EA3501S40B / EA3201S40B FEATURES & BENEFITS
OUTDOOR
makita.ca
140
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DCS6421-20
STANDARD EQUIPMENT INCLUDES:
20˝ Chain (523 099 072), 20˝ Guide Bar (445 050 655), Chain cover (952 020 660),Tool kit (957 004 002)
20˝ Bar
• Throttle-lock start position with decompression valve
• External access holes allow easy carburetor
adjustment
• Automatic adjustable chain oiler
• Electronic ignition system incorporates a
microprocessor
• Inertia chain brake
Reduced Engine Emission With
Catalytic-Converter
20˝ / 64 cc 2 Stroke Chainsaw
SPECIFICATIONS
Displacement
64 cc. (3.9 cu.in.)
Chain Pitch / Gauge
3/8˝ / .058˝
Maximum Engine Speed 13,500 RPM
Power Rating
3.5 kW / 4.7 H.P.
Fuel Tank Capacity
750 ml
Oil Tank Capacity
420 ml
Fuel / Oil mixture
50:1
Net Weight Dry w/o Bar/Chain
13.9 lbs. (6.3 kg)
DCS5121-18
STANDARD EQUIPMENT INCLUDES:
18˝ Chain (523 686 072),18˝ Guide bar (445 045 631), Chain cover (952 020 650), Tool Kit (957 004 002)
18˝ Bar
• Throttle-lock start position
• External access holes allow easy carburetor
adjustment
• Primer pump for easy starting
• Automatic chain oiler
• Electronic ignition
• Inertia chain brake
• Large diameter fuel / oil caps with external
fuel indicator
• Handles and grips proportioned for
optimum comfort
Efficient Cold Weather Operation
18˝ / 50 cc 2 Stroke Chainsaw
SPECIFICATIONS
Displacement
50 cc. (3.1 cu.in.)
Chain Pitch / Gauge
.325˝ / .058˝
Maximum Engine Speed 13,800 RPM
Power Rating
2.5 kW / 3.3 H.P.
Fuel Tank Capacity
470 ml
Oil Tank Capacity
269 ml
Fuel / Oil Mixture
50:1
Net Weight Dry w/o Bar/Chain
12.1 lbs. (5.4 kg)
EA4300F45C
STANDARD EQUIPMENT INCLUDES:
.325" Chain 18" 50G (512 484 672), 18" Sprocket Nose Bar .325" 50G (444 045 141), Chain Protector Cover (952 020 640),
Universal Wrench (941 713 160), Offset Screwdriver (940 827 000), Screwdriver (for CarburetorAdjustment) (944 340 001)
18˝ Bar
• Catalytic converter reduces engine emissions for
reduced environmental impact
• Throttle-lock start position with decompression
valve for reduced start up force
• External access holes allow easy
carburetor adjustment
• Primer pump for easy starting
• Automatic chain oiler
• Inertia chain brake
Rapid Start
18˝ / 43 cc 2 Stroke Chainsaw
SPECIFICATIONS
Displacement
42.4 cc (2.6 cu.in.)
Chain Pitch / Gauge
.325˝ / .050˝
Maximum Engine Speed 13,500 RPM
Power Rating
2.1kW / 2.9 H.P
Fuel / Oil Mixture (Makita Oil)
50:1
Ignition System
Electronic
Fuel Tank Capacity
480 ml
Oil Tank Capacity
280 ml
Dry Weight w/o Bar/Chain
10.8 lbs (4.9 kg)
STANDARD EQUIPMENT INCLUDES:
24" Chain (523 099 084), 24" Guide Bar (445 050 652), Chain Cover (952 020 660),Tool Kit (957 004 002)
20˝ Bar
• Scavenging Losses Rejection (SLR) muffler
recycles exhaust emissions for increased
operational efficiency and cleaner emissions
• Throttle-lock start position with decompression
valve for reduced start up force
• External access holes allow easy
carburetor adjustment
• Primer pump for easy starting
• Automatic chain oiler
• Inertia chain brake
Scavenging Losses
Rejection (SLR) Muffler
20˝ / 73 cc 2 Stroke Chainsaw
SPECIFICATIONS
Displacement
72.6 cc. (4.4 cu.in.)
Chain Pitch / Gauge
3/8" / . 058”
Maximum Engine Speed 10,000 RPM
Power Rating
4.0 kW / 5.4 H.P.
Fuel Tank Capacity
750 ml
Oil Tank Capacity
420 ml
Fuel / Oil Mixture
50:1
Net Weight: Dry w/o Bar/Chain
13.8 lbs (6.3kg)
EA7300P50E
Intelligent Ignition Coil
controls stable idling, increases output power,
protects against engine overrun and enables easy restarting
Touch & Stop Switch
automatically returns
switch to start position, eliminating
carburetor flooding and enabling
easy intermittent cutting operations
Rapid Start
system features spring assisted recoil starter
to reduce the pull force required to start the saw
Primer Bulb
allows
operator to load up fuel
system without flooding
the carburetor
Toolless Chain Tensioner
enables quick and easy
adjustment on the jobsite without
the need for additional tools
Catalytic Converter
complies with EPA Phase 2,
EU Stage 2 exhaust
emission regulations
Inertia Chain Brake
