32 / 220
18V LXT
Impact Drivers
makita.ca
30
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
DTP141Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Impact Driver, Hammer Driver-Drill, Driver-Drill And Screwdriver All In One!
• Impact driver, hammer driver-drill, driver-drill,
and screwdriver all in one, with mechanical high/low
speed switch for maximum versatility on the jobsite
• 3 stage impact power selection provides up to
1,330 in. lbs max. fastening torque
• TEK mode reduces impact power during final stages
of fastener seating, preventing over tightening
of fasteners (screwdriver mode only)
• Brushless DC motor with high power to weight
and size ratio
• Change ring
style mode
selector for
ease of use and
increased durability
1/4" 4-Mode Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4"
Impacts Per Minute:
Impact Driver Mode (Soft / Medium / Hard)
0 - 1,200 / 0 - 2,400 / 0 - 3,200 IPM
Hammer Drill Mode (Low / High)
0 - 8,400 / 0 - 32,400 BPM
No Load Speed:
Impact Driver Mode (Soft / Medium / Hard)
0 - 1,300 / 0 - 2,200 / 0 - 2,700 RPM
Drill Mode (Low / High)
0 - 700 / 0 - 2,700 RPM
Screwdriver Mode (Low / High)
0 - 600 / 0 - 2,300 RPM
Maximum Torque:
Impact Driver Mode
1,330 in.lbs (150 Nm)
Drill Mode
142 in. lbs (16 Nm)
Overall Length
6-3/4" (171 mm)
Net Weight
2.7 lbs (1.2 kg)
Variable Speed,
Reversible
DTS141Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Oil-Impulse Technology Reduces Noise Level By Up To 30%
• Oil-impulse mechanism utilizes hydraulic oil unit to reduce impacting noise level
• Low noise level ideal for use in sensitive environments (hospitals, schools and more) or as an operator
friendly solution to loud working environments
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• 3 stage impact power selection + TEK mode to ensure precise fastening and prevent damage to fasteners
• TEK mode reduces impact power during final stages of seating to prevent damage to fasteners
• LED charge level indicator displays approximate remaining battery power
• Brushless DC motor
with high power to
weight and size ratio
1/4" Oil-Impulse Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4"
No Load Speed:
0 - 3,200 / 2,000 / 1,200 RPM
Impacts Per Minute:
0 - 2,700 / 2,200 / 1,400 IPM
Maximum Fastening Torque
355 in. lbs (40 Nm)
Overall Length
5-3/8" (136 mm)
Net Weight
2.2 lbs (0.9 kg)
Variable 3-Speed,
Reversible
DTD154RME
STANDARD EQUIPMENT INCLUDES:
DTD154RTE:
Two 18V (5.0Ah) Li-Ion Batteries
BL1850B (196675-2), Rapid Charger (DC18RC), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case (821532-2)
DTD154RME:
Two 18V (4.0Ah) Li-Ion Batteries
BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case (821532-2)
DTD154Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Heavy Duty, ULTRA-COMPACT Design (Just 4-5/8" Long)
and Brushless DC Motor
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• 3 Stage impact power selection + TEK mode prevents over tightening of fasteners
• TEK mode reduces impact power during final stages of fastener seating
• Brushless DC motor generates
less heat buildup and is
ideal for prolonged use in
manufacturing and
production applications
1/4" Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4"
No Load Speed:
0 - 1,100 / 2,100 / 3,600 RPM
Impacts Per Minute:
0 - 1,100 / 2,600 / 3,800 IPM
Maximum Fastening Torque
1,550 in. lbs (175 Nm)
Overall Length
4-5/8" (117 mm)
Net Weight
3.3 lbs (1.5 kg)
DTD154Z
Variable 3-Speed,
Reversible
DTD154RTE
DTD153RME
STANDARD EQUIPMENT INCLUDES:
DTD153RME:
Two 18V (4.0Ah) Li-Ion Batteries
BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case
DTD153SYE:
Two 18V (Compact) Li-Ion Batteries
BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case
DTD153Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Compact and Lightweight Design with Brushless DC Motor
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Battery protection system
provides over-discharge,
temperature and circuit
protection for enhanced
performance, battery
cycle life and overall
battery life
1/4" Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4"
No Load Speed
0 - 3,400 RPM
Impacts Per Minute
0 - 3,600 IPM
Maximum Fastening Torque
1,500 in. lbs (170 Nm)
Overall Length
5" (126 mm)
Net Weight
3.3 lbs (1.5 kg)
DTD153Z
DTD153SYE
Variable Speed,
Reversible
DTD152RFE
STANDARD EQUIPMENT INCLUDES:
DTD152RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case (824812-5)
DTD152SYE:
Two 18V (Compact) Li-Ion Batteries
BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case (824812-5)
DTD152Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Ultra-Compact and Lightweight Design with Overall Length of Just 5-3/8"
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• NEW Battery Protection System provides Over-Discharge, Temperature and Circuit Protection
for enhanced performance, battery cycle life and overall battery life
• Increased max. torque of 1,460 in. lbs
• One-touch bit holder enables
quick and easy bit installation
• Twin LED lights with pre-glow
and after-glow functions
• Glow in the dark rubber bumper
1/4" Impact Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Hex Shank
1/4"
No Load Speed 0 - 2,900 RPM
Impacts Per Minute 0 - 3,500 IPM
Maximum Fastening Torque
1,460 in. lbs (165 Nm)
Overall Length 5-3/8" (137 mm)
Net Weight
2.0 lbs (0.9 kg)
Variable Speed, Reversible
DTD152Z
DTD152SYE
DTD171Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Features NEW "Quick Change Memory Mode"
• 4 stage impact power selection + TEK 1, TEK 2, 'Cam-Out' and Auto-Stop modes to ensure precise
fastening and prevent damage to fasteners
• 'Cam-out' elimination mode operates at low speed until fastening begins to eliminate 'cam-out'
and cross-threading
• 2-stage TEK modes reduce impact power during final stages of fastener seating in thick or thin metal
• Auto stop mode stops impact and rotation in 0.2 seconds after fastener is loosened (when trigger is
fully depressed in reverse rotation)
• Quick-change memory mode allows operator to rapidly toggle between two registered settings
1/4" Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4"
No Load Speed:
0 - 3,600 / 3,200 / 2,100 / 1,100 RPM
Impacts Per Minute:
0 - 3,800 / 3,600 / 2,600 / 1,100 IPM
Maximum Fastening Torque
1,590 in. lbs (180 Nm)
Overall Length
4-9/16" (116 mm)
Net Weight
2.0 lbs (0.9 kg)
Variable 4-Speed,
Reversible
