54 / 220
12VMAXCXT
Power Tools
makita.ca
52
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
DA333DSYE
STANDARD EQUIPMENT INCLUDES:
DA333DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), 3/8" Keyless Drill Chuck (763228-8),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Battery Cover (456128-6), Plastic Carrying Case (821723-5)
DA333DZ:
Tool Only. Batteries and Charger Sold Separately.
3/8" Keyless Drill Chuck (763228-8), Phillips Bit 2-50 (784244-7),
Hook (346909-5)
Compact Design For Optimal Versatility In Confined Spaces
• Compact head and center height for easy use when working between framing studs or any other close
quarter application
• Large paddle switch with variable speed enables fine adjustment for maximum control and precision in
a wide range of applications
• Electric brake stop rotation immediately after trigger is released for added user safety
• Easy-to-operate push button type Forward / Reverse change switch
• LED job light with pre-glow and afterglow feature illuminates drilling area
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
• Keyless Chuck for quick and easy bit installation and removal
Variable Speed, Reversible
3/8" Angle Drill
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Capacities:
Steel
3/8" (10 mm)
Wood
1/2" (12 mm)
No Load Speed
0 - 1,100 RPM
Overall length
12-3/8" (313 mm)
Net Weight
2.7 lbs (1.2 kg)
DA333DZ
DA333D
TL065DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346909-5)
Compact Angled Head For Easy Access In Confined Spaces
• 2-1/8" Head Height ideal for driving fasteners in confined spaces
• Machined Aluminum Head for added durability
• 360º Rotatable Head enables operation from optimum angle
• Conveniently located Forward / Reverse Switch
• LED Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
3/8" Angle Impact Wrench
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Square Drive
3/8"
No Load Speed
0 - 2,000 RPM
Impacts Per Minute
0 - 3,000 IPM
Maximum Fastening Torque
530 in. lbs (60 Nm)
Overall Length
15" (380 mm)
Net Weight
2.5 lbs (1.1 kg)
3/8" Square Drive,
Variable Speed, Reversible
TL064DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-45 (784202-3), Hook (346909-5)
Compact Angled Head For Easy Access In Confined Spaces
• 2-1/8" Head Height ideal for driving fasteners in confined spaces
• Machined Aluminum Head for added durability
• 360º Rotatable Head enables operation from optimum angle
• Conveniently located Forward / Reverse Switch
• LED Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
1/4" Angle Impact Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank
1/4"
No Load Speed
0 - 2,000 RPM
Impacts Per Minute
0 - 3,000 IPM
Maximum Fastening Torque
530 in. lbs (60 Nm)
Overall Length
15" (380 mm)
Net Weight
2.5 lbs (1.1 kg)
1/4" Hex Shank,
Variable Speed, Reversible
TM30DZKX4
STANDARD EQUIPMENT INCLUDES:
TM30DZKX4:
Tool Only. Batteries and Charger Sold Separately.
Abrasive Paper 60G (2 Ea. B-21565),
Abrasive Paper 120G (2 Ea. B-21593),Abrasive Paper 240G (2 Ea. B-22931), 1-1/8" Plunge Saw Blade (B-21353), Sanding Pad (B-67169),
Hex Wrench 5 (783233-9), Plastic Carrying Case (821608-5)
TM30DZX6:
Tool Only. Batteries and Charger Sold Separately.
Plunge Saw Blade (B-67066),AdapterA (196271-6),
Adapter C (313249-6), Hex Wrench 5 (783233-9)
Compact eXtreme Technology (CXT)
• Accepts standard Oscillating Interface System (OIS) accessories
• Soft start feature gradually increases speed to eliminate start up shock
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• LED job light illuminates work area
Variable Speed,
Soft Start,
Anti-Restart Feature
Multi Tool
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Oscillations Per Minute
6,000 - 20,000 OPM
Oscillation Angle
3.2º total
Circumference
6-5/8" (168 mm)
Overall Length
10-7/8" (277 mm)
Net Weight
2.0 lbs (0.9 kg)
TM30DZX6
CP100DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Multi Cutter Blade (198604-1)
Compact eXtreme Technology (CXT)
• Ideal for cutting carpet, cardboard, canvas, leather, felt, rubber matting, vinyl sheets, corrugated plastic
• 10-sided cutting blade with fixed bottom die for clean shear cutting effect
• Auto self-sharpening feature maintains sharp cutting performance
• Cuts approx. 1,900+ ft. of 3/16" cardboard per charge with 12V MAX CXT Li-Ion Battery BL1016
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Multi Cutter
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
300 RPM
Cutting Capacity
1/4" (6 mm)
Overall Length
11-1/2" (291 mm)
Net Weight
1.2 lbs (0.5 kg)
Multi Cutter Blade 198604-1
• Replacement 10-sided blade for
Makita 12V MAX CXT Li-Ion Multi Cutter
• Available 1/pk
• Includes replacement lock pin
