35 / 220
18V LXT
Drywall Tools / Saws
makita.ca
33
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY&SERVICE
Counts – ChooseMakita
DFS450RFE
STANDARD EQUIPMENT INCLUDES:
DFS450RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
Phillips Bit 2-25 (784211-2), Magnetic Bit Holder (784801-1), Belt Clip (281220-7), Plastic Carrying Case (824756-9),Locator (158753-6)
DFS450Z:
Tool Only. Batteries and Charger Sold Separately.
Two + Bits 2-25 (784261-7), Magnetic Bit Holder (784801-1),
Belt Clip (281220-7), Locator (158753-6)
Compact And Lightweight Design For Optimal Versatility And Efficiency
• SilentClutchofferssmootherengagementofgearing forhigherdurabilityand increasedoperationalefficiency
• Compact and Lightweight design for easy handling (Only 10-1/8" Long)
• One Touch Locator enables quick and easy bit changes
• LED Light with Afterglow feature
• Conveniently located Forward / Reverse Switch
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Reversible
1/4" Drywall Screwdriver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4"
No Load Speed
4,000 RPM
Overall Length
10-3/4" (273 mm)
Net Weight
4.2 lbs (1.9 kg)
DFS450Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries
and Charger Sold Separately.
10" C.T. Blade 40T (A-93669),
Dust Bag (122852-0), Vertical Vise (126617-2),Triangle Rule
(762001-3), Hex Wrench 2.5 (783208-8), Hex Wrench 6 (781044-6)
10
"
Sliding Compound Mitre Saws with Laser
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Blade Diameter
10" (255 mm)
Arbor
5/8" (15.88 mm)
No Load Speed
4,400 RPM
Overall Length
31-3/4" (805 mm)
Net Weight
57.6 lbs (26.1 kg)
DLS111Z (with AWS)
DLS112Z
Bluetooth
®
is a registered trademark of Bluetooth
®
SIG
Auto-Start Wireless System (AWS) Technology Features
Wireless Dust Collection Technology!
• Incorporates Makita's Deep And Exact Cutting Technology (DXT) up to
12" cuts in 2x material, 6-5/8" nested crown moulding and 5-1/4" vertical baseboard
• Professional cutting design and performance with cordless versatility!
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load
condition, enabling rapid movement between high speed and high torque applications
NEW Close To
Wall "Zero
Clearance"
Design!
DLS110Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
10" C.T. Blade 40T (A-93669), Dust Bag (122852-0), Vertical Vise (126617-2),
Triangle Rule (762001-3), Hex Wrench 6 (781044-6)
Incorporates Makita's Deep And Exact Cutting Technology
(DXT) Up To 12" Cuts In 2x Material, 6-5/8" Nested Crown
Moulding And 5-1/4" Vertical Baseboard
• Professional cutting design and performance with cordless versatility!
• Brushless DC motor with high power to weight and size ratio
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load
condition, enabling rapid movement between high speed and high torque applications
• Rail forward design enables saw to be placed against wall to maximize effective workspace
• 3 stage gear reduction system
greatly increases capacity
when cutting vertical
baseboard or
nested crown
molding
• 1-3/16" guide rail
diameter provides
increased stability
and cutting
precision
10" Sliding Compound Mitre Saw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Blade Diameter
10" (255 mm)
Arbor
5/8" (15.9 mm)
No Load Speed
4,400 RPM
Overall Length
31-3/4" (805 mm)
Net Weight
57.6 lbs (26.1 kg)
NEW Close To Wall "Zero
Clearance" Design!
DLS714Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
7-1/2" C.T. Blade 40T (A-90629), Dust Bag (122852-0), Hex Wrench 5 (783203-8),
Triangle Rule (762001-3), Vertical Vice (122571-8), 2 Ea. Holders (322312-4)
Up To 11-1/34" Cuts In 2x Material
• Brushless DC motor with high power to weight and size ratio
• Automatic Torque Drive Technology
TM
(ADT) adjusts motor speed and torque
during heavy-duty cutting applications for maximum jobsite efficiency and performance
• Dual sliding rail mechanism incorporating 4 linear ball bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Soft start feature gradually increases speed to eliminate start up shock
• 2 stage safety switch prevents accidental startup for increased operator safety
• Mitre capacity of 47° left or 57° right with positive stops at 0°, 15°, 22.5°, 30° & 45°
• Bevel capacity of 45° left or 5° right
7-1/2" Dual Sliding Compound Mitre Saw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Blade Diameter
7-1/2" (190 mm)
Arbor
5/8" (15.9 mm)
No Load Speed
5,700 RPM
Overall Length
25-3/4" (655 mm)
Net Weight
26.3 lbs (11.9 kg)
Soft Start, Electric Brake
DLS713Z
Incorporates Makita's Battery Protection System
Up To 11-3/4˝ Cuts In 2x Material
• Battery Protection System provides Over-Discharge, Temperature and Current Protection for
enhanced performance, battery cycle life and overall battery life
• Dual Sliding Rail Mechanism incorporating 6 Linear Ball Bearings provides increased rigidity to produce
precise, adjustment free cuts right
out of the box
7-1/2" Dual Sliding Compound Mitre Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
7-1/2" (190 mm)
Arbor
5/8" (15.9 mm)
No Load Speed
2,200 RPM
Overall Length 25-3/4" (699 mm)
Net Weight
27.3 lbs (12.4 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
7-1/2" C.T. Blade 40T (A-90912), Dust Bag (122852-0), Hex Wrench 5 (783203-8),
Triangle Rule (762001-3), Vertical Vice (122571-8),Two Holders (322312-4)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries
and Charger Sold Separately.
12" C.T. Blade 60T (B-66983),
Dust Bag (122852-0), Vertical Vise (126617-2),Triangle Rule
(762001-3), Hex Wrench 2.5 (783208-8), Hex Wrench 6 (781044-6)
12
"
Sliding Compound Mitre Saws with Laser
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Blade Diameter
12" (305 mm)
Arbor
1" (25.4 mm)
No Load Speed
4,400 RPM
Overall Length
35-1/4" (898 mm)
Net Weight
67.7 lbs (30.0 kg)
DLS211Z (with AWS) DLS212Z
Bluetooth
®
is a registered trademark of Bluetooth
®
SIG
Auto-Start Wireless System (AWS) Technology Features
Wireless Dust Collection Technology!
• Incorporates Makita's Deep And Exact Cutting Technology (DXT) up to
14-1/4" cuts in 2x material, 8" nested crown moulding and 6-3/4" vertical baseboard
• Professional cutting design and performance with cordless versatility!
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load
condition, enabling rapid movement between high speed and high torque applications
NEW Close To
Wall "Zero
Clearance"
Design!
