STANDARD EQUIPMENT INCLUDES:
Two Shear Blades, Blade Cover (454277-3), End Cover Set (196969-5),
Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2), Starter Rope (444028-2), Spark Plug (0650109950)
5 Position Adjustable Rear Handle for
Vertical or Angle Trimming
• 28-3/4" Cutting Length with 3 Edge Tooth Design
and High Anti-Abrasion Coated Surface for
Stain Free Long Lasting Operation
• Double Sided Stainless Steel Blades for
Extended Life, Clean Trimming and Cutting
on Both Sides of Blade
• Extended 50 Hour Long Life Gear Case
Lubrication System offers Minimal Service
Maintenance by circulating grease in the
gear housing.
• 5 Position Adjustable Rear Handle for
Vertical or Angle Trimming
• Anti-vibration design for Less
Operator Fatigue
• Forward Facing Exhaust
redirects away from
the operator
28-3/4" / 22.2cc 2-Stroke Hedge Trimmer
SPECIFICATIONS
Displacement
22.2cc
Maximum Engine Power 0.68 kW / 0.91 HP
Cutting Length
28-3/4" (728 mm)
Carburetor
Diaphragm type
Fuel / Oil Mixture
50:1
Fuel Tank Capacity
400 ml
Overall Length
49-1/2" (125 cm)
Net Weight
11.4 lbs (5.2 kg)
EH7500W
DUB183SF
STANDARD EQUIPMENT INCLUDES:
DUB183SF:
18V (3.0Ah) Li-Ion Battery
BL1830B (194205-3), Standard Charger (DC18SD), Long Nozzle (TP00000199)
DUB183Z:
Tool Only. Batteries and Charger Sold Separately.
Long Nozzle (TP00000199)
Unique Extended Nozzle Design for Optimum Operation
• Unique Extended Nozzle Design for Optimum Operation directs Air Flow Angle for Blowing / Sweeping
Debris, Grass Clipping, Leaves etc. from Driveway's, Sidewalks and more.
• Low / Medium / High Air Volume Settings with Variable Speed Control within Each Setting
• Ergonomic Soft Rubber Grip design for Vibration Absorption and Comfortable Operation
• Anti-static design to prevent buildup of Static Electricity
• Converts to Vacuum quickly and easily
• Light Weight Design for Reduced Operator Fatigue
Low / Medium / High
Air Volume Settings
18V LXT Cordless Blower / Vacuum
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Air Volume 92 CFM (2.6 m
3
/min)
Maximum Air Velocity 116 MPH (52 m/sec)
No Load Speed
0 - 18,000 RPM
Overall Length
33-1/4" (845 mm)
Net Weight
2.9 lbs (1.3 kg)
DUB183Z
DUB361Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shoulder Harness (166095-4), Long Nozzle (452123-4)
More power from Makita's 18Vx2 battery platform
• eXtreme Protection Technology (XPT) offers maximum protection against dust,
debris and liquids for
• Optimal performance in extreme conditions
• Battery capacity warning light indicates ideal
time to recharge battery
• Low noise level suitable for use in residential
areas and public spaces
• Push button air volume selection
(low / high settings)
• Long blowing nozzle with curved tip
for optimal blowing performance
• Shoulder belt for operator
convenience
18Vx2 LXT Cordless Blower / Vacuum
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Maximum Air Volume:
High
155 CFM (4.4 m
3
/min)
Low
92 CFM (2.6 m
3
/min)
Maximum Air Velocity:
High
208 MPH (93 m/sec)
Low
128 MPH (57 m/sec)
No Load Speed:
High
17,000 RPM
Low
10,000 RPM
Overall Length
35-5/8" (90 cm)
Net Weight
4.2 lbs (1.9 kg)
DUB182Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (132025-7), Dust Bag (122814-8)
Low / Medium / High Air Volume Settings
• Variable Speed Control within each speed setting
• Anti-Static Design to prevent buildup of static electricity
• Converts to Vacuum quickly and easily
• Ergonomic Soft Rubber Grip design for vibration
absorption and comfortable operation
18V LXT Cordless Blower / Vacuum
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Air Volume
92 CFM (2.6 m
3
/min)
Maximum Air Velocity
179 MPH (80 m/sec)
Maximum Air Pressure
5.4 kpa (550 mm H
2
O)
No Load Speed
0 - 18,000 RPM
Overall Length
20-3/4" (525 mm)
Net Weight
2.9 lbs (1.3 kg)
Variable Speed
Optional Long Nozzle
with Curved End
Sold Separately
(Part No.
TP00000199)
Makita offers a wide variety of
ACCESSORIES!
BLOWERACCESSORIES
Description
For Model No.
Part No.
16" Long Nozzle
DUB362
455915-0
11" Extension Nozzle
456957-7
11" Flat Nozzle
456958-5
12" Flat Nozzle
BHX2500CA
451753-8
21" Long Curved Nozzles
DUB361
452123-4
DUB182, DUB183
TP00000199
456957-7
TP00000199
456958-5
DUB362Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Front Nozzle (455914-2), Long Nozzle (455915-0)
Our Most Powerful Cordless Blower Yet!
Amazing 120 MPH and 473 CFM Operation
• Powered by two 18V Li-ion batteries in series to supply energy to the powerful 36V DC motor drive system
• 6-stage air volume/velocity settings by dial with variable speed control by trigger
• The trigger also has a lock on function, with button operable from either side of handle
• 3-stage telescopic long nozzle with adjustment range of 4" (100 mm)
• Dual LED charge level indicators display
approximate remaining battery power
• Best grip to frame angle provides optimum
nozzle to ground angle for efficient
sweeping operation
• Lightweight & compact for single
handed operation
• Longer run time thanks to
brushless motor
18Vx2 LXT Cordless Turbo Blower
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Max. Air Volume 473 CFM (13.4 m
3
/min)
Max. Air Velocity 120 MPH (54 m/sec)
No Load Speed
22,000 RPM
Overall Length 32-3/4", 34-3/4", 36-5/8"
(830 mm, 880 mm, 930 mm)
Net Weight
6.0 lbs (2.7 kg)
