37 / 220
18V LXT
Saws
makita.ca
35
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY&SERVICE
Counts – ChooseMakita
DSS611RFE
STANDARD EQUIPMENT INCLUDES:
DSS611RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
6-1/2" C.T. Saw Blade 16T (D-51063).), Hex Wrench 5 (783203-8), Guide Rule (164095-8), Plastic Carrying Case (141353-9)
DSS611Z:
Tool Only. Batteries and Charger Sold Separately.
6-1/2" C.T. Blade 16T (D-51063), Hex Wrench 5 (783203-8),
Guide Rule (164095-8)
• High Power Motor for maximum cutting efficiency
• Large Lock-Off Safety Lever prevents accidental start up
• Bevel Capacity of 50°
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
6-1/2" Circular Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
6-1/2" (165 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Depth:
0°
2-1/4" (57 mm)
45°
1-9/16" (40 mm)
50°
1-7/16" (36 mm)
No Load Speed
3,700 RPM
Overall Length
13-5/8" (347 mm)
Net Weight
6.8 lbs (3.1 kg)
DSS611Z
Cutting Capacity
Of 2-1/4" (57 mm)
DHS660ZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
6-1/2" C.T. Blade 24T (A-85092),
Guide Rule (164095-8), Dust Nozzle Set (199230-9)
SUB-COMPACT Size - PROFESSIONAL Power
• Ultra-Compact and lightweight design with high performance for heavy-duty cutting applications
• Brushless DC motor with high power to weight and size ratio
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load
condition, enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal
performance in extreme conditions
• Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
• Soft start feature gradually increases speed to eliminate start up shock
• Blower feature keeps cutting line free of sawdust
6-1/2" Sub-Compact Circular Saw
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Blade Diameter 6-1/2" (165 mm)
Arbor
5/8" (15.88 mm)
Maximum Cutting Depth:
0°
2-1/4" (57 mm)
45°
1-5/8" (41 mm)
50°
1-7/16" (37 mm)
No Load Speed
5,000 RPM
Overall Length 10-5/8" (270 mm)
Net Weight
5.6 lbs (2.5 kg)
Lock-Off Button,
Electric Brake, Soft
Start, Blower,
LED Light
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries
and Charger Sold Separately.
6-1/2" C.T. Blade 56T (B-57342),
Hex Wrench 5 (783203-8), Interlocking Case (197213-3)
6-1/2" Plunge Cut Circular Saw with AWS
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Blade Diameter
6-1/2" (165 mm)
Arbor
13/16" (20 mm)
Maximum Cutting Depth:
0°
2-3/16" (56 mm)
45°
1-9/16" (40 mm)
48°
1-1/2" (38 mm)
No Load Speed
2,500 - 6,300 RPM
Overall Length
13-5/8" (346 mm)
Net Weight
8.6 lbs (3.9 kg)
DSP601ZJ
Bluetooth
®
is a registered
trademark of Bluetooth
®
SIG
Auto-Start Wireless System (AWS) Technology Features
Wireless Dust Collection Technology!
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed
according to the load condition, enabling rapid movement between high speed and high torque applications
• Battery protection system provides over-discharge, temperature and current protection for enhanced
performance, battery cycle life and overall battery life
• High performance and lightweight design with magnesium diecast baseplate
• Constant speed control maintains constant speed under heavy load
• Overload protection prevents motor burnout due to current overload
• Depth stopper enables splinter free cutting
Automatic torque Drive
Technology (ADT),
Two-Stage Safety
Switch, Electric Brake,
Soft Start
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
5-3/8" C.T. Saw Blade 16T (A-94904), Hex Wrench 5 (783203-8), Guide Rule (164095-8)
Compact And Lightweight Design For High Maneuverability
• Blower feature keeps cutting line free of saw dust
• Electric Brake stops blade immediately for added safety
• High Power Motor for maximum cutting efficiency
• Large Lock-Off Safety Lever prevents accidental start up
• LED Job Light with Afterglow feature
• Stainless Steel Base Plate
• Bevel Capacity of 50°
Electric Brake, Blower, LED Light,
Cutting Capacity Of 2" (51 mm)
5-3/8" Circular Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
5-3/8" (136 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Depth:
0°
2" (51 mm)
45°
1-3/8" (35 mm)
No Load Speed
3,600 RPM
Overall Length
14-3/8" ( 364 mm)
Net Weight
6.0 lbs (2.7 kg)
DSS501Z
Makita's FIRST Cordless Plunge Cut Circular Saw!
• Brushless DC motor with high power to weight and size ratio
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed
according to the load condition, enabling rapid movement between high speed and high torque applications
• Battery protection system provides over-discharge, temperature and current protection for enhanced
performance, battery cycle life and overall battery life
• High performance and lightweight design with magnesium diecast baseplate
• Constant speed control maintains constant speed under heavy load
• Overload protection prevents motor
burnout due to
current overload
• Depth stopper enables
splinter free cutting
6-1/2" Plunge Cut Circular Saw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Blade Diameter
6-1/2" (165 mm)
Arbor
13/16" (20 mm)
Maximum Cutting Depth:
0°
2-3/16" (56 mm)
45°
1-9/16" (40 mm)
48°
1-1/2" (38 mm)
No Load Speed
2,500 - 6,300 RPM
Overall Length
13-5/8" (346 mm)
Net Weight
8.6 lbs (3.9 kg)
DSP600ZJ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
6-1/2" C.T. Blade 56T (B-57342), Hex Wrench 5 (783203-8),
Interlocking Case (197213-3)
Automatic torque Drive
Technology (ADT),
Two-Stage Safety
Switch, Electric Brake,
Soft Start
DHS661ZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
6-1/2" C.T. Blade 24T (A-85092), Guide Rule (164095-8), Dust Nozzle Set (199230-9)
SUB-COMPACT Size - PROFESSIONAL Power
• AWS (Auto-Start Wireless System) uses Bluetooth
®
technology to communicate between tool and vacuum
and enable wireless control when used with Makita AWS cordless tools
• Ultra-Compact and lightweight design with high performance for heavy-duty cutting applications
• Brushless DC motor with high power to weight and size ratio
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load
condition, enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum
protection against dust, debris and liquids for
optimal performance in extreme conditions
• Blower feature keeps cutting line free of sawdust
6-1/2" Sub-Compact Circular Saw with AWS
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Blade Diameter 6-1/2" (165 mm)
Arbor
5/8" (15.88 mm)
Maximum Cutting Depth:
0°
2-1/4" (57 mm)
45°
1-5/8" (41 mm)
50°
1-7/16" (37 mm)
No Load Speed
5,000 RPM
Overall Length 10-5/8" (270 mm)
Net Weight
5.6 lbs (2.5 kg)
Lock-Off Button,
Electric Brake, Soft
Start, Blower,
LED Light
Bluetooth
®
is a registered
trademark of Bluetooth
®
SIG
