29 / 220
DTW800Z
makita.ca
27
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
18V LXT
Drills / Impact Wrenches
When
QUALITY&SERVICE
Counts – ChooseMakita
DDF483ZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2" Keyless Drill Chuck (763241-6)
SUB-COMPACT Size - PROFESSIONAL Power
• Sub-compact size (only 6-3/8" long) with high power ideal for professional installers, cabinet makers,
electricians, hobbyists, DIY and more!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 20 clutch settings deliver up to 350 in. lbs of torque
• Dual LED job lights with pre-glow and
afterglow features
1/2" Sub-Compact Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Steel
1/2" (13 mm)
Wood
1-7/16" (36 mm)
No Load Speed:
Low
0 - 500 RPM
High
0 - 1,700 RPM
Maximum Lock Torque
350 in. lbs (40 Nm)
Overall Length 6-3/8" (162 mm)
Net Weight
1.6 lbs (0.7 kg)
Makita's FIRST 18VX2 Brushless Angle Drill!
The Power Of Electric In A Cordless Tool
• Brushless DC motor generates less heat buildup and is ideal for prolonged
use in manufacturing / production applications
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load
condition, enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
1/2" Angle Drill
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Wood Drilling Capacities:
Auger-Bit
2" (50 mm)
Self-Feed Bit (Low / High)
4-5/8" (118 mm) / 2-9/16" (65 mm)
Hole Saw (Low / High)
6-1/4" (159 mm) / 4-1/8" (105 mm)
Steel Drilling Capacity
1/2" (13 mm)
No Load Speed 0 - 350 / 0 - 1,400 RPM
Overall length
24-1/4" (538 mm)
Net Weight
11.3 lbs (5.1 kg)
DDA460PT2
STANDARD EQUIPMENT INCLUDES:
DDA460PT2:
Two 18V (5.0Ah) Li-Ion Batteries
BL1850B (196675-2), Dual Port Rapid Charger (DC18RD), 1/2" Drill Chuck (763250-5),
Chuck Key (763251-3), Straight Side Handle (126802-7), D-Style Front Handle (458431-1), Hex Wrench 6 (783204-6),
Plastic Carrying Case (821737-4)
DDA460Z:
Tool Only. Batteries and Charger Sold Separately.
1/2" Drill Chuck (763250-5), Chuck Key (763251-3),
Straight Side Handle (126802-7), D-Style Front Handle (458431-1), Hex Wrench 6 (783204-6)
DDA460Z
Automatic torque Drive
Technology (ADT),
Variable Speed, Reversible
STANDARD EQUIPMENT INCLUDES:
DDA350RFE
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
Side Handle (153489-2), Chuck Key Holder (450688-0), Chuck Key (763415-9), Plastic Carrying Case(824851-5)
DDA350Z:
ToolOnly.BatteriesandChargerSoldSeparately.
SideHandle (153489-2),ChuckKeyHolder (450688-0),ChuckKey (763415-9)
Compact Design For Optimal Versatility In Confined Spaces
• 2-5/8˝ Head height ideal for operation in confined spaces
• Industrial Aluminum Gear Housing for increased durability
• LED Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Variable Speed, Reversible
3/8" Angle Drill
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
3/8" (10 mm)
Wood
1" (25 mm)
No Load Speed
0 - 1,800 RPM
Overall Length
12-3/8" (314 mm)
Net Weight
4.0 lbs (1.8 kg)
DDA350RFE
DDA350Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
SideHandle (153489-2),3/8" KeylessDrillChuck (766005-7)
Compact Design For Optimal Versatility In Confined Spaces
• Compact head and center height for easy use when working between framing studs or any other
close quarter application
• 4-pole motor offers maximum operational efficiency and reliability with reduced size and weight
versus 2-pole motors
• Large paddle switch with variable speed enables fine adjustment for maximum control and precision
in a wide range of applications
• Industrial Aluminum gear housing for increased durability
• Electric brake stops bit rotation immediately after
trigger is released for added
user safety
• Keyless Chuck for
quick and easy bit
installation and
removal
• Easy-to-operate push button
type Forward / Reverse
change switch
Variable Speed, Reversible
3/8" Angle Drill
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
3/8" (10 mm)
Wood
1" (25 mm)
No Load Speed
0 - 1,800 RPM
Overall Length
12-7/8" (326 mm)
Net Weight
2.7 lbs (1.2 kg)
DDA351Z
DTW800Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346949-3)
Industry leading maximum fastening torque - 590 ft. lbs!
• Features 7/16" one-touch bit holder for rapid bit changes
• 3 Stage impact power selection prevents over-tightening of fasteners
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Heavy duty ring enables tool to be hung on hook or bucket lines when not immediately in use
• Variable speed trigger allows operator to adjust fastening speed based on materials or application
• Electric brake prevents
over-tightening of fasteners
7/16" High Torque Impact Wrench
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
7/16"
No Load Speed: 0 - 900 / 1,000 / 1,800 RPM
Impacts Per Minute:
0 - 1,800 / 2,000 / 2,200 IPM
Maximum Fastening Torque
590 ft. lbs (850 Nm)
Overall Length
9" ( 229 mm)
Net Weight
6.9 lbs (3.1 kg)
7/16
"
Hex, Variable Speed,
Reversible
Variable 2-Speed,
Reversible
Battery Sold Separately
