DUR187LZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Bump & FeedTrimmer Head (198385-7), Shoulder Harness (125516-5),
Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7),Accessory Bag (831304-7), Protective Guard (457324-9)
Lightweight and Powerful with Low Noise Level suitable for use in
Residential Areas and Public Spaces
• Brushless DC Motor for Longer Life / Less Heat / More Run Time & More Work
• XPT (eXtreme Protection Technology) Prevent Debris & Liquids from entering the tool, Expands Tool
Usage to Harsh Environments and Provides Longer Tool Life
• Automatic torque Drive Technology (ADT) Adjusts Motor Speed and Torque during
heavy-Duty cutting for Maximum Efficiency and Performance
• Battery Protection System provides Over-Discharge, Temperature and
Circuit Protection for Enhanced Performance, and Overall Battery Life
11-3/4" / 18V LXT Cordless Line Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed 4,000 / 5,000 / 6,000 RPM
Cutting Width
11-3/4" (300 mm)
Overall Length
70-1/2" (179.1 cm)
Net Weight
6.0 lbs (2.8 kg)
Brushless / ADT / XPT
Battery Protection System
3 Speed,
Reversible
MAINTENANCE ACCESSORIES FORGAS POWERED
LINE TRIMMERS&BRUSHCUTTERS
Description For Engine No.
For Models
Contents Part No.
4-Stroke Engine
Maintenance Kit for
Line Trimmers &
Brush Cutters
EH025
EH035
EBH253L, EBH253U
EBH341L, EBH341U
ER2550LH
Air Filter x 2
Fuel Filter
Spark Plug
197678-9
Lubricating
Maintenance Grease
for Line Trimmers
& Brush Cutters
N 00
EBH253L, EBH253U
EBH341L, EBH341U
EM2600L, EM400MP
EM401MP, ER2550LH
ER2600L, ER400MP
80 g 197437-1
DUR181SF
STANDARD EQUIPMENT INCLUDES:
DUR181SF:
18V (3.0Ah) Li-Ion Battery
BL1830B (194205-3),
Standard Charger (DC18SD), Bump & Feed Spool Set (195858-1), Nylon Cord (195864-6),
Shoulder Harness (125516-5), Protective Guard (453353-0), Safety Goggles (195246-2)
DUR181Z:
Tool Only. Batteries and Charger Sold Separately.
Nylon Cord (195864-6),
Bump & Feed Spool Set (195858-1), Shoulder Harness (125516-5), Protective Guard
(453353-0), Safety Goggles (195246-2)
Well Balanced Design With Fully Adjustable Features To Suit Any Operator
• Adjustable Trimmer Head features 5 angled cutting positions for maximum versatility and ease
of operation when trimming around obstacles
• Telescopic Shaft adjusts quickly and easily to suit any operator
• Lock-Off Safety Lever prevents accidental start up
• Battery Capacity Warning Light indicates low
battery capacity
10-1/4" / 18V LXT Cordless Line Trimmer
vSPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed
7,800 RPM
Cutting Width
10-1/4" (260 mm)
Overall Length
56-1/2" (143 cm)
Net Weight
5.5 lbs (2.5 kg)
Replacement
Nylon
Cutting Line
195864-6 (49')
or 195861-2 (98')
180°
Trimmer Head rotates 180° to
enable easy edge trimming
DUR181Z
DUR189Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Bump & FeedTrimmer Head (198972-2), Shoulder Harness (125516-5),
Safety Goggles (195246-2), Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7), Protective Guard (456651-1),Accessory Bag (831304-7)
Lightweight and Powerful with Low Noise Level suitable for use in
Residential Areas and Public Spaces
• Telescoping curved shaft adjusts (60-1/2" - 64-1/2" length) for convenient operation in tight places
• Brushless DC Motor for Longer Life / Less Heat / More Run Time & More Work
• XPT (eXtreme Protection Technology) Prevent Debris & Liquids from entering the tool, Expands Tool
• Usage to Harsh Environments and Provides Longer Tool Life
• Automatic torque Drive Technology (ADT) Adjusts Motor Speed and Torque during
heavy-duty cutting for Maximum Efficiency and Performance
• Battery Protection System provides Over-Discharge,Temperature
and Circuit Protection for Enhanced Performance, and Overall
Battery Life
11-3/4" / 18V LXT Cordless Line Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed 4,000 / 5,000 / 6,000 RPM
Cutting Width
11-3/4" (300 mm)
Overall Length
63-1/2" (161 cm)
Net Weight
5.8 lbs (2.6 kg)
Brushless / ADT / XPT
Battery Protection System
3 Speed, Reversible, Telescoping curved
shaft adjusts (60-1/2" - 64-1/2" length)
UR100DZX
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Plastic Blade (198847-5), Plastic Blade Set (198850-6), Protective Guard (135950-1),
Shoulder Harness (125516-5), Hex Wrench 4 (783202-0), Safety Goggles (195246-2),Accessory Bag (831304-7)
9" / 12V LXT Cordless Nylon Blade Trimmer
Well Balanced Design With Adjustable Features To Suit Any Operator
• Adjustable front grip features 6 angled positions for maximum versatility and ease of operation when
trimming on slopes or while using as an edger
• Telescopic shaft adjusts quickly and easily to suit any operator (33-1/2" to 47-1/4")
• Standard equipped with 9" nylon blade cutting head
(optional nylon trimmer line head 10-1/4" available)
• Lock-off safety lever prevents accidental start up
• Battery capacity warning light indicates low battery capacity
• XPT (eXtreme Protection Technology) Prevent Debris &
Liquids from entering the tool, Expands Tool
Usage to Harsh Environments and Provides
Longer Tool Life
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
10,000 RPM
Cutting Width
9" (230 mm)
Overall Length
46-3/4" (118 cm)
Net Weight
4.3 lbs (1.73 kg)
DUR188LZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Bump & FeedTrimmer Head (198385-7), Protective Guard (457324-9),
Shoulder Harness (125516-5), Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7),Accessory Bag (831304-7)
Lightweight and Powerful with Low Noise Level suitable for use in Residential
Areas and Public Spaces. Split shaft for ease of storage and transporting.
• Brushless DC Motor for Longer Life / Less Heat / More Run Time & More Work
• XPT (eXtreme Protection Technology) Prevent Debris & Liquids from entering the tool, Expands Tool
Usage to Harsh Environments and Provides Longer Tool Life
• Automatic torque Drive Technology (ADT) Adjusts Motor Speed and Torque during heavy-Duty cutting for
Maximum Efficiency and Performance
• Battery Protection System provides Over-Discharge,Temperature and Circuit Protection for
Enhanced Performance, and Overall Battery Life
• Front Mounted Operator Controls for easy function changes during use
• Reverse Switch for Clearing Entangled Weeds and Grass
from Cutting Head
• Split shaft design for easier storage and transportation
11-3/4" / 18V LXT Cordless Split Shaft Line Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed 4,000 / 5,000 / 6,000 RPM
Cutting Width
11-3/4" (300 mm)
Overall Length
70-1/2" (179.1 cm)
Net Weight
6.7 lbs (3.0 kg)
3 Speed, Reversible
Brushless / ADT / XPT
Battery Protection System
197437-1
Service Gear
Assembly Every
30 Hours
197678-9
