STANDARD EQUIPMENT INCLUDES:
Hoop (ME01676330), Water Block (ME01676331), Suction Pipe (ME01676336), Coupling (), Socket Wrench (ME08121017)
Increased Pumping Capacity, Suction Head and Total Head For
Maximum Operational Efficiency
• 115' Total Head (Total height at sea level, to which water can be raised above original water level)
• Super low noise muffler
• Three-Vane impeller with semi-open design for efficient water flow
• Self priming pump for easy operation
1˝ / 1.1 H.P. 4 Stroke Centrifugal Water Pump
SPECIFICATIONS
Suction / Discharge Diameter 1˝ (25.4 mm)
Total Head
115´ (35 m)
Suction Head
29´ (8.7 m)
Maximum Pumping Capacity:
Litres Per Minute
110 LPM
Maximum Power
1.0 H.P.
Fuel Tank Capacity
500 ml
Run Time (Per Tank, Full Load)
0.9 hrs
Dimensions (L x W x H)
12-1/2˝ x 9-1/8˝ x 12-7/8˝
(319 mm x 231 mm x 327 mm)
Dry Weight
12.8 lbs. (5.8 kg)
EW1050H
STANDARD EQUIPMENT INCLUDES:
Tool Kit (277-90301-J0), Strainer (480-05050-29), Starter Rope (277-50110-08), Spark Plug (065-01402-10)
• 105´ Total head (Total height at sea level, to which water can be raised above original water level)
• Electronic sensor shuts off engine if oil level is low
• Self priming pump for easy operation
• Meets EPA / CARB emission standards
• Powered by Robin Engines, Engine model # EX15
2˝ / 2.7 H.P. 4 Stroke Centrifugal Water Pump
SPECIFICATIONS
Suction / Discharge Diameter 2˝ (50.8 mm)
Total Head
105´ (32 m)
Suction Head
26´ (8.0 m)
Maximum Pumping Capacity:
Litres Per Minute
520 LPM
Run Time (Per Tank, Full Load)
1.8 Hrs
Maximum Power
4.3 H.P.
Fuel Mix
No Fuel Mixing
4-Stroke Oil
10W-30
Fuel Tank Capacity
2.7 L
Dimensions 18-1/2˝ x 13-1/2˝ x 15-3/4˝
(470 mm x 344 mm x 414 mm)
Dry Weight
54.9 lbs. (24.9 kg)
EW220R
WATER & TRASH PUMP ACCESSORIES
Description
Size
For Model (s)
Part No.
PVC Suction Hoses
(Non-Collapsible)
1" x 20'
EW1050H
123048-A
2" x 20' (Includes Male / Female Fittings)
EW220R
123042-A
3" x 20' (Includes Male / Female Fittings)
EW320R / TR
123043-A
PVC Discharge Hoses
(Collapsible)
1" x 25'
EW1050H
123049-A
1" x 50'
128049-A
2" x 50' (Includes Male / Female Fittings)
EW220R
123045-A
3" x 50' (Includes Male / Female Fittings)
EW320R / TR
123046-A
Replacement Gaskets for
Female Fittings
2"
EW220R
421002-A
3"
EW320R / TR
421003-A
Strainer
1"
EW1050H
480-02550-29
2"
EW220R
480-05050-29
3"
EW320R / TR
480-08310-33
Tool Kit
-
EW1050H
196134-6
EW220R, EW320R / TR
226-90303-00
Spanner Wrench
2" Hose
EW220R
781001-A
3" Hose
EW320R/TR
781002-A
GENERATOR WHEEL KITS
Part No.
Description
For Models
110004-B
• Constructed of rugged,
lightweight tubular steel
• Mounts directly to generator
frame for easy portability
• Pneumatic wheels for easy
transportation around the jobsite
G2800I
EG301A
110004-C
EG511A
EG711A
G12000R
110004-D
EW220R
EW320R / TR
