11 / 180
HRU01ZX2
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
Bump & FeedTrimmer Head (195961-8), Protective Guard (195959-5),
Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7),Accessory Bag (831304-7), Direct Connect Battery Converter
Low Noise Level And Zero Emissions
• Brushless DC Motor with high power to weight and size ratio
• Battery Power Warning light indicates approximate remaining battery power
• Motor Indicator Warning Light indicates current limiter has been activated
• Current Limiter prevents motor burnout caused by overheating
• Electric Brake for increased operator safety
• 11-3/4˝ Cutting Path (using standard equipment string
trimmer head)
• Includes BCV02 18V to 36V Li-Ion
Battery Converter enabling use with
2 x 18V Li-Ion BL1830 Batteries
11-3/4˝ Curved Shaft Line Trimmer
Electric Brake,
Variable Speed,
Reversible
SPECIFICATIONS
Battery Capacities:
36V (2.6 Ah) Li-Ion
Two 18V (3.0 Ah) Li-Ion
Cutting Width
11-3/4˝ (300 mm)
No Load Speed:
High
0 - 7,000 RPM
Low
0 - 5,100 RPM
Dimensions (L x W x H)
67-3/4˝ x 11-5/8˝ x 16-1/2˝
(172 cm x 29 cm x 42 cm)
Net Weight
8.4 lbs (3.8 kg)
makita.ca11
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Cordless
Power Tools
When
QUALITY & SERVICE
Counts – Choose Makita
DUB361Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shoulder Harness (166095-4), Long Nozzle (452123-4)
More Power From Makita's 18Vx2 Battery Platform
• eXtreme Protection Technology (XPT) offers maximum protection against dust,
debris and liquids for
• Optimal performance in extreme conditions
• Battery capacity warning light indicates ideal
time to recharge battery
• Low noise level suitable for use in residential
areas and public spaces
• Push button air volume selection
(low / high settings)
• Long blowing nozzle with curved tip
for optimal blowing performance
• Shoulder belt for operator
convenience
Blower
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Maximum Air Volume:
High
155 CFM (4.4 m
3
/min)
Low
92 CFM (2.6 m
3
/min)
Maximum Air Velocity:
High
208 MPH (93 m/sec)
Low
128 MPH (57 m/sec)
No Load Speed:
High
17,000 RPM
Low
10,000 RPM
Overall Length
35-5/8˝ (90 cm)
Net Weight
4.2 lbs (1.9 kg)
DUR364LZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Bump and FeedTrimmer HeadAssy (197297-1), Safety Goggles (195246-2), Hex Wrench 5 (783217-7), Hex Wrench 4 (783202-0),
Accessory Bag (831304-7), Protector (455622-5)
Powerful Trimming For Where Low Noise Is A Concern
• Brushless motor is located on the trimmer head end to provide ultimate torque for trimming
• XPT (eXtreme Protection Technology) is provided to protect the unit under wet and
dirty conditions for the longest life
• Electronic current limiter for overload protection
• Dual battery fuel gauges for batteries state of charge at a glance
• Soft start feature for added motor protection
• Brushless motor with electronic 2 speed selection
• Reverse switch for easy removal of stuck grass clippings
in the trimmer head
14˝ Line Trimmer
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Cutting Width
13-3/4˝ (350 mm)
No Load Speed:
Low
5,000 RPM
High
6,500 RPM
Overall Length
69˝ (175 cm)
Net Weight
8.6 lbs (3.9 kg)
DUC302Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
12˝ Chain (196740-7), 12˝ Guide Bar (165245-8), Chain Cover (419288-5), Spike Bumper Set (197819-7)
Makita's FIRST 18Vx2 Direct Chainsaw! Ideal For
Cutting Firewood Or Brush, Pruning Applications And More!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris
and liquids for optimal performance in extreme conditions
• Battery capacity warning light indicates ideal time to recharge battery
• Lock-off button prevents accidental startup
• Electric chain brake provides maximum operator safety if kickback occurs
• Tool-less chain tension adjustment for quick and easy adjustment on the jobsite
• Automatic chain oiler
12˝ Chainsaw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Guide Bar Length
12˝ (300 mm)
Chain Pitch / Gauge
3/8˝ / 0.043˝
Chain Speed
1,650 FPM (500 m/min)
Overall Length
22-3/4˝ (577 mm)
Net Weight
7.7 lbs (3.5 kg)
Electric Chain Brake
HKU01ZX2
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
Direct Connect Battery Converter
Lightweight Design with High Efficiency, Zero Emissions
and Low Noise Level
• Zero Emissions and Low Noise Level ideal for use in sensitive work environments,
including residential areas and more
• Adjustable 3-Stage Handle enables positioning at optimal angle of operation or for more compact
storage when not in use
• Battery Capacity Warning Light
indicates approximate remaining
battery power for each battery
• Transport Wheels enable easy
movement around the work site
and can be folded upright
when not in use
13-3/4˝ Cultivator
SPECIFICATIONS
Battery Capacities:
36V (2.6 Ah) Li-Ion
Two 18V (3.0 Ah) Li-Ion
No Load Speed:
Tine Axle Speed
85 RPM
Motor Speed
4,100 RPM
Cultivating Width
13-3/4˝ / 8-7/8˝ (350 / 225 mm)
Tine Diameter
9-5/8˝ (245 mm)
Transmission Speeds
1-Forward
Dimensions (L x W x H)
47˝x 19-1/4˝x 39-1/4˝
(119 cm x 49 cm x 100 cm)
Net Weight
48.5 lbs (22.2 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly Set (196689-1), Blade Cover (450490-1)
Reduced Noise And Emissions Versus
Competitive Gas Models
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing
18V Li-Ion battery platform
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Electric brake stops blade 3-5 seconds after trigger is
released for increased operator safety
• Battery capacity warning light indicates
approximate remaining battery power
• 5 position rotating rear handle with
positive stops at 0
°
, 45
°
and 90
°
enables optimal positioning when
cutting vertical or angled hedges
25-1/2˝ Hedge Trimmer
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Strokes Per Minute (min-1)
1,000 - 1,800 SPM
Cutting Width
25-1/2˝ (650 mm)
Maximum Cutting Thickness
11/16˝ (18 mm)
Overall Length
48-1/2˝ (123 cm)
Net Weight
8.9 lbs (4.0 kg)
DUH651Z
Dual Blade Action
For
ACCESSORIES
see page 167
For
ACCESSORIES
see pages 161 - 162
For
ACCESSORIES
see page 167
