190 / 220
Advanced High Pressure
Pneumatic Technology
AC310HX
PNEUMATIC
188
makita.ca
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
STANDARD EQUIPMENT INCLUDES:
Wheel Kit (HY00000212)
Advanced High Pressure Pneumatic Technology
• Low noise level - Just 90 dB
• Oil-less design requires no day to day maintenance
• Features dual high pressure and dual 90-130 PSI fittings enables use of multiple pneumatic tools
• Unique High Pressure fittings eliminates confusion with 90-130 PSI fittings
• Internal breaker and reset function eliminates overload of main electrical source
High Pressure Air Compressor
SPECIFICATIONS
Maximum Pressure:
High Pressure
375 PSI
Regular Pressure
130 PSI
Performance:
(90 PSI) 3.6 CFM
(300 PSI) 2.7 CFM
Pump
Oil-less
Output Power
1,500 W
Motor
2.5 HP
Tank Size
1.6 gal. (6.2 L)
Dimensions (L x W x H)
18-3/4" x 14-3/4" x 20"
(476 mm x 375 mm x 507 mm)
Net Weight
79.4 lbs (36.0 kg)
AC310HX
HIGH PRESSURE PNEUMATICACCESSORIES
Description
Contents
Application
Part No.
Middle Joint
Repair Kit
Hose Joint (1 each), Heat Shrink Tubing (1 each),
Nylon Sleeves (2 each)
Repairing leaks in High Pressure Hoses
A-46676
Female Hose Joint
Female Quick Connect Coupler (1 each),
Hose Protector (1 each), Nylon Sleeve (1 each)
Replacement Female Hose Fittings
A-46470
Male Hose Joint
Male Quick Connect Coupler (1 each),
Hose Protector (1 each), Nylon Sleeve (1 each)
Replacement Male Hose Fittings
A-46486
Nylon Sleeve
Nylon Sleeve (1 each)
Replacement Nylon Sleeves
KN00008978
Female Quick Connect Coupler (High Pressure)
AC310H (High Pressure)
HY00000351
Female Quick Connect Coupler (90-135 PSI)
AC310H (Regular Pressure)
HY00000337
HIGH PRESSURE COLLATEDAUTOFEEDSCREWS
Length Shank
Diameter
Shank /
Thread
Head
Diameter
Notes
Application Box Qty.
For Model
Part No.
1"
0.139"
Fine
0.322" PH2 Recess /
Ultra-Coated
Drywall to
Steel
2,000
(20 Strips
of 100)
AR410HR
F-32830
1-1/8"
F-32843
1-5/8"
F-32856
1"
0.146"
Coarse
Drywall to
Wood
F-32869
1-1/8"
F-32872
1-1/4"
F-32885
1-5/8"
F-32898
HIGH PRESSURE PNEUMATICHOSE
Length
Inner Diameter (I.D.)
Maximum Operating Pressure Part No.
25' (7.5 m)
1/4" (6 mm)
470 PSI (3.25 Mpa)
B-80036
50' (15 m)
B-80014
100' (30 m)
B-80020
HIGH PRESSURE PNEUMATIC
MAINTENANCE ACCESSORIES
Description
For Model(s)
Part No.
Air Leak
Repair Set
AN450H, AN610H
194735-4
AN250HC, AN911H
194737-0
AR410HR
194738-8
Pneumatic
Oil 30 mL
All Makita High
Pressure Tools
194381-3
