EN5950SH
STANDARD EQUIPMENT INCLUDES:
HedgeTrimmer HeadAssy (135544-2), Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2), Starter Rope (444023-2),
Spark Plug (168534-0), Oil Set,Accessory Bag (831304-7)
Short Shaft Style Ideal For Vertical Cutting of Tall Hedges and Shrubs
Complies with CARB Tier 3, EPA Phase 2, EU Stage 2 Emissions Requirements
• Multi-position engine lubrication system allows Makita 4-Stroke Pole Hedge Trimmers to be operated at
any angle for maximum versatility
• Fixed hedge trimmer head ideal for use in vertical
cutting applications
• 23-1/4" double-sided blades for fast, versatile
cutting of hedges and shrubs
• Wide trigger control and soft rubber grip design for
comfortable operation
23-1/4" / 25.4cc 4-Stroke Short Shaft Pole Hedge Trimmer
SPECIFICATIONS
Displacement
25.4cc
Maximum Engine Power 0.77 Kw / 1.1 HP
Cutting Length
23-1/4" (590 mm)
Carburetor
Diaphragm Type
Fuel Tank Capacity
0.6 L
Overall Length
70" (178 cm)
Net Weight
13.2 lbs (6.0 kg)
EN4950H
STANDARD EQUIPMENT INCLUDES:
HedgeTrimmer HeadAssy (135784-2), Blade Cover (452328-6), Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2),
Starter Rope (444023-2), Spark Plug (168534-0), Oil Set,Accessory Bag (831304-7)
Long Shaft Style Ideal For Reaching Tall Hedges Or Shrubs
Complies with CARB Tier 3, EPA Phase 2, EU Stage 2 Emissions Requirements
• Multi-position engine lubrication system allows Makita 4-Stroke Pole Hedge
Trimmers to be operated at any angle for maximum versatility
• 135° hedge trimmer head articulation (-90° - 45°)
with 13 positive stops (11.25° increments)
• Pin style angle securing system provides
added retention at positive stop angles
versus friction securing systems
• Hedge trimmer blades fold up to
180° to provide compact size during
transport or storage
19-1/4" / 25.4cc 4-Stroke Long Shaft Pole Hedge Trimmer
SPECIFICATIONS
Displacement
25.4cc
Maximum Engine Power 0.77 Kw / 1.03 HP
Cutting Length
19-1/4" (490 mm)
Carburetor
Diaphragm Type
Ignition System
Electronic
Fuel Tank Capacity
0.6 L
Overall Length
100-3/8" (255 cm)
Net Weight
15.2 lbs ( 6.9 kg)
EY2650H25H
STANDARD EQUIPMENT INCLUDES:
Chain (196142-7), 10"GuideBar (165695-7),ChainCover (452093-7),ShoulderHarness (125516-5),BoxDriver 10-16 (782233-6),Driver (783020-6),
HexWrench 4 (783223-2),OilSupply,SafetyGoggles (195246-2),AccessoryBag (831304-7),StarterRope (444023-2),SparkPlug (168534-0)
Specialized Saw for Limbing / Pruning in High Reach Areas
• Environment-Friendly MM4 / 4-Stroke Engine in compliance with:
CARB Tier 3, EPA Phase 2 and EU Stage 2 Regulations
• Telescoping shaft easily adjusts from 8 ft. to 13 ft. allowing access
to hard-to-reach branches
• Weighs only 16.0 lbs with reduced cutting head weight
for improved balance and reduced operator fatigue
• Heavy duty dual-stage air filter with large sealing
areas is easily accessible
• Translucent bar oil tank with adjustable
automatic chain lubrication for
efficient operation
• Engine oil filling port and drain
plug are easily accessible
for fast oil changes
8' to 13' / 25.4cc 4-Stroke 10˝ High Reach Pole Chainsaw
SPECIFICATIONS
Displacement
25.4cc
Chain Pitch / Gauge
3/8" / 0.050"
Maximum Engine Power 0.77 Kw / 1.1 HP
Maximum Engine Speed 10,000 RPM
Cutting Length
10" (255 mm)
Carburetor
Diaphragm Type
Fuel Tank Capacity
600 ml
Oil Tank Capacity
120 ml
Overall Length
154-1/2" (272 cm)
Net Weight
16 lbs ( 7.2 kg)
Makita offers a wide variety of
ACCESSORIES!
Multi-Position Engine
Lubrication System
EN7350SH
STANDARD EQUIPMENT INCLUDES:
HedgeTrimmer HeadAssembly (126283-5), Blade Cover (451868-1), Shear BladeA (725185-8), Shear Blade B (725186-6),
Chip Receiver (451866-5), Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2), Starter Rope (444023-2), Spark Plug (168534-0),
Oil Supply,Accessory Bag (831304-7)
Short Shaft Style Ideal For Vertical Cutting
of Tall Hedges and Shrubs
Complies with CARB Tier 3, EPA Phase 2, EU Stage 2 Emissions Requirements
• Multi-position engine lubrication system allows Makita 4-Stroke Pole Hedge
Trimmers to be operated at any angle for maximum versatility
• Fixed hedge trimmer head ideal for use in vertical
cutting applications
• 28-3/4" single-sided blades for fast, versatile cutting
of hedges and shrubs
• Wide trigger control and soft rubber grip design
for comfortable operation
28-3/4" / 25.4cc 4-Stroke Short Shaft Pole Hedge Trimmer
SPECIFICATIONS
Displacement
25.4cc
Maximum Engine Power 0.77 Kw / 1.1 HP
Cutting Length
28-3/4" (730 mm)
Carburetor
Diaphragm Type
Fuel Tank Capacity
0.6 L
Overall Length
75-1/4" (191 cm)
Net Weight
13.7 lbs (6.2 kg)
Single Sided Blade For
Precision Trimming
EN4951SH
STANDARD EQUIPMENT INCLUDES:
HedgeTrimmer HeadAssembly (135780-0), Blade Cover (454279-9), Box Driver 10-16 (782233-6), Hex Wrench 4 (783223-2),
Starter Rope (444023-2), Spark Plug (168534-0), Shoulder Harness (125516-5), Oil Supply,Accessory Bag (831304-7)
Short Shaft Style Ideal For Reaching Taller Hedges Or Lower Hedge Areas
Without Extended Up Reaching Or Bending Down
Complies with CARB Tier 3, EPA Phase 2, EU Stage 2 Emissions Requirements
• Multi-position engine lubrication system allows Makita 4-Stroke Pole Hedge Trimmers
to be operated at any angle for maximum versatility
• 135° hedge trimmer head articulation (-90° - 45°) with 13 positive
stops (11.25° increments)
• Pin style angle securing system provides added retention at
positive stop angles versus friction securing systems
• Hedge trimmer blades fold up to 180° to provide
compact size during transport or storage
• Clutch prevents engagement of hedge trimmer
head when folded in the 180° position for
maximum safety during transport
or storage
19-1/4" / 25.4cc 4-Stroke Short Shaft Pole Hedge Trimmer
SPECIFICATIONS
Displacement
25.4cc
Maximum Engine Power 0.77 Kw / 1.03 HP
Cutting Length
19-1/4" (490 mm)
Carburetor
Diaphragm Type
Fuel Tank Capacity
0.6 L
Overall Length
80-1/2" (205 cm)
Net Weight
14.5 lbs (6.6 kg)
With Fixed
Cutting Head
With Adjustable
Cutting Head
With Adjustable
Cutting Head
STANDARD EQUIPMENT INCLUDES:
Cord Holder Complete Set (194677-2), Hook Complete Set (158024-1), Blade Cover (450490-1), Shear BladeAssembly Set (194665-9)
21-5/8" Electric Hedge Trimmer
SPECIFICATIONS
Cutting Length
21-5/8" (550 mm)
Strokes Per Minute
1,600 SPM
AMPS(120V)
4.8 A
Overall Length
38-1/4" (97 cm)
Net Weight
3.7 lbs (8.2 kg)
UH5570
Ergonomic Soft Rubber Grip For Vibration Absorption
And Comfortable Operation
Three switches are installed in handle, front grip and sub grip
• 2-hand operation switch–motor will run only when grips
are held with both hands
• Guard is provided at the tip of blades to
prevent kick-back
• Blades are coated particularly to improve durability
• Built in clutch for safety
• Easy blade replacement
• Powerful 550W Motor
• Protection of extension cord from breakage
Electric Brake
