209 / 220
OUTDOOR
Power Equipment
makita.ca
207
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY&SERVICE
Counts – ChooseMakita
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly Set (196689-1), Blade Cover (450490-1)
25-1/2" / 18Vx2 LXT Cordless Hedge Trimmer
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Strokes Per Minute (min-1)
1,000 - 1,800 SPM
Cutting Length
25-1/2" (650 mm)
Maximum Cutting Thickness
11/16˝ (18 mm)
Overall Length
48-1/2" (123 cm)
Net Weight
8.9 lbs (4.0 kg)
DUH651Z
STANDARD EQUIPMENT INCLUDES:
Two Shear Blades, Blade Cover (452327-8), End Cover Set (196969-5),
Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2), Starter Rope (444028-2), Spark Plug (0650109950)
5 Position Adjustable Rear Handle for
Vertical or Angle Trimming
• 23-1/8" Cutting Length with 3 Edge Tooth Design
and High Anti-Abrasion Coated Surface for
Stain Free Long Lasting Operation
• Double Sided Stainless Steel Blades for
Extended Life, Clean Trimming and Cutting
on Both Sides of Blade
• Extended 50 Hour Long Life Gear Case
Lubrication System offers Minimal Service
Maintenance by circulating grease in the
gear housing.
• 5 Position Adjustable Rear Handle for
Vertical or Angle Trimming
• Anti-vibration design for Less
Operator Fatigue
• Forward Facing Exhaust
redirects away from
the operator
23-1/8" / 22.2cc 2-Stroke Hedge Trimmer
SPECIFICATIONS
Displacement
22.2cc
Maximum Engine Power 0.68 kW / 0.91 HP
Cutting Length
23-1/8" (588 mm)
Carburetor
Diaphragm type
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
400 ml
Overall Length
44" (111 cm)
Net Weight
11.0 lbs (5.0 kg)
EH6000W
STANDARD EQUIPMENT INCLUDES:
Two Shear Blades, Blade Cover (454279-9), End Cover Set (196969-5),
Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2), Starter Rope (444028-2), Spark Plug (0650109950)
5 Position Adjustable Rear Handle for
Vertical or Angle Trimming
• 19" Cutting Length with 3 Edge Tooth Design
and High Anti-Abrasion Coated Surface for
Stain Free Long Lasting Operation
• Double Sided Stainless Steel Blades for
Extended Life, Clean Trimming and Cutting
on Both Sides of Blade
• Extended 50 Hour Long Life Gear Case
Lubrication System offers Minimal Service
Maintenance by circulating grease in the
gear housing.
• 5 Position Adjustable Rear Handle for
Vertical or Angle Trimming
• Anti-vibration design for Less
Operator Fatigue
• Forward Facing Exhaust
redirects away from
the operator
19" / 22.2cc 2-Stroke Hedge Trimmer
SPECIFICATIONS
Displacement
22.2cc
Maximum Engine Power 0.68 kW / 0.91 HP
Cutting Length
19" (483 mm)
Carburetor
Diaphragm type
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
400 ml
Overall Length
40" (101 cm)
Net Weight
10.5 lbs (4.8 kg)
EH5000W
Reduced Noise And Emissions Versus
Competitive Gas Models
• Accepts two 18V Li-Ion batteries without a battery converter for use with
existing 18V Li-Ion battery platform
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Electric brake stops blade 3-5 seconds after trigger is
released for increased operator safety
• Battery capacity warning light indicates
approximate remaining battery power
• 5 position rotating rear handle with
positive stops at 0°, 45° and 90°
enables optimal positioning when
cutting vertical or angled hedges
Dual Blade Action
DUH523SF
STANDARD EQUIPMENT INCLUDES:
DUH523SF:
18V (3.0Ah) Li-Ion Battery
BL1830B (194205-3), Standard Charger (DC18SD), Shear Blade Complete Set (195846-8),
Blade Cover (453723-3)
DUH523Z:
Tool Only. Batteries and Charger Sold Separately.
Blade Cover (453723-3), Shear Blade Complete Set (195846-8)
Designed for Maximum Versatility and Ease of Operation
• Battery Protection System provides Over-Discharge, Temperature and Current Protection
for enhanced performance, battery cycle life and overall battery life
• Anti-Vibration Structure features five cushions linking handle and motor sections for significantly
reduced vibration transmission to operator
• Non-Electrolyzed Nickel Plated Blades reduce
staining and rusting
• Tool-less Blade Changing System
enables simple and easy blade changes
• Ergonomic Soft Rubber Grip design for
vibration absorption and comfortable
operation
22" / 18V LXT Cordless Hedge Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Strokes Per Minute (min-1)
1,350 SPM
Cutting Length
22" (560 mm)
Maximum Cutting Thickness
15/32" (12 mm)
Overall Length
38" (96 cm)
Net Weight
6.0 lbs (2.7 kg)
Dual Blade Action
DUH523Z
STANDARD EQUIPMENT INCLUDES:
Cord Holder Complete Set (194677-2), Hook Complete Set (158024-1), Blade Cover (450490-1), Shear BladeAssembly Set (194669-1)
25-1/2" Electric Hedge Trimmer
SPECIFICATIONS
Cutting Length
25-1/2" (650 mm)
Strokes Per Minute
1,600 SPM
AMPS(120V)
4.8 A
Overall Length
40-1/2" (103 cm)
Net Weight
3.8 lbs (8.4 kg)
UH6570
Ergonomic Soft Rubber Grip For Vibration Absorption
And Comfortable Operation
Three switches are installed in handle, front grip and sub grip
• 2-hand operation switch–motor will run only when grips
are held with both hands
• Guard is provided at the tip of blades to
prevent kick-back
• Blades are coated particularly to improve durability
• Built in clutch for safety
• Easy blade replacement
• Powerful 550W Motor
• Protection of extension cord from breakage
Electric Brake
DUH602Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly Set (199101-0), Blade Cover (459121-9), Safety Goggles (195246-2)
Reduced Noise And Emissions Versus Competitive Gas Models
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Electric brake stops blade 3-5 seconds after trigger is released
for increased operator safety
• Battery capacity warning light indicates
approximate remaining battery power
• 5 position rotating rear handle with positive stops
at 0°, 45° and 90° enables optimal positioning
when cutting vertical or angled hedges
• 3 speed selection switch plus variable speed
trigger to tailor the tool to the trimming needs
• Reverse button function for freeing
the blade if it happens to jam
• Dual blade action cuts quickly
with shearing effect
23-5/8" / 18V LXT Cordless Hedge Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Strokes Per Minute (min-1)
0 - 2,000 / 0 - 3,600 / 0 - 4,400 SPM
Cutting Length
23-5/8" (600 mm)
Maximum Cutting Thickness
7/8" (21.5 mm)
Overall Length
43-3/4" (111.3 cm)
Net Weight
7.8 lbs (3.5 kg)
Dual Blade Action
