DUR364LZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Bump and FeedTrimmer HeadAssembly (197297-1), Safety Goggles (195246-2), Hex Wrench 5 (783217-7), Hex Wrench 4 (783202-0),
Accessory Bag (831304-7), Protector (455622-5)
Powerful Trimming For Where Low Noise Is A Concern
• Brushless motor is located on the trimmer head end to provide ultimate torque
for trimming
• XPT (eXtreme Protection Technology) is provided to protect the unit under wet and
dirty conditions for the longest life
• Electronic current limiter for overload protection
• Dual Charge Level Indicators for batteries state of charge at a glance
• Soft start feature for added motor protection
• Brushless motor with electronic 2 speed selection
• Reverse switch for easy removal of stuck grass clippings
in the trimmer head
13-3/4" / 18Vx2 LXT Cordless Line Trimmer
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Cutting Width
13-3/4" (350 mm)
No Load Speed:
Low
5,000 RPM
High
6,500 RPM
Overall Length
69" (175 cm)
Net Weight
7.3 lbs (3.3 kg)
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
Trimmer Head (DA00000655), Protective Guard (DA00000630), Socket Wrench M5 (DA00000457),Tool Kit (DA00000458),
Spark Plug (965 603 021)
Compliant With EPA Phase 2, EU Stage 2 Exhaust Emissions Regulations
• Multi-positional engine
• Environment-friendly 2-stroke engine with catalytic exhaust
• Equipped with Easy Start system for faster,
easier starting
• Compact trimmer head cover for better view
of cutting area, without losing performance
of preventing grass clippings
to be scattered
• High power output to easily
trim the 16" cutting swath
15-3/4" / 25.7cc 2-Stroke Line Trimmer
SPECIFICATIONS
Cutting Width
15-3/4" (400 mm)
Displacement
25.7cc
Maximum Engine Power 0.83 Kw / 1.11 HP
Carburetor
Diaphragm Type
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
0.6L
Overall Length
64-3/4" (164 cm)
Dry Weight
9.5 lbs ( 4.3 kg)
ER2600L
Lightweight yet powerful
2-Stroke trimmer
STANDARD EQUIPMENT INCLUDES:
ProtectorAssembly (DA00000525), Protector (DA00000526),Trimmer Head (DA00000454), Shoulder Harness (DA00000456),
Socket Wrench M5 (DA00000457),Tool Kit (DA00000458), Spark Plug (965 603 021)
Compliant With EPA Phase 2, EU Stage 2 Exhaust Emissions Regulations
• Multi-positional engine
• Environment-friendly 2-stroke engine with
catalytic exhaust
• Wide trigger control and soft grip for
comfortable operation
• Primer bulb and choke for easy starting
• Durable nylon string trimmer head
17" / 25.7cc 2-Stroke Line Trimmer
SPECIFICATIONS
Cutting Width
17" (430 mm)
Displacement
25.7cc
Maximum Engine Power 0.83 Kw / 1.15 HP
Carburetor
Diaphragm Type
Ignition System
vRecoil
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
0.6L
Overall Length
69-3/4" (177 cm)
Dry Weight
10.8 lbs (4.9 kg)
EM2600L
Professional Use
EBH253L
STANDARD EQUIPMENT INCLUDES:
Trimmer HeadAssembly (123234-9), Protective Guard (452260-4),Trimmer Head Protective GuardAttachment (135753-3),
Box Wrench 16-17 (783013-3), Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7), Shoulder Harness (125516-5), Engine Oil Set,
Starter Rope (444020-8), Spark Plug (168534-0),Accessory Bag (831304-7)
Save The Cost Of The Trimmer With Fuel Savings Alone!
• Patented lubrication system enables Makita 4-Stroke Brushcutters & Line Trimmers to be
used on any angles and slopes
• Anti-vibration system for fatigue free use
• Clean exhaust emissions and lower fuel consumption
• 40% less fuel consumption compared to
2-stroke equivalent
Quiet, Low Vibration,
Extreme Fuel Cost Savings
16" / 24.5cc 4-Stroke Line Trimmer
SPECIFICATIONS
Cutting Width
16" (406 mm)
Displacement
24.5cc
Maximum Engine Power 0.71 Kw / 0.97 HP
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.5 L
Oil Tank Capacity
0.08 L
4-Stroke Crank Case Oil
10W-30
Overall Length
69-3/4" (177 cm)
Dry Weight
11.5 lbs ( 5.2 kg)
DUR365UZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Bump and FeedTrimmer HeadAssembly (197296-3), Protective Guard (197295-5),
Safety Goggles (195246-2), Shoulder Harness (125516-5), Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7),Accessory Bag (831304-7)
Powerful Trimming For Where Low Noise Is A Concern
• Brushless motor is located on the trimmer head end to provide
ultimate torque for trimming
• XPT (eXtreme Protection Technology) is provided to protect the
unit under wet and dirty conditions for the longest life
• Electronic current limiter for overload protection
• Dual LED charge level indicators display approximate
remaining battery power
• Soft start feature for added motor protection
• Brushless motor with electronic 3 speed selection
• Reverse switch for easy removal of stuck grass clippings
in the trimmer head
• Ergonomically designed bike handle for best
operator control
9" / 18Vx2 LXT Cordless Brush Cutter
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
No Load Speed 3,500 / 5,300 / 6,500 RPM
Cutting Width
13-3/4" (350 mm)
Overall Length
69" (175 cm)
Net Weight
8.9 lbs (4.0 kg)
Powered By Two 18V Li-Ion Batteries
ER2550LH
STANDARD EQUIPMENT INCLUDES:
CutterAssy (122980-1), Protective Guard (141511-7), Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2), Engine Oil Set,
Starter Rope (444019-3), Spark Plug (168534-0),Accessory Bag (831304-7)
Makita Mini 4-Stroke Series Curved Shaft Trimmer For Professional Use
• Professional series flexible shaft for maximum durability and minimum vibration
• Wide trigger control and soft grip for
comfortable operation
• Primer bulb and choke for easy starting
• Durable nylon string trimmer head
• Outstanding power to weight ratio
16-1/4" / 24.5cc 4-Stroke Line Trimmer
SPECIFICATIONS
Cutting Width
16-1/4" (412 mm)
Displacement
24.5cc
Maximum Engine Power 0.71 Kw / 0.97 HP
Carburetor
Diaphragm Type
Fuel / Oil Mixture
Not Required
Fuel Tank Capacity
0.5 L
Oil Tank Capacity
0.08 L
4-Stroke Crank Case Oil
10W-30
Overall Length
64" (163 cm)
Dry Weight
10.8 lbs (4.9 kg)
