When
QUALITY&SERVICE
Counts – ChooseMakita
HS301DSYE
STANDARD EQUIPMENT INCLUDES:
HS301DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
3-3/8" C.T. Blade 20CT (A-95021), Hex Wrench 4 (783202-0), Plastic Carrying Case (821663-7)
HS301DZ:
Tool Only. Batteries and Charger Sold Separately.
3-3/8˝ C.T. Blade 20CT (A-95021), Hex Wrench 4 (783202-0)
Compact eXtreme Technology (CXT)
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and
overall battery life
• Blower feature keeps cutting line free
of sawdust
• Bevel capacity 0º - 45º
3-3/8" Circular Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Blade Diameter
3-3/8" (85 mm)
Arbor
9/16" (15 mm)
Maximum Cutting Capacities:
0º
1" (25.5 mm)
45º
5/8" (16.5 mm)
No Load Speed
1,500 RPM
Overall Length
12-3/8" (313 mm)
Net Weight
3.5 lbs (1.6 kg)
HS301DZ
CC301DSYE
STANDARD EQUIPMENT INCLUDES:
CC301DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB),
Two Battery Covers (456128-6), Diamond Wheel (A-95722), Hex Wrench 4 (783202-0)
CC301DZ:
Tool Only. Batteries and Charger Sold Separately.
Diamond Wheel (A-95722), Hex Wrench 4 (783202-0)
Compact eXtreme Technology (CXT)
Specifically Designed For Cutting Glass and Ceramic Tile
• Battery protection system shuts tool off when overloaded or when
battery capacity is low
• Water supply tank (500 ml) features large cap for quick and easy refilling
• Bevel capacity of 45º
3-3/8" Glass & Tile Circular Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Blade Diameter
3-3/8" (85 mm)
Arbor
9/16" (15 mm)
Maximum Cutting Depth:
0°
1" (25.5 mm)
45°
5/8" (16.5 mm)
No Load Speed
1,600 RPM
Overall Length
12-3/8" (313 mm)
Net Weight
4.0 lbs (1.8 kg)
CC301DZ
JV101DSYE
STANDARD EQUIPMENT INCLUDES:
JV101DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Blade (1 Ea. 792529-7), Hex Wrench 3 (783201-2), Guide Rule (192732-4), Plastic Carrying Case (821691-2)
JV101DZ:
Tool Only. Batteries and Charger Sold Separately.
Blade (1 Ea. 792529-7), Hex Wrench 3 (783201-2)
Compact eXtreme Technology (CXT)
• 3 orbital settings enable operator to obtain a more aggressive cut
• Blower feature keeps cutting line free of saw dust
• Bevel capacity 0º - 45º
• Adapts quickly and easily to Makita Dust Extractors
Variable Speed
Jig Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Depth:
Mild Steel
1/16" (2 mm)
Wood
2-9/16" (65 mm)
Stroke Per Minute
0- 2,900 SPM
Length of Stroke
11/16" (18 mm)
Overall Length
9-1/8" (232 mm)
Net Weight
3.8 lbs (1.7 kg)
JV101DZ
SD100DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Base Cover (456624-4), Blade Cover (456632-5), Blade (B-49703),
Dust Collector (123559-1), Hex Wrench 3 (783201-2)
Designed For Efficient And Dust-Free Drywall Cutting
• Ideal for cutting holes and vents in drywall, plasterboard and wooden panelling
• Excellent tool balance and lightweight design enables easy straight cutting and overhead operation
• Variable speed trigger enables operator to adjust cutting speed based on materials or application
• Cutting depth can be adjusted according to drywall thickness
• Integrated dust box enables dust-free operation in overhead cutting applications
• Base cover protects drywall material from damage
• LED job light illuminates work area
• Quickly and easily adapts to Makita Dust Extractors
for dust-free operation
Drywall Cutter
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Capacities:
Drywall
1-3/16" (30 mm)
Wood
9/16" (15 mm)
Strokes Per Minute
0 - 6,000 SPM
Length of Stroke
1/4" (6 mm)
Overall Length
9-3/4" (248 mm)
Net Weight
2.7 lbs (1.2 kg)
Variable Speed
JV103DSYJ
STANDARD EQUIPMENT INCLUDES:
JV103DSYJ:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Jig Saw Blades (1 Ea. 792529-7), Hex Wrench 3 (783201-2), Cover Plate (457867-1), Interlocking Case (197210-9)
JV103DZ:
Tool Only. Batteries and Charger Sold Separately.
Jig Saw Blades (1 Ea. 792529-7), Hex Wrench 3 (783201-2),
Cover Plate (457867-1)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Tool-less blade change system enables fast, one-handed blade changes
• Soft no-load rotation function can be enabled or disabled at the operator’s preference
Tool-Less Blade Change, Soft Start, Soft No-Load,
Variable Speed, Electric Brake
Jig Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Depth:
Steel
3/8" (10 mm)
Wood
3-1/2" (90 mm)
Aluminum
13/16" (20 mm)
Stroke Per Minute
800 - 3,000 SPM
Length of Stroke
7/8" (23 mm)
Overall Length
9-3/8" (237 mm)
Net Weight
3.8 lbs (1.7 kg)
JV103DZ
D-Handle
Style
JV102DSYJ
STANDARD EQUIPMENT INCLUDES:
JV102DSYJ:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Jig Saw Blades (1 Ea. 792529-7), Hex Wrench 3 (783201-2), Cover Plate (457867-1), Interlocking Case (197210-9)
JV102DZ:
Tool Only. Batteries and Charger Sold Separately.
Jig Saw Blades (1 Ea. 792529-7), Hex Wrench 3 (783201-2),
Cover Plate (457867-1)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Tool-less blade change system enables fast, one-handed blade changes
• Soft no-load rotation function can be enabled or disabled at the operator’s preference
Tool-Less Blade Change, Soft Start, Soft No-Load,
Variable Speed, Electric Brake
Jig Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Depth:
Steel
3/8" (10 mm)
Wood
3-1/2" (90 mm)
Aluminum
13/16" (20 mm)
Stroke Per Minute
800 - 3,000 SPM
Length of Stroke
7/8" (23 mm)
Overall Length
9-3/8" (237 mm)
Net Weight
3.9 lbs (1.8 kg)
JV102DZ
Barrel Handle
Style
