33 / 220
18V LXT
Impact Drivers / Drywall Tools
31
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DTL061Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-45 (784202-3), Hook (346449-3)
Compact Angled Head For Easy Access In Confined Spaces
• 2-1/8" Head height ideal for driving fasteners in confined spaces
• Machined Aluminum Head for added durability
• 360° Rotatable Head enables operation from optimum angle
• Conveniently located Forward / Reverse Switch
• LED Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration
absorption and comfortable operation
1/4˝ Hex Shank,
Variable Speed, Reversible
1/4" Angle Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4"
No Load Speed
0 - 2,000 RPM
Impacts Per Minute
0 - 3,000 IPM
Maximum Torque
530 in. lbs (60 Nm)
Overall Length
15-1/4" (387 mm)
Net Weight
3.8 lbs (1.7 kg)
2-1/8"
DTD155ZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
SUB-COMPACT Size - PROFESSIONAL Power
• Sub-compact size (only 5-5/16" long) with high power ideal for professional installers, cabinet makers,
electricians, hobbyists, DIY and more!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 2 stage impact power selection + 'Cam-Out' mode ensures precise fastening and prevents damage to fasteners
• 'Cam-Out' elimination mode operates
at low speed until fastening
begins to eliminate
'cam-out' and cross-threading
1/4" Sub-Compact Impact Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Hex Shank
1/4"
No Load Speed:
High
0 - 3,000 RPM
Low
0 - 1,300 RPM
Impacts Per Minute:
High
0 - 3,900 IPM
Low
0 - 1,600 IPM
Maximum Fastening Torque
1,240 in. lbs (140 Nm)
Overall Length 5-5/16" (135 mm)
Net Weight
1.8 lbs (0.8 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
1/8˝ Collet Cone (763677-9), Wrench 17 (781008-0), 1/8˝ Drywall Guide Bit (733229-0)
Lightweight Design With High RPM's For Fast Drywall Cutting
• Battery protection system provides over-discharge, temperature and current protection for enhanced
performance, battery cycle life and overall battery life
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Soft start feature gradually increases speed to eliminate start up shock
• Sliding lock-on switch ideal for operation during periods of prolonged use
• Easily attaches to Makita DVC350Z Cordless Vacuum Cleaner for cleaner operation
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Drywall Cutout Tool
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Collet Capacity
1/8" (3.18 mm)
1/4" (6.35 mm)
No Load Speed
30,000 RPM
Overall Length
12-1/8" (309 mm)
Net Weight
2.4 lbs (1.1 kg)
DCO180Z
DSD180Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
Base Cover (456624-4), Blade Cover (456632-5), Blade (B-49703),
Dust Collector (123559-1), Hex Wrench 3 (783201-2)
Designed For Efficient And Dust-Free Drywall Cutting
• Ideal for cutting holes and vents in drywall
• Excellent tool balance enables easy overhead operation
• Variable speed trigger enables operator to adjust cutting speed based on materials or application
• Integrated dust box enables dust-free operation in overhead cutting applications
• Base cover protects drywall material from damage
• LED charge level indicator displays approximate remaining battery power
Drywall Cutter
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Capacities:
Drywall
1-3/16" (30 mm)
Wood
9/16" (15 mm)
Strokes Per Minute
0 - 6,000 SPM
Length of Stroke
1/4" (6 mm)
Overall Length
10-3/8" (263 mm)
Net Weight
2.9 lbs (1.3 kg)
Variable Speed
Variable 2-Speed,
Reversible
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
Abrasive Paper 120G
(1 Ea. B-68557), Pad (199939-3), Hex Wrench 5 (783217-7),Tool Bag (195638-5)
Bluetooth
®
is a registered trademark of Bluetooth
®
SIG
Makita's FIRST Drywall Pole Sander!
• Direct drive brushless DC motor with high power to weight and size ratio positioned at sanding head for maximum power and performance
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing / production applications
• AWS (Auto-Start Wireless System) uses Bluetooth
®
technology to communicate between tool and vacuum and enables wireless control when used with Makita AWS cordless tools
• Soft start and constant speed control features offer maximum operator control and tool performance in heavy-duty sanding applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal performance in extreme conditions
• Variable speed dial allows operator to set sanding speed based on materials or application
• Dust collection brush easily removed to enable easy sanding in corners and ceilings
• Optional extension handle set (part no. 199937-7) provides up to 22-3/4"
additional reach for easy sanding on high walls and ceilings
• Soft, medium and hard density sanding pads available
• Use with Makita AWS Dust Extractors DVC265, DVC864
or DVC154 for complete dust extraction solution
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Pad Diameter
8-1/4" (210 mm)
Abrasive Disc Diameter
8-7/8" (225 mm)
No Load Speed
1,000 - 4,000 RPM
Overall Length
43-1/4" (1,100 mm)
Net Weight
9.3 lbs (4.2 kg)
Drywall Pole Sander with AWS
DSL800Z
1/2" Square Drive,
Variable 3-Speed, Reversible
DRYWALL POLE SANDERABRASIVE SANDPAPER
Part No.
Diameter
Grit
Grain
Holes
Qty / Pk For Model
B-68535
8-7/8"
40G
Ceramic
8 Hole
25 / Pk
DSL800
B-68541
80G
B-68557
120G
B-68563
180G
E-02696
220G
B-68579
320G
B-68535
