makita.ca
153
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
BFT041RZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Bluetooth
®
Enabled For Wireless Data Capture Of Fastening Torque And Angle
• Precise torque control consistently delivers
repeatability of +/- 10%
• Built in LED to illuminate tight spaces
• Using optional receiver, can record torque
and angle data
• Highly accurate spring clutch
• Uses LXT technology for long battery life
• Design and built to withstand high volume
assembly processes
1/4˝ Torque Tracer Cordless Precise Torque Screwdrivers
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Hex
1/4˝ (6.4 mm)
Width
2-13/16˝ (72 mm)
Height (With Battery)
10-1/2˝ (266 mm)
Length (With Battery)
7-1/2˝ (191 mm)
Net Weight
2.2 lbs. (1.0 kg)
No Load Speed:
BFT041RZ
800 RPM
BFT082RZ
860 RPM
BFT124RZ
600 RPM
Fastening Torque:
BFT041RZ
1 - 4 Nm. (8.9 - 35 in./lbs.)
BFT082RZ
4 - 8 Nm. (35 – 71 in./lbs.)
BFT124RZ
6-12 Nm. (53 – 106 in./lbs.)
BFL201RZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Bluetooth
®
Enabled For Wireless Data Capture Of Fastening Torque And Angle
• Precise torque control consistently delivers
repeatability of +/- 10%
• Built in LED to illuminate tight spaces
• Using optional receiver, can record torque
and angle data
• Highly accurate spring clutch
• Uses LXT technology for long battery life
• Design and built to
withstand high
volume assembly
processes
3/8˝ Torque Tracer Cordless Precise Torque Angle Wrenches
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Square
3/8˝ (9.5 mm)
Width
2-13/16˝ (72 mm)
Height (With Battery)
3-7/8˝ (98 mm)
Length (With Battery)
16-7/8˝ (429 mm)
Net Weight
2.6 lbs. (1.2 kg)
No Load Speed:
BFL201RZ
360 RPM
BFL301RZ
260 RPM
BFL402RZ
200 RPM
Fastening Torque:
BFL201RZ
10 - 20 Nm. (88.5 – 177 in./lbs.)
BFL301RZ
16 - 30 Nm. (142 – 266 in./lbs.)
BFL402RZ
25 - 40 Nm. (221 – 354 in./lbs.)
MANUFACTURING & ASSEMBLY
BFT124RZ
BFT082RZ
Reversible
BFL402RZ
BFL301RZ
BFT084FZ BFT126FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Designed and manufactured to withstand high volume assembly processes
Reversible
1/4˝
Cordless Precise Torque Screwdrivers
SPECIFICATIONS
Battery Capacities
14V Li-ion
Capacity (Driving Shank)
Hex
1/4˝ (6.4 mm)
Width
2-15/16˝ (74 mm)
Height (With Battery)
9-7/8˝ (250 mm)
Length (With Battery)
7-7/8˝ (200 mm)
Net Weight
2.4 lbs. (1.1 kg)
No Load Speed:
BFT084FZ
780 RPM
BFT126FZ
450 RPM
Fastening Torque:
BFT084FZ
3 - 8 Nm. (27 - 71 in./lbs.)
BFT126FZ
5 - 12 Nm. (44 - 106 in./lbs.)
BFT081FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly pocesses
Reversible
1/4˝
Cordless Precise Torque Screwdrivers
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Hex
1/4˝ (6.4 mm)
Width
2-13/16˝ (71 mm)
Height (With Battery)
9-7/8˝ (251 mm)
Length (With Battery)
7-7/8˝ (200 mm)
Net Weight
2.2 lbs. (1.0 kg)
No Load Speed:
BFT081FZ
700 RPM
BFT123FZ
390 RPM
Fastening Torque:
BFL301RZ
3 - 8 Nm. (26.6 – 70.8 in./lbs.)
BFL402RZ
5 - 12 Nm. (44.3 – 106 in./lbs.)
BFT123FZ
Reversible
