Why Professionals Prefer Makita Generators
and Water Pumps Powered By Subaru-Robin
4-Cycle Air Cooled EX Series Engines
• Case-hardened steel timing chain allows for precision timing and maximum durability
• Heavy-Duty piston rings and a cast-iron cylinder liner resist wear and ensure a long engine life
• Automotive collets and forged steel retainers used on Subaru EX engines prolongs engine life
• Hardened steel rocker arms with precision tappet adjusters are used for greater durability and
reduce service requirements
• Dual ball bearing crankshaft support offers maximum stability under demanding loads
• Chain-driven overhead cam design offers superior power and performance with an automatic
decompression system to reduce the required pulling force by 30% to 40% and ensures starting on the first pull.
EX engines start easily – even in cold Canadian winters.
• Cooling fins cast into the interior and exterior of the block maximize surface area for superior engine cooling
• Spherical graphite cast iron crankshaft and crank pin allows for smooth engine operation and extended engine life.
GENERATOR SELECTION CHART
Appliance/Tools
Approximate Running
Wattage Requirements
Approximate Wattage
Required for Starting
Smallest Applicable
Generator
Microwave (750W)
750
1550
G1700I
Coffee Maker
1750
1750
G2800I
Clothes Dryer Electric
5750
7550
EG711A
Washing Machine
750
3050
EG511A
Refrigerator
700
2900
G2800I
Television- Colour
300
300
G1700I
Computer-Desk Top
700
700
G1700I
Furnace Fan
1/2 Horsepower
875
3225
EG301A
Central Air
24,000 BTU
3800
8800
G12000R
32,000 BTU
5000
11500
G12000R
Pumps
Sump Pump-1/2 HP
1050
3200
EG301A
Well Pump- 1/2 HP
1000
3100
G2800I
Air Compressor-Portable
2 horsepower (capacitor start)
2000
5100
EG511A
2.5 horsepower (capacitor start)
2500
5900
EG711A
3 horsepower (capacitor start)
3000
6800
EG711A
Tools
Circular Saw- 7 1/4"
1400
3700
EG301A
Chain Saw- 2 HP (Electric)
1100
1100
G1700I
Drill- 1/2"
600
1500
G1700I
Battery Charger- 15 amp
500
1200
G1700I
Electric Welder 200 amp A/C
9000
9000
G12000R
This chart is for reference only. The wattage requirements for your appliance, motor, or tool may require more or less wattage than is listed in this chart.
Please refer to your owners manual to verify whether or not your generator is appropriate for the equipment you wish to run.
You may also contact your local Makita Factory Service Centre for additional information if you plan on purchasing a new generator.
Note: All wattage requirements are approximate. Values are subject to change without notice
STANDARD EQUIPMENT INCLUDES:
Tool Kit (277-90301-H0), Strainer (480-08310-33), Starter Rope (279-50110-08), Spark Plug (065-01402-10)
• 92’ Total Head (Total height at sea level, to which water can be raised above original water level)
• Electronic sensor shuts off engine if oil is low
• Self priming pump for easy operation
• Mechanical seal made of Silicone-Carbide
• Powered by Robin Engines, Engine model # EX27
3˝ / 9.0 H.P. 4 Stroke Trash Pump
SPECIFICATIONS
Suction / Discharge Diameter 3˝ (76.2 mm)
Total Head
92´ (28 m)
Suction Head
26´ (8.0 m)
Maximum Pumping Capacity:
Liters Per Minute
1,300 LPM
Run Time (Per Tank, Full Load)
2.3 Hrs
Maximum Power
9.0 H.P.
Fuel Mix
No Fuel Mixing
4-Stroke Oil
10W-30
Fuel Tank Capacity
6.1 L
Dimensions (L x W x H)
26.5˝ x 19.1˝ x 24˝
(672 mm x 484 mm x 610 mm)
Dry Weight
106.9 lbs. (48.5 kg)
EW320TR
STANDARD EQUIPMENT INCLUDES:
Tool Kit (277-90301-J0), Strainer (480-08050-29), Starter Rope (277-50110-08), Spark Plug (065-01402-10)
• 105' Total Head (Total height at sea level, to which water can be raised above original water level)
• Electronic sensor shuts off engine if oil level is low
• Self priming pump for easy operation
• Meets EPA / CARB emission standards
• Powered by Robin Engines, Engine model # EX17
3˝ / 5.7 H.P. 4 Stroke Centrifugal Water Pump
SPECIFICATIONS
Suction / Discharge Diameter 3˝ (76.2 mm)
Total Head
105´ (32 m)
Suction Head
26´ (8.0 m)
Maximum Pumping Capacity:
Liters Per Minute
1,000 LPM
Run Time (Per Tank, Full Load)
1.8 Hrs
Max. Power
5.7 H.P.
Fuel Mix
No Fuel Mixing
4 Stroke Oil
10W-30
Fuel Tank Capacity
3.6 L
Dimensions (L x W x H)
20.7˝ x 14.5˝ x 16.5˝
(527 mm x 368 mm x 418 mm)
Dry Weight
60.9 lbs. (27.6 kg)
EW320R
