COLOUR CODED PLASTIC PROTECTORS & IDENTIFIERS
BFT SERIES BTD & BTW SERIES
BFL SERIES
Models
BFT020FZ, BFT040FZ
BFT080FZ, BFT081FZ
BFT122FZ, BFT123FZ
BFT041RZ, BFT082RZ
BFT084FZ, BFT124RZ
BFT126FZ
BTD040Z
BTD042Z
BTD060Z
BTD062Z
BTW070Z
BTW072Z
BTD120SA
BTW120SA
Models
BFL080FZ, BFL081FZ, BFL082FZ, BFL120FZ, BFL121FZ
BFL122FZ, BFL200FZ, BFL201RZ, BFL202FZ, BFL300FZ
BFL301RZ, BFL400FZ, BFL402RZ
Part No.
Part No.
Clutch Case Only
Angle Head Only
Complete
Yellow
418423-2
-
-
Yellow
418691-7
418692-5
418693-3
418032-7
Blue
418424-0
417835-6
-
Blue
418743-4
418746-8
418749-2
418064-4
Red
418425-8
417834-8
-
Red
418744-2
418747-6
418750-7
418065-2
Clear
450331-1
417349-5
418834-1
Clear
418745-0
418748-4
418751-5
418066-0
ASSEMBLY ACCESSORIES
194444-5
800W96-7
889920-9
A-55924
638386-8
194089-9
765027-4
Receiver
RCV02
RCV02
Software
CD-ROM
RCV02
Instructional
CD-ROM
RCV02 with
CD-ROM Set
Includes Instructional
and Software CD-ROM's
RS-232C
Cable
USB
Serial
Adapter
Set
Torque
Adustment
Tool
For all BFH, BFL and
BFT models
STANDARD EQUIPMENT INCLUDES:
7.2V (1.0Ah) Li-Ion Battery
BL14302 (194356-2), Charger (DC10WB), Holster (168435-2), Drill Set (194375-8), Bit Holder (419730-6),
Phillips Bit 1-50 (784245-5), Phillips Bit 2-50 (784244-7), Slotted Bit 6-50 (784025-9), Soft Case (831272-4),Tool Bag (831277-4)
1/4˝ Cordless Impact Driver
SPECIFICATIONS
Battery
7.2V (1.0 Ah) Li-Ion
Impacts Per Minute
3,000 IPM
No Load Speed
2,300 RPM
Maximum Fastening Torque
195 in. lbs (22 Nm)
Capacities:
Machine Screw 1/8˝ - 5/16˝ (M3 - M8)
Standard Bolt
1/8˝ - 5/16˝ (M3 - M8)
High Tensile Bolt 1/8˝ - 1/4˝ (M3 - M6)
Overall Length
11-1/8˝ (282 mm)
Net Weight
1.2 lbs (0.5 kg)
TD021DS
Variable Speed, Reversible
Compact And Lightweight Design With Precision Control
And High Fastening Torque
• Multi-function variable speed rotary switch allows operators to adjust driving speed and direction
simultaneously for precise fastening applications
• Switch position enables easy access for left or right handed users
• Lock-off button prevents accidental startup
• Adjustable handle with enhanced hinge mechanism for operational versatility
• LED job light with pre-glow feature
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
BML145
• 4-Position Pivoting Head for greater versatility
• High illumination emits high power at 4,500 Lux
• New Xenon bulb for extra brightness
• BATTERY NOT INCLUDED
14.4V Li-Ion Flashlight
SPECIFICATIONS
Battery Capacities
14V Li-ion
Continuous Use
up to 3.7 hours
Overall Length
11-1/8˝ (284 mm)
Net Weight (no battery)
0.9 lbs. (0.4 kg)
