Electric Power Tools
125
STANDARD EQUIPMENT INCLUDES:
1/2" Drill Chuck (192877-8), Chuck Key (763432-9), Side Handle (122428-3), Depth Gauge (321059-7), Plastic Carrying Case (824608-4)
Makita’s Most Popular 3/4˝ Hammer Drill
Hammer & Rotation / Rotation Only
• Industrial Aluminum Gear Housing for durability
• 1/2" Chuck will accept 3/4" concrete bits with 1/2" reduced shank
• Depth Setting Rod for easier drilling of accurate hole depths
• 360° Swivel Side Handle
Variable 2-Speed, Reversible
3/4" Hammer Drill
SPECIFICATIONS
Maximum Capacities:
Concrete 3/4" (20 mm)
Steel 1/2" (13 mm)
Wood 1-1/2" (40 mm)
No Load Speed:
Low 0 - 900 RPM
High 0 - 2,300 RPM
Blows Per Minute:
Low 0 - 18,000 BPM
High 0 - 46,000 BPM
AMPS (120V) 6.0 A
Overall Length 13-3/4" (350 mm)
Net Weight 6.4 lbs (2.9 kg)
HP2010N
STANDARD EQUIPMENT INCLUDES:
Dust Bag (122708-7), Dust Cap (421727-3), Side Handle (135302-6), Plastic Carrying Case (824729-2) (Shown with Optional Bit)
SDS-Plus Shank, Built-In Dust Collection System
Hammer & Rotation / Hammer Only / Rotation Only
• Dust Collection System especially suited for operation in Hospitals, Schools and other job sites
where dust collection is mandatory
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
• Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation
Variable Speed, Reversible,
With Dust Collector
1" Rotary Hammer
SPECIFICATIONS
Bit Type SDS-PLUS
Maximum Capacities:
Concrete 1" (25 mm)
Steel 1/2" (13 mm)
Wood 1-1/4" (32 mm)
No Load Speed 0 - 1,000 RPM
Blows Per Minute 0 - 4,500 BPM
Impact Energy 2.2 J (1.6 ft. lbs)
AMPS (120V) 6.7 A
Overall Length 16" (407 mm)
Net Weight 7.1 lbs (3.2 kg)
HR2432
STANDARD EQUIPMENT INCLUDES:
NozzleAssembly (123245-4), Dust BagAssembly (123241-2)
• Double sided impeller and enlarged blower outlet provides increased air volume for maximum
performance and efficiency
• Self standing design allows tool to stand upright for use in stationary applications
• Top and rear handle design enables comfortable positioning for optimal jobsite maneuverability
• Converts quickly and easily between blower and vacuum modes
• Variable speed trigger and dial enables operator to adjust blower or suction speed based
on the material or application
• Lock-on button for operator convenience during periods of prolonged use
• Ergonomic soft rubber grip design
for comfortable operation
Anti-Static Design
Blower / Vacuum
SPECIFICATIONS
Max. Air Volume 145 CFM (4.1 m3/min)
Max. Air Velocity 203 MPH (91 m/sec)
No Load Speed 0 - 16,000 RPM
AMPS (120V) 6.8 A
Overall Length 18 -7/8" (479 mm)
Net Weight 4.3 lbs (2.0 kg)
UB1103
Optional Long Nozzle with
Curved End available
(Part No. 196729-5)
STANDARD EQUIPMENT INCLUDES:
Side Handle (158057-6), Depth Gauge (415486-9), Plastic Carrying Case (824650-5)
SDS-PLUS Shank, Up To 46% REDUCED VIBRATION!
Hammer & Rotation / Rotation Only
• Anti-Vibration Technology (AVTTM ) system incorporates an active dynamic vibration absorbing
counterbalance spring and a vibration absorbing handle to actively counteract the vibration of the tool
for greatly reduced transmission to the operator
• Torque limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Variable speed trigger allows operator to adjust speed based on materials or application
• Reverse rotation system using brush holder unit provides the same amount of power in forward and
reverse and extends life of carbon brushes
• 2 operating modes: Rotation / Rotation + Hammer
• One-touch SDS-PLUS sliding chuck for easy bit
installation and removal
Variable Speed, Reversible
11/16" Rotary Hammer
SPECIFICATIONS
Bit Type SDS-PLUS
Maximum Capacities:
Concrete 11/16" (18 mm)
Steel 1/2" (13 mm)
Wood 15/16" (24 mm)
No Load Speed 0 – 2,100 RPM
Blows Per Minute 0 – 4,800 BPM
Impact Energy 1.4 J (1.0 ft. lbs)
AMPS (120V) 4.1 A
Overall Length 11-1/4" (285 mm)
Net Weight 5.4 lbs (2.5 kg)
HR1841F
STANDARD EQUIPMENT INCLUDES:
Side Handle (158057-6), Depth Gauge (324219-0), Plastic Carrying Case (824799-1)
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• High Durability design with Zig-Zag Armature Varnish, Enhanced Sealing, Improved Impact Bolt and
Impact Reducing Cushion Ring
• Reverse Rotation System using Brush Holder Unit provides the same amount of power in forward and
reverse and extends life of carbon brushes
• Rubber Housing Bumper protects mode selector switch and gear housing from damage
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• One-Touch Sliding Chuck for easy bit installation and removal
• LED Light illuminates drilling position
Variable Speed,
Reversible
15/16" Rotary Hammer
SPECIFICATIONS
Bit Type SDS-PLUS
Maximum Capacities:
Concrete 15/16" (24 mm)
Steel 1/2" (13 mm)
Wood 1-1/4" (32 mm)
No Load Speed 0 – 1,100 RPM
Blows Per Minute 0 – 4,500 BPM
Impact Energy 2.7 J (1.99 ft. lbs)
AMPS (120V) 6.7 A
Overall Length 14-1/2" (370 mm)
Net Weight 6.4 lbs (2.9 kg)
HR2470F
STANDARD EQUIPMENT INCLUDES:
Side Handle (158057-6), Depth Gauge (415486-9), Plastic Carrying Case (821706-5)
SDS-PLUS Shank
Hammer & Rotation / Rotation Only
• Torque limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Variable speed trigger allows operator to adjust speed based on materials or application
• Reverse rotation system using brush holder unit provides the same amount of power in forward and
reverse and extends life of carbon brushes
• 2 operating modes: Rotation / Rotation + Hammer
• One-touch SDS-PLUS sliding chuck for easy bit installation and removal
• Ergonomic soft rubber grip for vibration absorption and
comfortable operation Variable Speed, Reversible
11/16" Rotary Hammer
SPECIFICATIONS
Bit Type SDS-PLUS
Maximum Capacities:
Concrete 11/16" (18 mm)
Steel 1/2" (13 mm)
Wood 15/16" (24 mm)
No Load Speed 0 – 2,100 RPM
Blows Per Minute 0 – 4,800 BPM
Impact Energy 1.4 J (1.0 ft. lbs)
AMPS (120V) 4.1 A
Overall Length 11-1/4" (285 mm)
Net Weight 5.3 lbs (2.4 kg)
HR1840
