30 / 220
18V LXT
Impact Wrenches
makita.ca
28
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
LXWT01
STANDARD EQUIPMENT INCLUDES:
LXWT01:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3),
Rapid Charger (DC18RC), Hook (345736-7), Battery Cover (450128-8), Plastic Carrying Case (141644-8)
LXWT01Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (345736-7)
Compact and Lightweight Design with High Maximum Fastening Torque
• Features 7/16" One-Touch Bit Holder for rapid bit changes
• Heavy Duty Ring enables tool to be hung on hook or bucket
lines when not immediately in use
• Same Fastening Torque in forward and reverse rotation
• Rubber Joint Construction
suppresses transmission of
vibration to battery,
minimizing
battery failures
due to terminal
breakage or poor
electrical contact
7/16" Hex Driver Impact Wrench
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
7/16"
No Load Speed
1,900 RPM
Impacts Per Minute
2,200 IPM
Maximum Torque
325 ft. lbs (440 Nm)
Overall Length
10-3/4" (273 mm)
Net Weight
7.8 lbs (3.5 kg)
7/16" Hex Drive,
Reversible
LXWT01Z
DTW1001Z
STANDARD EQUIPMENT INCLUDES:
DTW1001RTE:
Two 18V (5.0Ah) Li-Ion Batteries
BL1850B (196675-2), Rapid Charger (DC18RC), Plastic Carrying Case ,
Hook (346949-3)
DTW1001Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346949-3)
Class-leading maximum fastening torque - 780 ft. lbs!
• 3 Stage impact power selection prevents over-tightening of fasteners
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Rubber joint construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
• Twin LED job lights with pre-glow and afterglow features illuminates work area
3/4" High Torque Impact Wrench
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Square Drive
3/4"
No Load Speed: 0 - 900 / 1,000 / 1,800 RPM
Impacts Per Minute: 0 - 1,800 / 2,000 / 2,200 IPM
Nut-Busting Torque (reverse)
1,250 ft. lbs (1,700 Nm)
Maximum Fastening Torque
780 ft. lbs (1,050 Nm)
Overall Length
9" ( 229 mm)
Net Weight
6.9 lbs (3.1 kg)
3/4
"
Square Drive,
Variable Speed,
Reversible
DTW1001RTE
DTW1002Z
STANDARD EQUIPMENT INCLUDES:
DTW1002RTE:
Two 18V (5.0Ah) Li-Ion Batteries
BL1850B (196675-2), Rapid Charger (DC18RC),
Plastic Carrying Case (821669-5), Hook (346949-3)
DTW1002Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346949-3)
Class-leading maximum fastening torque - 740 ft. lbs!
• 3 Stage impact power selection prevents over-tightening of fasteners
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Rubber joint construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
• Twin LED job lights with pre-glow and afterglow features illuminates work area
1/2" High Torque Impact Wrench
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Square Drive
1/2"
No Load Speed: 0 - 900 / 1,000 / 1,800 RPM
Impacts Per Minute: 0 - 1,800 / 2,000 / 2,200 IPM
Nut-Busting Torque (reverse)
1,180 ft. lbs (1,600 Nm)
Maximum Fastening Torque
740 ft. lbs (1,000 Nm)
Overall Length
9" ( 229 mm)
Net Weight
6.7 lbs (3.0 kg)
1/2
"
Square Drive,
Variable Speed,
Reversible
DTW1002RTE
1/2" Square Drive,
Variable 3-Speed, Reversible
Features Increased
Maximum Fastening
Torque And Ultra-Compact Design
• Auto stop mode stops impact and rotation in
0.2 seconds after fastener is loosened (when trigger is
fully depressed in reverse rotation)
• eXtreme Protection Technology (XPT) offers maximum
protection against dust, debris and liquids
for optimal performance in extreme conditions
• Battery protection system provides over-discharge,
temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Square Drive
1/2"
No Load Speed: 0 - 1,600 / 2,100 / 2,800 RPM
Impacts Per Minute:
0 - 1,800 / 2,600 / 3,500 IPM
Maximum Torque
210 ft.lbs (280 Nm)
Overall Length
5-3/4" (147 mm)
Net Weight
3.8 lbs (1.7 kg)
STANDARD EQUIPMENT INCLUDES:
Two 18V (4.0Ah)Li-IonBatteries
BL1840B (196401-9),RapidCharger
(DC18RC),Hook (346449-3),BatteryCover (450128-8),PlasticCarryingCase
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger
Sold Separately.
Hook (346449-3 )
1/2" Impact Wrenches
DTW285RME
DTW285Z
DTW285XZ
DTW285RTE, DTW285RME, DTW285Z, DTW285XZ
STANDARD EQUIPMENT INCLUDES:
Two 18V (5.0Ah)Li-IonBatteries
BL1850B (196675-2),RapidCharger
(DC18RC),Hook (346449-3),BatteryCover (450128-8),PlasticCarryingCase
DTW285RTE
Round
Head Pin
Flat
Head Pin
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
DTW450Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (345736-7)
DTW450XZ:
Tool Only. Batteries and Charger Sold Separately.
Hook (345736-7)
Compact And Lightweight Design With High Maximum Fastening Torque
• Same Fastening Torque in forward and reverse rotation
• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
1/2" Impact Wrenches
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Square Drive
1/2"
No Load Speed
1,600 RPM
Impacts Per Minute
2,200 IPM
Maximum Torque
325 ft. lbs (440 Nm)
Overall Length
10-1/2" (266 mm)
Net Weight
7.5 lbs (3.4 kg)
Round
Head Pin
Flat
Head Pin
DTW450Z
DTW450XZ
1/2" Square Drive, Reversible
