Cordless
Power Tools
makita.ca
157
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
BFH120FRAE
STANDARD EQUIPMENT INCLUDES:
Two 12V (2.0Ah) MAKSTAR Batteries
(193928-0), Charger (DC18RA), Steel Carrying Case (183664-6),TorqueAdjustmentTool (765027-4)
• Precise torque control consistently delivers repeatability of +/- 10%
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Hex
1/4˝ (6.4 mm)
No Load Speed
400 RPM
Fastening Torque
5.0 - 12.0 Nm.
(44 - 106 in./lbs.)
Width
2-3/16˝ (55.5 mm)
Height (With Battery) 10-15/32˝ (266 mm)
Length (With Battery)
7-7/8˝ (200 mm)
Net Weight
3.3 lbs. (1.3 kg)
Reversible
BFH040RAE
STANDARD EQUIPMENT INCLUDES:
Two 12V (2.0Ah) MAKSTAR Batteries
(193928-0), Charger (DC18RA), Steel carrying case (183664-6),Torque adjustment tool (765027-4)
• Precise torque control consistently delivers repeatability of +/- 10%
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
1/4˝
Cordless Hazardous Location Screwdriver
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Hex
1/4˝ (6.4 mm)
No Load Speed
400 RPM
Fastening Torque
0.8 - 4.5 Nm.
(7 - 40 in./lbs.)
Width
2-3/16˝ (71 mm)
Height (With Battery) 10-15/32˝ (266 mm)
Length (With Battery)
7-7/8˝ (200 mm)
Net Weight
3.3 lbs. (1.3 kg)
Reversible
BFH090SAE
STANDARD EQUIPMENT INCLUDES:
Two 12V (2.0Ah) MAKSTAR Batteries
(193928-0), Charger (DC18RA), Steel carrying case (183664-6),Torque adjustment tool (765027-4)
• Precise torque control consistently delivers repeatability of +/- 10%
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
1/4˝
Cordless Hazardous Location Screwdriver
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Hex
1/4˝ (6.4 mm)
No Load Speed
400 RPM
Fastening Torque
3.4 - 9 Nm.
(30 - 80 in./lbs.)
Width
2-3/16˝ (71 mm)
Height (With Battery) 10-15/32˝ (266 mm)
Length (With Battery)
7-1/2˝ (190 mm)
Net Weight
3.1 lbs. (1.4 kg)
Reversible
1/4˝
Cordless Hazardous Location Screwdriver
HAZLOC series tools are the only cordless power tools in the world, certified to be used in
a Class I Division 2 (group A – D) environment as outlined in UL1604 standard.
Class I:
Specifies that ignitable gases, vapours or liquids exist.
Division 2:
Specifies that concentrations of flammable gases, vapours or liquids are not likely to exist under normal
operating conditions but likely to exist under abnormal conditions.
BFH090SAE
