STANDARD EQUIPMENT INCLUDES:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Battery Cover (450128-8),Thickness Gauge (762013-6),
Hex Wrench 13 (783201-2), Side Blade Set (792533-6), Centre Blade (792534-4), Plastic Carrying Case (141478-9
16 ga Cordless Straight Shear
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
16 gauge (1.6 mm)
Stainless
18 gauge (1.2 mm)
No Load Speed
4,300 SPM
Minimum Cutting Radius 9-7/8˝ (250 mm)
Overall Length
14-1/4˝ (362 mm)
Net Weight
4.4 lbs. (2.0 kg)
DJS161RFE
In-Line Design Allows For Better Control And Excellent Maneuverability
• Battery Capacity Warning Light indicates ideal time to recharge battery
• Anti-Restart feature prevents accidental start up of tool during battery changing when switch is locked
in the on position
• Electronic Current Limiter with Warning Light prevents motor burnout caused by overloading
• Adjustable blade set minimizes burring for various thicknesses of material
• Small Circumference, Ergonomic Soft Rubber Grip design for vibration absorption
and comfortable operation
DJS130RFE
STANDARD EQUIPMENT INCLUDES:
DJS130RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Battery Cover (450128-8), Hook (281220-7),
Hex Wrench 4 (783202-0), Shear HeadAssy (125849-8), Plastic Carrying Case (824756-9)
DJS130F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3),Hook(281220-7),HexWrench4(783202-0),ShearHeadAssy(125849-8)
DJS130Z:
ToolOnly.BatteriesandChargerSoldSeparately.
Hook(281220-7),HexWrench4(783202-0),ShearHeadAssy(125849-8)
Shear Head Attachment Rotates 360° For Optimum Maneuverability
• Compact and Lightweight (Overall Length 13-3/4˝)
• Lock-Off Button prevents accidental engagement of trigger
• On Board Hex Wrench Storage
• Belt Clip for operator convenience
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
18 ga Cordless Straight Shear
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
18 gauge (1.3 mm)
Stainless
20 gauge (1 mm)
No Load Speed
2,800 SPM
Overall Length
13-3/4˝ (350 mm)
Net Weight
5.3 lbs. (2.4 kg)
DJS130F
DJS130Z
DJN161Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
Wrench(781028-4),HexWrench(783208-8),Die(A-15051),Punch(A-83951)
Optimal Size And Maneuverability For Cutting Keystone Plate,
Deck Plate, Metal Roofing And Other Corrugated Sheet Materials
• Battery Capacity Warning Light indicates ideal time to recharge battery
• Anti-Restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Die rotates 360° with positive stops at 0°, 90° Left, 90° Right and 180° for simple and accurate
adjustment on the jobsite
• Built-in thickness gauge for operator convenience
• Easy punch and die replacement for less down time
16 ga Cordless Nibbler
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Capacities:
Mild Steel
1.6 mm / 16 ga
Stainless
1.2 mm / 18 ga
Aluminum
2.5 mm / 12 ga
Strokes Per Minute
1,900 SPM
Minimum Cutting Radius:
Outside Edge
2˝ (50 mm)
Inside Edge
1-3/4˝ (45 mm)
Overall Length
12-3/8˝ (313 mm)
Net Weight
4.8 lbs (2.2 kg)
LXJP02
STANDARD EQUIPMENT INCLUDES:
LXJP02:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), 4˝ CTCutter Blade 6T(A-95118),
Angle Guide (123148-2), Dust Bag (123150-5), Lock Nut Wrench 20 (782401-1), Set Plate (415579-2), Battery Cover (450128-8),
Plastic Carrying Case (821522-5)
LXJP02Z:
ToolOnly.BatteriesandChargerSoldSeparately.
4˝CTCutterBlade6T(A-95118),AngleGuide(123148-2),DustBag(123150-5),
LockNutWrench20(782401-1),SetPlate(415579-2)
Lightweight and Compact Design with Enhanced Ergonomics
for Maximum Maneuverability
• Anti-Restart feature prevents accidental start up of tool during battery changing when the switch
is locked in the on position
• Electronic Current Limiter with Warning Light prevents motor burnout caused by overloading
• Depth Adjustment Knob enables quick adjustment for #0, #10 and #20 biscuits
• Rack-and-Pinion Angle Guide enables precise adjustment of fence
• Cast Aluminum Adjustable Fence with positive stops at 0°, 45° and 90°
• Non-Marring Rubber Insert Strip eliminates damage to materials
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
4˝ Cordless Plate Joiner
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
4˝ (100 mm)
Maximum Cutting Depth
3/4˝ (20 mm)
No Load Speed
10,000 RPM
Overall Length
13-3/4˝ (351 mm)
Net Weight
7.1 lbs. (3.2 kg)
LXJP02Z
STANDARD EQUIPMENT INCLUDES:
1/8" Collet Cone (763677-9), Wrench 17 (781008-0), 1/8" Drywall Guide Bit (733229-0)
Lighweight Design With High RPM's For Fast Drywall Cutting
• Battery protection system provides over-discharge, temperature and current protection for enhanced
performance, battery cycle life and overall battery life
• Anti-restart feature prevents accidental start up of tool during battery changing when switch i
locked in the on position
• Soft start feature gradually increases speed to eliminate start up shock
• Sliding lock-on switch ideal for operation during periods of prolonged use
• Easily attaches to Makita DVC350F / Z Cordless Vacuum Cleaner for cleaner operation
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Cordless Drywall Cutout Tool
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Collet Capacity
1/8˝ (3.18 mm)
1/4˝ (6.35 mm)
No Load Speed
30,000 RPM
Overall Length
12-1/8˝ (309 mm)
Net Weight
2.4 lbs (1.1 kg)
DCO180Z
STANDARD EQUIPMENT INCLUDES:
DGD800RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RC), Battery Cover (450128-8), 1/4˝ Collet Cone
(763673-7), Collet Nut (763668-0), 2 Ea. Wrench 13 (781039-9), Plastic Carrying Case (824975-7)
DGD800F:
18V (3.0Ah) Li-ion Battery
BL1830 (194205-3), 1/4˝ Collet Cone (763673-7), Collet Nut (763668-0),
2 Ea. Wrench 13 (781039-9)
DGD800Z:
ToolOnly.BatteriesandChargerSoldSeperately.
1/4˝ColletCone(763673-7),ColletNut(763668-0),2Ea.Wrench13(781039-9)
Compact And Lightweight Die Grinder
• Anti-Restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Low Battery Capacity Light indicates ideal time to recharge battery
• Vent Slots direct exhaust towards opposite side of operator
• Easy to Grip Motor Housing for easier handling
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
1/4˝ Cordless Die Grinder
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Collet Capacity
1/4˝ (8 mm)
Maximum Wheel Diameter 1-1/2˝ (38 mm)
No Load Speed
25,000 RPM
Overall Length
15-3/4˝ (402 mm)
Net Weight
4.4 lbs. (2.0 kg)
DGD800RFE
DGD800F
DGD800Z
2-1/8˝
