Ergonomic Soft Rubber Grip For Vibration Absorption
And Comfortable Operation
Three switches are installed in handle, front grip and sub grip
• 2-hand operation switch–motor will run only when grips are held with both hands
• Guard is provided at the tip of blades to prevent kick-back
• Blades are coated particularly to improve durability
• Built in clutch for safety
• Easy blade replacement
• Powerful 550W Motor
• Protection of extension cord from breakage
SPECIFICATIONS
Strokes Per Minute
1,600 SPM
AMPS (120V)
4.8 A
UH6570:
Overall Length 40-1/2˝ (1,031 mm)
UH6570:
Net Weight
3.8 lbs. (8.4 kg)
UH5570:
Overall Length 40-1/2˝ (1,031 mm)
UH6570:
Net Weight
3.7 lbs. (8.2 kg)
STANDARD EQUIPMENT INCLUDES:
Cord Holder Complete Set (194677-2),Hook Complete Set(158024-1), Blade Cover (450490-1),
Shear BladeAssembly Set (194669-1)
UH6570
STANDARD EQUIPME
N
T INCLUDES:
Cord Holder Complete Set (194677-2),Hook Complete Set(158024-1), Blade Cover (450490-1),
Shear BladeAssembly Set (194665-9)
UH5570
25-1/2˝ Bar
(650 mm)
21-5/8˝ Bar
(550 mm)
UH6570, UH5570
Electric Hedge Trimmers
Electric Brake
EN5950SH
STANDARD EQUIPMENT INCLUDES:
Blade Cover,Tool Set, Oil Set,Accessory Bag (831304-7)
Short Shaft Style Ideal For Vertical Cutting of Tall Hedges and Shrubs
Complies with CARB Tier 3, EPA Phase 2, EU Stage 2 Emissions Requirements
• Multi-position engine lubrication system allows Makita 4-Stroke Pole Hedge Trimmers to be operated at
any angle for maximum vertsaility
• Fixed hedge trimmer head ideal for use in vertical cutting applications
• 23-1/4
˝
double-sided blades for fast, versatile cutting of hedges and shrubs
• Wide trigger control and soft
rubber grip design for
comfortable operation
23-1/4˝ / 25.4 cc 4 Stroke Short Shaft Pole Hedge Trimmer
SPECIFICATIONS
Displacement
25.4 cc
Maximum Engine Power 0.77 Kw / 1.1 HP
Cutting Length
23-1/4˝ (590 mm)
Carburetor
Diaphragm Type
Ignition System
Electronic
Fuel Tank Capacity
0.6 L
Overall Length
71-1/4˝ (181 cm)
Net Weight
14.1 lbs ( 6.4 kg)
EN4950H
STANDARD EQUIPMENT INCLUDES:
Blade Cover,Tool Set, Oil Set,Accessory Bag (831304-7)
Long Shaft Style Ideal For Reaching Tall Hedges Or Shrubs
Complies with CARB Tier 3, EPA Phase 2, EU Stage 2 Emissions Requirements
• Multi-position engine lubrication system allows Makita 4-Stroke Pole Hedge Trimmers to be operated at
any angle for maximum vertsaility
• 135
°
hedge trimmer head articulation (-90
°
- 45
°
)
with 13 positive stops (11.25
°
increments)
• Pin style angle securing system provides
added retention at positive stop angles
versus fricton securing systems
• Hedge trimmer blades fold up to
180
°
to provide compact size during
transport or storage
19-1/4˝ / 25.4 cc 4 Stroke Long Shaft Pole Hedge Trimmer
SPECIFICATIONS
Displacement
25.4 cc
Maximum Engine Power 0.77 Kw / 1.1 H.P.
Cutting Length
19-1/4˝ (490 mm)
Carburetor
Diaphragm Type
Ignition System
Electronic
Fuel Tank Capacity
0.6 L
Overall Length
99˝ (252 cm)
Net Weight
15.6 lbs. ( 7.2 kg)
Ideal for pruning and limbing in tall trees
or hard to reach areas
• Reduced fuel consumption and operating costs impact versus
competitive 2 stroke models
• Cleaner 4-stroke emissions limits environmental impact and reduced carbon
buildup in engine
• Lighweight head design for reduced operator fatigue
• Patented lubrication system enables telescopic pole chainsaw to be used at any angle
• Decompression valve and primer pump enable quick and easy starting
• Fully compliant with CARB Tier 3, EPA Phase 2, EU Stage 2 exhaust
emissions regulations
SPECIFICATIONS
Displacement
25.4 cc (1.5 cu. in.)
Chain Pitch / Gauge
3/8˝ / . 050˝
Maximum Engine Power
0.77 Kw / 1.1 HP
Maximum Engine Speed
10,000 RPM
Cutting Length
10˝ (255 mm)
Carburetor
Diaphragm Type
Fuel Tank Capacity
600 ml
Oil Tank Capacity
120 ml
Overall Length
154-1/2˝ (2,720 mm)
Net Weight
16 lbs ( 7.2 kg)
EY2650H25H
10˝ / 25.4 cc 4-Stroke Pole Chainsaw
STANDARD EQUIPMENT INCLUDES:
Blade Cover,Tool Set, Oil Set,Accessory Bag (831304-7)
