BFL300FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8˝
Cordless Precise Torque Angle Wrench
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Square
3/8˝ (9.5 mm)
No Load Speed
400 RPM
Fastening Torque
16 - 30 Nm.
(142 – 266 in./lbs.)
Width
2-7/8˝ (73 mm)
Height (With Battery)
4-1/8˝ (104 mm)
Length (With Battery) 19-15/16˝ (506 mm)
Net Weight
3.1 lbs. (1.4 kg)
BFL400FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8˝
Cordless Precise Torque Angle Wrench
SPECIFICATIONS
Battery Capacities
14.4V Li-ion
Capacity (Driving Shank)
Square
3/8˝ (9.5 mm)
No Load Speed
260 RPM
Fastening Torque
25 - 40 Nm.
(221 – 354 in./lbs.)
Width
2-7/8˝ (73 mm)
Height (With Battery)
4-1/8˝ (104 mm)
Length (With Battery) 20-1/16˝ (510 mm)
Net Weight
3.3 lbs. (1.5 kg)
BFL081FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high
volume assembly processes
Reversible
3/8˝
Cordless Precise Torque Angle Wrenches
SPECIFICATIONS
Battery
12V Ni-MH
Capacity (Driving Shank)
Square
3/8˝ (9.5 mm)
Width
2-13/16˝ (71 mm)
Height (With Battery)
3-5/8˝ (92 mm)
Length (With Battery)
17.0˝ (430 mm)
Net Weight
2.4 lbs. (1.1 kg)
No Load Speed:
BFL081FZ
700 RPM
BFL121FZ
410 RPM
BFL200FZ
220 RPM
Fastening Torque:
BFL081FZ
2 - 8 Nm. (17.7 – 70.8 in./lbs.)
BFL121FZ
5 - 12 Nm. (44.3 – 106 in./lbs.)
BFL200FZ
8 - 20 Nm. (70.8 – 177 in./lbs.)
Reversible
Reversible
BFL200FZ
BFL121FZ
BFL080FZ BFL120FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand high volume assembly processes
3/8˝
Cordless Precise Torque Angle Wrenches
SPECIFICATIONS
Battery
9.6V Ni-MH
Capacity (Driving Shank)
Square
3/8˝ (9.5 mm)
Width
2-9/16˝ (65 mm)
Height (With Battery) 2-15/16˝ (74.0 mm)
Length (With Battery)
17˝ (430 mm)
Net Weight
2.4 lbs. (1.1 kg)
No Load Speed:
BFL080FZ
450 RPM
BFL120FZ
250 RPM
Fastening Torque:
BFL080FZ
2 - 8 Nm. (17.7 – 70.8 in./lbs.)
BFL120FZ
5 - 12 Nm. (44.3 – 106 in./lbs.)
Reversible
BFT020FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for
outstanding ergonomics
• On board LED and audible signal informs user of
successful rundown
• Highly accurate spring clutch
• Designed and manufactured to withstand
high volume assembly processes
1/4˝
Cordless Precise Torque Screwdrivers
SPECIFICATIONS
Battery
9.6V Ni-MH
Capacity (Driving Shank)
Hex
1/4˝ (6.4 mm)
Width
2-9/16˝ (65 mm)
Height (With Battery)
10-3/4˝ (274 mm)
Length (With Battery)
7-7/8˝ (200 mm)
Net Weight
2.2 lbs. (1.0 kg)
No Load Speed:
BFT020FZ
540 RPM
BFT040FZ
950 RPM
BFT080FZ
540 RPM
BFT122FZ
320 RPM
Fastening Torque:
BFT020FZ
0.5 - 2 Nm. (4.4 – 17.7 in./lbs.)
BFT040FZ
5-12 Nm. (44.3 – 106 in./lbs.)
BFT080FZ
3 - 8 Nm. (26.6 – 70.8 in./lbs.)
BFT122FZ
5-12 Nm. (44.3 – 106 in./lbs.)
Reversible
BFT122FZ
BFT080FZ
BFT040FZ
BFL082FZ BFL122FZ BFL202FZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Torque adjustment tool (765027-4)
Precise Torque Control Consistently Delivers Repeatability Of +/- 10%
• Built in LED to illuminate tight spaces
• Extremely compact and lightweight for outstanding ergonomics
• On board LED and audible signal informs user of successful rundown
• Designed and manufactured to withstand
high volume assembly processes
3/8˝
Cordless Precise Torque Angle Wrenches
SPECIFICATIONS
Battery Capacities
14V Li-ion
Capacity (Driving Shank)
Square
3/8˝ (9.5 mm)
Width
2-15/16˝ (74 mm)
Height (With Battery)
3-7/8˝ (98 mm)
Length (With Battery)
16-5/8˝ (422 mm)
Net Weight
2.6 lbs. (1.2 kg)
No Load Speed:
BFL082FZ
700 RPM
BFL122FZ
410 RPM
BFL202FZ
220 RPM
Fastening Torque:
BFL082FZ
2 - 8 Nm. (18 – 71 in./lbs.)
BFL122FZ
5 - 12 Nm. (44 – 106 in./lbs.)
BFL202FZ
8 - 20 Nm. (71 – 177 in./lbs.)
Reversible
