General Catalogue

27 / 220

18V LXT Drills
makita.ca 25
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
ManufacturingAnd Assembly
When QUALITY&SERVICE Counts – ChooseMakita
Hammer Drill / Driver
STANDARD EQUIPMENT INCLUDES:
DHP481RTE: Same as DHP481Z except with Two 18V (5.0Ah) Li-Ion
Batteries BL1850B (196675-2), Rapid Charger (DC18RC),
Plastic Carrying Case (821524-1)
DHP481Z: Tool Only. Batteries and Charger Sold Separately.
Side Handle (126413-8),Two Double Ended Bits 2-45 (784637-8),
Bit Holder (452947-8), Stopper Pole (122576-8),
1/2" Keyless Chuck (763248-2), Hook (346449-3)
Drill / Driver
Variable 2-Speed,
Reversible
Features Brushless DC Motor
• eXtreme Protection Technology (XPT) offers
maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• LED charge level indicator displays approximate
remaining battery power
• Brushless DC motor generates less heat buildup
and is ideal for prolonged use in manufacturing /
production applications
DHP481RTE / Z & DDF481RTE / Z 1/2˝ Hammer Drills / Drivers
PICTURED: DHP481RTEHammer
Drill / Driver
DHP481RTE
DHP481Z
DDF481RTE
DDF481Z
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Concrete 5/8" (16 mm)
Steel 1/2" (13 mm)
Wood 3" (76 mm)
No Load Speed 0 - 550 / 0 - 2,100 RPM
Blows Per Min. 0 - 8,250 / 0 - 31,500 BPM
Maximum Lock Torque
1,090 in. lbs (125 Nm)
Overall Length 8-1/8" (205 mm)
Net Weight 6.0 lbs (2.7 kg)
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Steel 1/2" (13 mm)
Wood 3" (76 mm)
No Load Speed 0 - 550 / 0 - 2,100 RPM
Maximum Lock Torque
1,090 in. lbs (125 Nm)
Overall Length 8-1/8" (205 mm)
Net Weight 5.7 lbs (2.6 kg)
STANDARD EQUIPMENT INCLUDES:
DDF481RTE: Same as DDF481Z except withTwo 18V (5.0Ah)
Li-Ion Batteries BL1850B (196675-2), Rapid Charger (DC18RC),
Plastic Carrying Case (821524-1)
DDF481Z: Tool Only. Batteries and Charger Sold Separately.
Side Handle (126412-0),Two Double Ended Bits (784637-8),
Bit Holder (452947-8), 1/2" Keyless Chuck (763248-2),
Hook (346449-3)
DHP482SYE
STANDARD EQUIPMENT INCLUDES:
DHP482SYE: Two 18V (Compact) Li-Ion Batteries BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),
Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2" Keyless Drill Chuck (766027-7), Plastic Carrying Case (824812-5)
DHP482Z: Tool Only. Batteries and Charger Sold Separately. Hook (346449-3), Double Ended Bit 2-45 (784637-8),
1/2" Keyless Drill Chuck (766027-7)
Incorporates Makita's NEW Battery Protection System
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• eXtreme Protection Technology (XPT) offers maximum
protection against dust, debris and liquids for optimal
performance in extreme conditions
• 21 clutch settings deliver up to 480 in. lbs of torque
• All metal gears for
more efficient
power transmission
1/2" Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Concrete 1/2" (13 mm)
Steel 1/2" (13 mm)
Wood 1-1/2" (38 mm)
No Load Speed:
Low 0 - 600 RPM
High 0 - 1,900 RPM
Blows Per Minute:
Low 0 - 9,000 BPM
High 0 - 28,500 BPM
Maximum Lock Torque
480 in. lbs (54 Nm)
Overall Length 7-3/4" (198 mm)
Net Weight 3.5 lbs (1.5 kg)
DHP482Z
Variable 2-Speed,
Reversible
DHP484RME
STANDARD EQUIPMENT INCLUDES:
DHP484RME: Two 18V (4.0Ah) Li-Ion Batteries BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),
Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2" Keyless Drill Chuck (766027-7), Plastic Carrying Case (821532-2)
DHP484SYE: Two 18V (Compact) Li-Ion Batteries BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),
Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2" Keyless Drill Chuck (766027-7), Plastic Carrying Case (821532-2)
DHP484Z: Tool Only. Batteries and Charger Sold Separately. Hook (346449-3), Double Ended Bit 2-45 (784637-8),
1/2" Keyless Drill Chuck (766027-7)
Features Brushless DC Motor
• eXtreme Protection Technology (XPT) offers
maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor generates less heat
buildup and is ideal for prolonged
use in manufacturing and
production applications
1/2" Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Concrete 1/2" (13 mm)
Steel 1/2" (13 mm)
Wood 1-1/2" (38 mm)
No Load Speed:
Low 0 - 500 RPM
High 0 - 2,000 RPM
Blows Per Minute:
Low 0 - 7,500 BPM
High 0 - 30,000 BPM
Maximum Lock Torque
530 in. lbs (60 Nm)
Overall Length 7-1/8" (182 mm)
Net Weight 4.0 lbs (1.8 kg)
DHP484Z DHP484SYE
Variable 2-Speed,
Reversible
DHP458RFE
STANDARD EQUIPMENT INCLUDES:
DHP458RFE: Two18V (3.0Ah)Li-IonBatteries BL1830B (194205-3),
Rapid Charger (DC18RC),BatteryCover (450128-8),SideHandle (126131-8),TwoDoubleEndedBits2-45 (784637-8),
BitHolder (452947-8),StopperPole (122576-8),1/2" KeylessChuck (766015-4),Hook (346449-3), PlasticCarryingCase (821532-2)
DHP458Z: Tool Only. Batteries and Charger Sold Separately.Side Handle (126131-8),Two Double Ended Bits 2-45 (784637-8),
Bit Holder (452947-8), Stopper Pole (122576-8), 1/2" Keyless Chuck (766015-4), Hook (346449-3)
High Efficiency, Compact Design
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• LED charge level indicator displays approximate remaining battery power
• Battery Protection System provides Over-Discharge,
Temperature and Circuit Protection for
enhanced performance,
battery cycle life
and overall
battery life
• 21 Clutch Settings
deliver up to 750 in. lbs
of torque
1/2" Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Concrete 5/8" (16 mm)
Steel 1/2" (13 mm)
Wood 2-9/16" (65 mm)
No Load Speed:
Low 0 - 400 RPM
High 0 - 1,800 RPM
Blows Per Minute:
Low 0 - 6,000 BPM
High 0 - 27,000 BPM
Maximum Lock Torque
750 in. lbs (84 Nm)
Overall Length 8-7/8" (225 mm)
Net Weight 5.3 lbs (2.4 kg)
DHP458Z
Independent Battery
Charge Level Indicator,
Variable 2-Speed,
Reversible
DHP485Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Double Ended Bit 2-45 (784637-8), Hook (346449-3), 1/2" Keyless Drill Chuck (766027-7)
Compact And Lightweight Design
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• Battery protection system provides over-discharge,
temperature and circuit protection for enhanced performance,
battery cycle life and overall battery life
• 21 clutch settings deliver up to 440 in. lbs. of torque
1/2" Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Masonry 1/2" (13 mm)
Steel 1/2" (13 mm)
Wood 1-1/2" (38 mm)
No Load Speed:
Low 0 - 500 RPM
High 0 - 1,900 RPM
Blows Per Minute:
Low 0 - 7,500 BPM
High 0 - 28,500 BPM
Maximum Lock Torque
440 in. lbs (50 Nm)
Overall Length 7-1/8" (182 mm)
Net Weight 2.4 lbs (1.1 kg)
Variable 2-Speed,
Reversible
