WOODWORKING
makita.ca
80
STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case
Ideal For Welding and Forming Plastics, Heat Shrink Tubing, Soldering
Copper Pipe, Bending Plastic Pipe, Thawing Metal Pipes, Activating/
De-Activating Adhesives and Putties, Stripping Paint And More!
• Variable temperature dial provides stepless eletronic temperature adjustment to achieve
precise heating requirements
• Thermocouple control maintains temperature for consistent and efficient operation
• Ceramic core protects the heating element for maximum durability and operational longevity
• 2-stage air volume control provides versatility in a wide range of applications
• Rear housing design with integrated rubber bumpers allows tool to be positioned upright for use as a static
heating source during two-handed operations
• Ergonomic soft rubber grip design for comfortable operation
Heat Gun
SPECIFICATIONS
Air Temperature
80
°
C - 550
°
C (180° - 1,020 °F)
Air Volume:
Low
8.8 CFM (250 l/min)
High
16 CFM (450 l/min)
AMPS (120V)
12.0 A
Watts
1,400 W
Overall Length
9.1˝ (230 mm)
Net Weight
1.39 lbs. (0.63 kg)
HG551V
2-Stage Air Volume Control,
Variable Temperature
STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case
Ideal For Welding and Forming Plastics, Heat Shrink Tubing, Soldering
Copper Pipe, Bending Plastic Pipe, Thawing Metal Pipes, Activating/
De-Activating Adhesives and Putties, Stripping Paint And More!
• 2-stage air volume control provides versatility in a wide range of applications
• Rear housing design with integrated rubber bumpers allows tool to be positioned upright for use as a static
heating source during two-handed operations
• Ergonomic soft rubber grip design for comfortable operation
Heat Gun
SPECIFICATIONS
Air Temperature
500
°
C (932°F)
Air Volume:
Low
8.8 CFM (250 l/min)
High
14.1 CFM (400 l/min)
AMPS (120V)
10.0 A
Watts
1,200 W
Overall Length
9.1˝ (230 mm)
Net Weight
1.28 lbs. (0.58 kg)
HG5012
2-Stage Air Volume Control,
Single Temperature
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
HEAT GUN ACCESSORIES
Item
Application
Dimensions
HG1100
HG5012 HG551V
Wide Angle Slit Nozzles
Directs hot air for lap welding PVC sheet materials, single ply roofing,
industrial and marine fabrics and more
1-3/4" width
110751-A
-
2" width
-
P-71423
Reflector Nozzles
Directs flow of hot air around objects, including pipes,
tubing and wiring when activating solder connectors,
heat shrinking tubing, soldering copper or plastic pipes,
thawing pipes and bending plastic pipes
3/8" width
110746-A
-
21/32" width
-
P-71495
1-1/2" width
110705-A
-
1-9/16" width
-
P-71445
3" width
110730-A
-
Glass / Window Nozzles
Protects adjacent surfaces from over heating by deflecting hot
air away from delicate materials. Ideal for use with glass.
2" width
-
P-71417
3" width
110704-A
-
Reduction Nozzles
Directs flow of hot air for use during soldering, welding
or general heating applications
3/8" diameter
110706-A
-
9/16" diameter
110707-A
-
25/32" diameter
110708-A
P-71439
Surface Nozzle
Ideal for spreading hot air over large surfaces when welding
flooring, drying or stripping paint, activating or de-activating
adhesives, heat shrinking packaging and more
3" width
110702-A
-
Welding Nozzles
Provides concentrated hot air flow when welding plastics
1/4" width
110720-A (use with 110706-A)
-
1/4" diameter
-
P-71451
1" (speed style)
-
P-71473
1" (overlap style)
-
P-71489
Plastic Welding Rods
Welding Polyvinyl Chloride (PVC) materials
(ensure welding rod matches materials being welded)
1/8" diameter x 9"
length (16 / pk)
110731-A
Welding Acylonitrile Butadiene Styrene (ABS) materials
(ensure welding rod matches the materials being welded)
110742-A
Scraper
Hand held scraper for use when removing adhesives,
decals, paint, putty, silicone and more
-
P-71548
Pressure Roller
For use during lap welding, seam sealing or
edge veneer applications
1-1/4" width
P-71504
