33 / 180
Cordless
Power Tools
makita.ca33
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
TD110DSYE
STANDARD EQUIPMENT INCLUDES:
TD110DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
TD110DZ:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• LED job light with pre-glow and after-glow feature illuminates work area
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Variable Speed,
Reversible
1/4˝ Hex Impact Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank
1/4˝ (6.3 mm)
No Load Speed
0 - 2,600 RPM
Impacts Per Minute
0 - 3,500 IPM
Maximum Torque 970 in. lbs (110 Nm)
Overall Length
6˝ (153 mm)
Net Weight
2.3 lbs (1.0 kg)
TD110DZ
HS301DSYE
STANDARD EQUIPMENT INCLUDES:
HS301DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
3-3/8˝C.T. Blade 20CT (A-95021), Hex Wrench 4 (783202-0), Plastic Carrying Case (821663-7)
HS301DZ:
Tool Only. Batteries and Charger Sold Separately.
3-3/8˝C.T. Blade 20CT (A-95021), Hex Wrench 4 (783202-0)
Compact eXtreme Technology (CXT)
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and
overall battery life
• Blower feature keeps cutting line free
of sawdust
• Bevel capacity 0º - 45º
3-3/8˝ Circular Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Blade Diameter
3-3/8˝ (85 mm)
Arbor
9/16˝ (15 mm)
Maximum Cutting Capacities:
0º
1˝ (25.5 mm)
45º
5/8˝ (16.5 mm)
No Load Speed
1,500 RPM
Overall Length
12-3/8˝ (313 mm)
Net Weight
3.5 lbs (1.6 kg)
HS301DZ
CC301DSYE
STANDARD EQUIPMENT INCLUDES:
CC301DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Diamond Wheel (A-95722),
Hex Wrench 4 (783202-0)
CC301DZ:
Tool Only. Batteries and Charger Sold Separately.
Diamond Wheel (A-95722), Hex Wrench 4 (783202-0)
Compact eXtreme Technology (CXT)
Specifically Designed For Cutting Glass and Ceramic Tile
• Battery protection system shuts tool off when overloaded or when
battery capacity is low
• Water supply tank (500 ml) features large cap for quick and easy refilling
• Bevel capacity of 45º
3-3/8˝ Glass & Tile Circular Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Blade Diameter
3-3/8˝ (85 mm)
Arbor
9/16˝ (15 mm)
Maximum Cutting Depth:
0°
1˝ (25.5 mm)
45°
5/8˝ (16.5 mm)
No Load Speed
1,600 RPM
Overall Length
12-3/8˝ (313 mm)
Net Weight
4.0 lbs (1.8 kg)
CC301DZ
JV101DSYE
STANDARD EQUIPMENT INCLUDES:
JV101DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Blade (1 Ea. 792529-7), Hex Wrench 3 (783201-2), Guide Rule (192732-4), Plastic Carrying Case (821691-2)
JV101DZ:
Tool Only. Batteries and Charger Sold Separately.
Blade (1 Ea. 792529-7), Hex Wrench 3 (783201-2)
Compact eXtreme Technology (CXT)
• 3 orbital settings enable operator to obtain a more aggressive cut
• Blower feature keeps cutting line free of saw dust
• Bevel capacity 0º - 45º
• Adapts quickly and easily to Makita Dust Extractors
Variable Speed
Jig Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Depth:
Mild Steel
1/16˝ (2 mm)
Wood
2-9/16˝ (65 mm)
Stroke Per Minute
0- 2,900 SPM
Length of Stroke
11/16˝ (18 mm)
Overall Length
9-1/8˝ (232 mm)
Net Weight
3.8 lbs (1.7 kg)
JV101DZ
When
QUALITY & SERVICE
Counts – Choose Makita
TM30DZKX4
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Abrasive Paper 60G (2 Ea. B-21565),Abrasive Paper 120G (2 Ea. B-21593),
Abrasive Paper 240G (2 Ea. B-22931), 1-1/8" Plunge Saw Blade (B-21353), Sanding Pad (B-21537), Hex Wrench 5 (783233-9),
AccessoryTool Box (143308-0), Plastic Carrying Case (821608-5)
Compact eXtreme Technology (CXT)
• Accepts standard Oscillating Interface System (OIS) accessories
• Soft start feature gradually increases speed to eliminate start up shock
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• LED job light illuminates work area
Variable Speed,
Soft Start,
Anti-Restart Feature
Multi Tool
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Oscillations Per Minute
6,000 - 20,000 OPM
Oscillation Angle
3.2º total
Circumference
6-5/8˝ (168 mm)
Overall Length
10-7/8˝ (277 mm)
Net Weight
3.1 lbs (1.4 kg)
For
ACCESSORIES
see pages 74 - 75
For
ACCESSORIES
see pages 72 - 73
JR103DSYE
STANDARD EQUIPMENT INCLUDES:
JR103DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
Slide Charger (DC10SB), Battery Cover (456128-6),
Reciprocating Saw Blade (1 Ea. B-20432, 1 Ea. 723063-A-5), Hex Wrench 3 (783201-3), Plastic Carrying Case (821662-9)
JR103DZ:
Tool Only. Batteries and Charger Sold Separately.
1 Ea. Reciprocating Saw Blade (B-20432, 723063-A-5),
Hex Wrench 3 (783201-3)
Compact eXtreme Technology (CXT)
• Multi-position switch (tool handle and tool body) with lock-off levers for easier operation, maximum
versatility and operator safety
• One-handed, fast toolless blade changes
• Battery protection system provides
over-discharge, temperature and
circuit protection for enhanced
performance, battery cycle
life and overall battery life
• LED job light with
pre-glow and
after-glow
feature
illuminates
work area
Reciprocating Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Capacities:
Wood
2˝ (50 mm)
Pipe
2˝ (50 mm)
Length of Stroke
1/2˝ (13 mm)
Strokes Per Minute
0 - 3,300 SPM
Overall Length
14-3/4˝ (376 mm)
Net Weight
2.9 lbs (1.3 kg)
JR103DZ
For
ACCESSORIES
see pages 70 - 71
