STANDARD EQUIPMENT INCLUDES:
Tool-Kit (227-90301-10),Spark Plug (065-01402-80), Wheel Kit (110004-C), (Battery Not Included)
Electric Start
• RECEPTACLES: Duplex 120V (20 AMP), Locking 120V (20 AMP), Locking 120V (30 AMP),
Locking 120V / 240V (30 AMP)
• GENERATOR: Full copper windings, AC & DC circuit breakers, AVR (Automatic Voltage Regulator)
• SUBARU-ROBIN: Air-cooled 4 cycle single cylinder OHC gasoline engine, Idle switch features full
power mode, Low oil automatic shut-off, Auto
decompression / Electronic ignition, Overhead
valve for more fuel efficiency
8.2 Hours Of Continuous Operation
12,000W / 653 cc 4 Stroke Generator
SPECIFICATIONS
Maximum Output Current
12,000W
(100 / 50 AMP)
Rated Output Current 9,500W / 79.2 / 39.6 A
AC Voltage
60 Hz (120V / 240V)
DC Voltage
12 VDC (8.3 AMP)
Displacement
653 cc
Max. Power
22 H.P. @ 3,600 RPM
Fuel Tank Capacity
44 L
Continuous Operation
8.2 Hrs (at high RPM)
Noise Level
77 dB
Dimensions (L x W x H)
32.5˝ x 24.1˝ x 30.4˝
(826 mm x 611 mm x 771 mm)
Dry Weight
310.0 lbs. (141 kg)
G12000R
STANDARD EQUIPMENT INCLUDES:
Tool Kit (224-90303-00), Starter Rope (20B-50110-08), Spark Plug (065-01402-10)
• RECEPTACLES: Duplex 120V (20 AMP) Locking 120V (20 AMP), Locking 120V (30 AMP),
Locking 120V, 240V (20 AMP)
• GENERATOR: Full copper windings, AC & DC circuit breakers, AVR (Automatic Voltage Regulator)
• SUBARU-ROBIN: Air-cooled 4 cycle single cylinder OHC gasoline engine, Full power mode switch,
Low oil automatic shut-off, Auto decompression / Electronic ignition, Overhead valve for more
fuel efficiency
6.6 Hours Of Continuous Operation
7,100W / 404 cc 4 Stroke Generator
SPECIFICATIONS
Maximum Output Current
7,100W
(59.2 / 29.6 AMP)
Rated Output Current 5,000W / 41.6 / 20.8 A
AC Voltage
60 Hz (120V / 240V)
DC Voltage
12 VDC (8.3 AMP)
Displacement
404 cc
Max. Power
12.5 H.P. @ 4,000 RPM
Fuel Tank Capacity
22 L
Continuous Operation
6.6 Hrs (at high RPM)
Noise Level
75.5 dB
Dimensions (L x W x H)
28-1/2˝ x 20-7/8˝ x 21-3/4˝
(725 mm x 530 mm x 580 mm)
Dry Weight
189.6 lbs. (86 kg)
EG711A
STANDARD EQUIPMENT INCLUDES:
Tool Kit (277-90301-JO), Starter Rope (279-50110-08), Spark Plug (065-01402-10)
• RECEPTACLES: Duplex 120V (20 AMP), Locking 120V (20 AMP)
• GENERATOR: Full copper windings, AC & DC circuit breakers, AVR (Automatic Voltage Regulator)
• SUBARU-ROBIN: Air-cooled 4 cycle single cylinder OHC gasoline engine, full power mode switch,
Low oil automatic shut-off, Auto decompression / Electronic ignition,
Overhead valve for more fuel efficiency
6.8 Hours Of Continuous Operation
5,100W / 287 cc 4 Stroke Generator
SPECIFICATIONS
Maximum Output Current
5,100W
(42.5 / 21.3 AMP)
Rated Output Current
4,200W / 35.0 / 17.5 A
AC Voltage
60 Hz (120V / 240V)
DC Voltage
12 VDC (8.3 AMP)
Displacement
287 cc
Engine
EX30D
Max. Power
9.5 H.P. @ 4,000 RPM
Fuel Tank Capacity
17.8 L
Continuous Operation
6.8 Hrs. (at high RPM)
Noise Level
74 dB
Dimensions (L x W x H)
26-1/2˝ x 20˝ x 21-1/4˝
(675 mm x 570 mm x 570 mm)
Dry Weight
152.1 lbs. (69 kg)
EG511A
EG301A
STANDARD EQUIPMENT INCLUDES:
Tool Kit (277-90301-JO), Starter Rope (277-50110-08), Spark Plug (065-01402-10)
• RECEPTACLES: Duplex 120V (20AMP)
• GENERATOR: Full copper windings, Brushless design, AC & DC circuit breakers
• SUBARU-ROBIN: Air-cooled 4 cycle single cylinder OHC gasoline engine, full power mode switch,
Low oil automatic shut-off,Auto decompression / Electronic ignition, Overhead valve for more fuel
efficiency, Recoil starter
8.2 Hours Of Continuous Operation
3,000W / 169 cc 4 Stroke Generator
SPECIFICATIONS
Maximum Output Current 3,000W (25 AMP)
Rated Output Current
AC Voltage
60 Hz (120V)
DC Voltage
12 VDC (8.3 AMP)
Displacement
169 cc
Max. Power
6.0 H.P. @ 4,000 RPM
Fuel Tank Capacity
12.8 L
Continuous Operation
8.2 Hrs (at high RPM)
Noise Level
70.5 dB
Dimensions (L x W x H)
23-5/8˝ x 16-1/2˝ x 19-3/4˝
(600 mm x 420 mm x 500 mm)
Dry Weight
103.4 lbs. (47 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Kit (277-90301-J0), Starter Rope (277-50408-08), Spark Plug (065-01402-10)
Multi-Monitor LED Display
• RECEPTACLES: Duplex 120V (20AMP), Locking 120V (20AMP)
• GENERATOR: Full copper windings, Brushless design, AC & DC circuit breakers
• SUBARU-ROBIN: Air-cooled 4-cycle single cylinder OHC gasoline engine, Idle switch features full
power mode, Low oil automatic shut-off,Auto decompression / Electronic ignition, Overhead valve for
more fuel efficiency, Recoil starter
9.1 Hours of Continuous Operation
2,800W / 169 cc 4 Stroke Inverter Generator
SPECIFICATIONS
Maximum Output Current 2,800W (23.3 AMP)
Rated Output Current
2,500W / 20.8 A
AC Voltage
60 Hz (120V)
DC Voltage
12 VDC (8.3 AMP)
Displacement
169 cc
Max. Power
6.0 H.P. @ 4,000 RPM
Fuel Tank Capacity
10 L
Continuous Operation
9.1 Hrs (at High RPM)
Noise Level
67 dB
Dimensions (L x W x H) 19˝ x 17˝ x 18-3/4˝
(487 mm x 432 mm x 475 mm)
Dry Weight
82.0 lbs. (37.0 kg)
G2800I
STANDARD EQUIPMENT INCLUDES:
Tool Kit (33K-99001-00), Starter Rope (284-50233-08), Spark Plug (065-01403-80)
• RECEPTACLES: Duplex 120V (20 AMP)
• GENERATOR: Full copper windings, AC & DC circuit breakers
• SUBARU-ROBIN: Air-cooled 4-cycle single cylinder OHC gasoline engine, Idle switch features full power
mode, Low oil automatic shut-off,Auto decompression / Electronic ignition, Overhead valve for more fuel
efficiency, Recoil starter
• Invertor Generator restricts fluctuations: Voltage less than 3%, Frequency less than 1%, Wave distortion
less than 2.5%. Can be used to power your computer
or other sensitive equipment
3.5 Hours of Continuous Operation
1,700W / 85.8 cc 4 Stroke Inverter Generator
SPECIFICATIONS
Maximum Output Current 1,700W (14.2 AMP)
Rated Output Current
1,350W / 11.2 A
AC Voltage
60 Hz (120V)
DC Voltage
12 VDC (8.3 AMP)
Displacement
85.8 cc
Max. Power
2.4 H.P. @ 4,000 RPM
Fuel Tank Capacity
3.5 L
Continuous Operation
3.5 Hrs (at High RPM)
Noise Level
59 dB
Dimensions (L x W x H)
18-15/16˝ x 11/5/8˝ x 17-1/2˝
(490 mm x 295 mm x 445 mm)
Dry Weight
45.2 lbs. (20.5 kg)
G1700I
