General Catalogue

18V LXT

Saws

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

Makita offers a wide variety of

ACCESSORIES!

THE WORLD'S FIRST CORDLESS REAR-HANDLE CIRCULAR SAW!

558 Cuts In 2" x 4" Material Using 5.0 Ah Batteries!!

• High performance for heavy-duty cutting applications

• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load

condition, enabling rapid movement between high speed and high torque applications

• LED charge level indicator displays approximate remaining battery power

• Lightweight design with magnesium baseplate and blade case

• Enlarged depth scale with rubberized lever for maximum operator convenience and accuracy

• Large integrated tool hanger provides convenience

on the jobsite and fits 4" x 4" material

7-1/4" Rear Handle Circular Saw

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Blade Diameter

7-1/4" (185 mm)

Arbor

5/8" (15.88 mm)

Maximum Cutting Depth:

0°

2-9/16" (65 mm)

45°

1-3/4" (45 mm)

53°

1-1/2" (38 mm)

No Load Speed

5,100 RPM

Overall Length

17-1/2" (446 mm)

Net Weight

11.0 lbs (5.0 kg)

DRS780PT21

STANDARD EQUIPMENT INCLUDES:

DRS780PT21:

Two 18V (5.0Ah) Li-Ion Batteries

BL1850B (196675-2), Dual Port Rapid Charger (DC18RD), 7-1/4" C.T. Blade 24T

(1 Ea.A-94530-10), Offset Wrench 13 (782016-4), 21"Tool Bag (821007X)

DRS780Z:

Tool Only. Batteries and Charger Sold Separately.

7-1/4" C.T. Blade 24T (1 Ea.A-94530-10), Offset Wrench 13 (782016-4)

Cutting

Capacity

of 2-9/16"

(65 mm)

DRS780Z

Makita's FIRST 18Vx2 7-1/4˝ Circular Saw!

• Offers the power of electric saws with the convenience and versatility of

cordless saws!

• Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety

• Large lock-off safety lever prevents accidental start up

• High performance and lightweight design with magnesium blade case and base plate

• Blower feature keeps cutting line free of sawdust

• Bevel capacity of 50° with positive stop at 45°

7-1/4" Circular Saw

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Blade Diameter

7-1/4" (185 mm)

Arbor

5/8" (15.88 mm)

Maximum Cutting Depth:

0°

2-5/8" (66 mm)

45°

1-7/8" (47.5 mm)

50°

1-11/16˝ (42.5 mm)

No Load Speed

4,800 RPM

Overall Length

14" (356 mm)

Net Weight

7.5 lbs (3.4 kg)

DHS711Z

DHS711PF2

STANDARD EQUIPMENT INCLUDES:

DHS711PF2:

Two 18V (3.0Ah) Li-Ion Batteries

BL1830B (194205-3), Dual-Port Rapid Charger (DC18RD), Battery Cover (450128-8),

7-1/4" C.T. Blade 24T (1 Ea.A-94530-10), Hex Wrench 5 (783217-7), Guide Rule (164095-8),Tool Bag (831284-7)

DHS711Z:

Tool Only. Batteries and Charger Sold Separately.

7-1/4" C.T. Blade 24T (1 Ea.A-94530-10), Hex Wrench (783217-7),

Guide Rule (164095-8)

Cutting Capacity

of 2-5/8" (66 mm)

DLS600Z

Incorporates Makita's Deep And Exact Cutting Technology (DXT)

Up To 3-5/8˝ Cuts In 2x Material

• Compact size and weight ideal for cutting small materials, including molding, casing and trim, flooring,

dowels, DIY, hobby and more!

• Brushless DC motor with high power to weight and size ratio

• 3 stage gear reduction system increases cutting capacity vs. traditional mitre saws

• Mini sub-fence provides material support for

vertical and left bevel cuts

• Adjustable position LED job light successfully

illuminates cutting area

6-1/2" Dual Compound Mitre Saw with Laser

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Blade Diameter

6-1/2" (165 mm)

Arbor

5/8" (15.88 mm)

No Load Speed

5,000 RPM

Overall Length 13-3/8" (340 mm)

Net Weight

13.3 lbs (6.0 kg)

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

6-1/2" C.T. Blade 64T (A-99948), Dust Bag (122884-7), Vertical Vise (122940-3),

Triangle Rule (762001-3), Sub-Fence (126697-8), Hex Wrench 2.5 (783208-8), Hex Wrench 5 (783203-8)

High Performance And Efficiency For Heavy-Duty

Cutting Applications

• Electric brake stops blade 3-5 seconds after trigger is released for increased

operator safety

• Soft start feature gradually increases speed to eliminate start up shock

• Lightweight design with magnesium baseplate and blade case

• LED charge level indicator displays approximate remaining battery power

• Twin LED job light, with pre-glow and afterglow, and blower function keeps cut line visible for precise

cutting performance

• Trigger-lock button prevents accidental start-up for increased safety

• Bevel capacity of 0° - 56° with positive stop at 22.5° and 45°

7-1/4" Circular Saw

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Blade Diameter

7-1/4" (165 mm)

Arbor

5/8" (15.88 mm)

Maximum Cutting Depth:

0°

2-5/8" (66 mm)

45°

1-13/16" (45.5 mm)

56°

1-5/16" (34.0 mm)

No Load Speed

6,000 RPM

Overall Length

13-1/2" (342 mm)

Net Weight

7.8 lbs (3.5 kg)

DHS780Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

7-1/4" CTBlade 24T (B-61656), Dust Nozzle Set (196520-1), Hex Wrench 6 (783204-6)

Cutting Capacity

of 2-5/8" (66 mm)

DHS680Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

6-1/2" C.T. Saw Blade 24T (A-85092), Hex Wrench 5 (783203-8)

Makita's FIRST Brushless Li-Ion Circular Saw!

• Ultra-compact and lightweight design with high performance for heavy-duty cutting applications

• Automatic Torque Drive Technology

(ADT) adjusts motor speed and torque during

heavy-duty cutting applications for maximum jobsite efficiency and performance

• LED charge level indicator displays approximate remaining battery power

• Enlarged depth and bevel scales with rubberized levers for maximum operator convenience

and accuracy

6-1/2" Circular Saw

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Blade Diameter

6-1/2" (165 mm)

Arbor

5/8" (15.9 mm)

Maximum Cutting Depth:

0°

2-1/4" (57 mm)

45°

1-5/8" (41 mm)

50°

1-7/16" (37 mm)

No Load Speed

5,000 RPM

Overall Length

13-3/4" (350 mm)

Net Weight

6.0 lbs (2.7 kg)

Automatic Torque Drive Technology,

Two-Stage Safety Switch, Electric Brake,

Soft Start, Blower, LED Light,

Cutting Capacity Of 2-1/4" (57 mm)

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries

and Charger Sold Separately.

7-1/4" CTBlade 24T (B-61656),

Dust Nozzle Set (196520-1), Hex Wrench 6 (783204-6)

7-1/4" Circular Saw with AWS

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Blade Diameter

7-1/4" (165 mm)

Arbor

5/8" (15.88 mm)

Maximum Cutting Depth:

0°

2-5/8" (66 mm)

45°

1-13/16" (45.5 mm)

56°

1-5/16" (34.0 mm)

No Load Speed

6,000 RPM

Overall Length

13-1/2" (342 mm)

Net Weight

7.8 lbs (3.5 kg)

DHS781Z

Bluetooth

is a registered

trademark of Bluetooth

SIG

Auto-Start Wireless System (AWS) Technology Features

Wireless Dust Collection Technology!

• AWS (Auto-Start Wireless System) uses Bluetooth

technology to communicate between tool and vacuum

and enable wireless control when used with Makita AWS cordless tools (DHS781 Only)

• Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety

• Soft start feature gradually increases speed to eliminate start up shock

• Lightweight design with magnesium baseplate and blade case

• LED charge level indicator displays approximate remaining battery power

• Twin LED job light, with pre-glow and afterglow, and blower function

keeps cut line visible for precise cutting performance

• Trigger-lock button prevents accidental

start-up for increased safety

Cutting

Capacity

of 2-5/8"

(66 mm)
