General Catalogue

HR2651

HAMMERS

makita.ca

124

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

POWER

Makita’s

Efficient

Hammering

Competitor’s

Inefficient

Hammering

Synchronized RPM and BPM creates

up to 50% more efficient drilling

*Only For Makita Electric Rotary Hammers featuring

ANTI-VIBRATION TECHNOLOGY

STANDARD EQUIPMENT INCLUDES:

HR2631F:

Side Handle (122878-2), Depth Gauge (331886-4), Plastic Carrying Case (824913-9)

HR2631FT:

Side Handle (122878-2), Depth Gauge (331886-4), Quick Change Drill Chuck (194079-2), Plastic Carrying Case (824915-5)

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

• Anti-Vibration Technology

(AVT

) actively

counteracts vibration of tool for greatly reduced

transmission to operator

• Torque limiter stops bit rotation if bit jams for

increased operator safety and enhanced

tool protection

1" Rotary Hammers

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum Capacities:

Concrete

1" (26 mm)

Steel

1/2" (13 mm)

Wood

1-1/4" (32 mm)

No Load Speed

0 - 1,200 RPM

Blows Per Minute

0 - 4,600 BPM

Impact Energy

2.9 J (2.1 ft. lbs)

AMPS (120V)

7.0 A

HR2631F:

Overall Length

14-1/4" (361 mm)

Net Weight 6.4 lbs (2.9 kg)

HR2631FT:

Overall Length

(with SDS-PLUS Chuck)

15-1/8" (385 mm)

Net Weight 6.8 lbs (3.1 kg)

HR2631F

HR2631FT

Variable Speed

STANDARD EQUIPMENT INCLUDES:

Side Handle (122878-2), Depth Gauge (331886-4), Plastic Carrying Case (824695-3)

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

• Anti-Vibration Technology

(AVT

) actively counteracts vibration of tool for greatly reduced

transmission to operator

• Torque limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• High durability design with zig-zag armature varnish, enhanced sealing, improved impact bolt and

impact reducing cushion ring

• Retractable sky hook allows tool to be hung on rafters, pipes or scaffolding

• Improved bit guide for increased bit stability during drilling applications

• Re-located operating mode lever for increased protection and durability

Variable Speed,

Reversible

1" Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum Capacities:

Concrete

1" (26 mm)

Steel

1/2" (13 mm)

Wood

1-1/4" (32 mm)

No Load Speed

0 - 1,100 RPM

Blows Per Minute

0 - 4,500 BPM

Impact Energy

2.9 J (2.1 ft. lbs)

AMPS (120V)

8.0 A

Overall Length 16-5/8" (422 mm)

Net Weight

6.8 lbs (3.1 kg)

HR2641

STANDARD EQUIPMENT INCLUDES:

Side Handle (158057-6) Depth Gauge (324219-0), Five Sealing Caps (424474-5), Dust Collector (127190-5), Plastic Carrying Case (821778-0)

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

• Integrated dust extraction system with HEPA filter captures harmful silica dust at point of origin for

virtually dust-free operation and reduced harm to workers

• Ideal for use in dust sensitive environments, e.g. hospitals, healthcare facilities, offices, facilities,

institutions and more!

• HEPA filter offers 99.75% efficiency

• Dust filter cleaning dial removes excess dust from filter, maintaining vacuum efficiency and performance

• Anti-Vibration Technology

(AVT

) system incorporates an active dynamic vibration absorbing

counterbalance spring to actively counteract the vibration of the tool for greatly reduced transmission

to the operator

1" Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum capacities:

Concrete

1" (26 mm)

Steel

1/2" (13 mm)

Wood

1-1/4" (32 mm)

No Load Speed

0 - 1,100 RPM

Blows Per Minute

0 - 4,500 BPM

Impact Energy

2.9 J (2.1 ft. lbs)

AMPS (120V)

8.0 A

Overall Length

26-1/4" (666 mm)

Net Weight

10.0 lbs (4.6 kg)

HR2663

Variable

Speed,

Reversible

STANDARD EQUIPMENT INCLUDES:

Side Handle (158057-6) Depth Gauge (324219-0), Five Sealing Caps (424474-5), Dust Collector (136018-6), Plastic Carrying Case (821722-7)

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

• Integrated dust extraction system with HEPA filter captures harmful silica dust at point of origin for

virtually dust-free operation and reduced harm to workers

• Ideal for use in dust sensitive environments, e.g. hospitals, healthcare facilities, offices, facilities,

institutions and more!

• HEPA filter offers 99.75% efficiency

• Anti-Vibration Technology

(AVT

) system incorporates an active dynamic vibration absorbing

counterbalance spring to actively counteract the vibration of the tool for greatly reduced transmission

to the operator

1" Rotary Hammer

SPECIFICATIONS

Bit Type

SDS-PLUS

Maximum capacities:

Concrete

1" (26 mm)

Steel

1/2" (13 mm)

Wood

1-1/4" (32 mm)

No Load Speed

0 - 1,200 RPM

Blows Per Minute

0 - 4,600 BPM

Impact Energy

2.9 J (2.1 ft. lbs)

AMPS (120V)

7.0 A

Overall Length

23-3/4" (666 mm)

Net Weight

11.5 lbs (5.2 kg)

HR2651

Variable

Speed,

Reversible

Integrated Dust

Extraction System

with HEPA Filter
