chuck (194079-2)
Makita's FIRST 18Vx2 Direct
1˝ Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
Features Quick Change Drill Chuck
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-Ion battery platform
• Center of gravity located close to rear handle resulting in ideal tool balance during operation
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• 40 angle bit positions enable chisels to be positioned at optimum angle of operation
• Rubber housing bumper protects mode selector switch and gear housing from damage
• LED job light with afterglow feature
• One touch sliding chuck enables quick and
easy bit changes
1˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Capacities:
Concrete 1˝ (26 mm)
Steel 1/2˝ (13 mm)
Wood 1-1/4˝ (32 mm)
No Load Speed 0 - 1,250 RPM
Blows Per Minute 0 - 5,000 BPM
Impact Energy 2.5 J (1.8 ft. lbs)
Overall Length 14-3/4˝ (374 mm)
Net Weight 7.7 lbs (3.5 kg)
DHR264Z
Variable
Speed,
Reversible
Quick Change Drill Chuck
194079-2
Cordless Power Tools
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
ManufacturingAnd Assembly
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Blade Set (194068-7)
Makita's FIRST 18Vx2 Brushless Reciprocating Saw!
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing
18V Li-Ion battery platform
• Brushless DC motor generates less heat buildup and is ideal for use in prolonged manufacturing and
production applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, dirt and debris for optimal
performance in extreme conditions
• Retractable Sky Hook allows tool to be hung on rafters, pipes or scaffolding
• 2 speed settings provides ideal settings for wood or metal cutting applications
Reciprocating Saw
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Maximum Cutting Capacities:
Pipe 5-1/8˝ (130 mm)
Wood (11-3/4˝ blade) 10˝ (255 mm)
Strokes Per Minute:
High 0 - 3,000 SPM
Low 0 - 2,300 SPM
Length of Stroke 1-1/4˝ (32 mm)
Overall Length 17-3/4˝ (449 mm)
Net Weight 6.2 lbs (2.8 kg)
DJR360Z
Toolless Blade Change,
Variable 2-Speed
DLS714Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. 7-1/2˝ C.T. Blade 40T(A-90629), Dust Bag (122852-0), Hex Wrench 5 (783203-8),
Triangle Rule (762001-3), Vertical Vice (122571-8), 2 Ea. Holders (322312-4)
Up To 11-1/34" Cuts In 2x Material
• Brushless DC motor with high power to weight and size ratio
• Automatic Torque Drive TechnologyTM (ADT) adjusts motor speed and torque during
heavy-duty cutting applications for maximum jobsite efficiency and performance
• Dual sliding rail mechanism incorporating 4 linear ball bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Soft start feature gradually increases speed to eliminate start up shock
• 2 stage safety switch prevents accidental startup for increased operator safety
• Mitre capacity of 47° left or 57° right with positive stops at 0°, 15°, 22.5°, 30° & 45°
• Bevel capacity of 45° left or 5° right
7-1/2˝ Dual Sliding Compound Mitre Saw
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Blade Diameter 7-1/2˝ (190 mm)
Arbor 5/8˝ (15.9 mm)
No Load Speed 5,700 RPM
Overall Length 25-3/4˝ (655 mm)
Net Weight 26.3 lbs (11.9 kg)
Soft Start, Electric Brake
When QUALITY & SERVICE Counts – Choose Makita
For ACCESSORIES see pages 70 - 71
For ACCESSORIES see pages 99 - 101
For ACCESSORIES see pages 99 - 101
For ACCESSORIES see pages 52 & 69
DJR360Z
Cutting Capacity
of 2-5/8" (66 mm)
Power tools featuring Makita’s 18Vx2 Direct Connect System technology
use Two 18V Li-Ion Batteries directly without a battery converter!
