52 / 220
12VMAXCXT
Power Tools
makita.ca
50
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
TW140DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346909-5)
Compact eXtreme Technology (CXT)
• Variable speed trigger allows operator to adjust fastening speed based on materials or application
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• LED job light with pre-glow and after-glow feature illuminates work area
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
3/8" Square Drive,
Variable Speed,
Reversible
3/8" Impact Wrench
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Square Drive
3/8"
No Load Speed
0 - 2,600 RPM
Impacts Per Minute
0 - 3,200 IPM
Maximum Torque 100 ft. lbs (140 Nm)
Overall Length
6-3/8" (161 mm)
Net Weight
1.8 lbs (0.8 kg)
JR103DSYE
STANDARD EQUIPMENT INCLUDES:
JR103DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
Slide Charger (DC10SB), Battery Cover (456128-6),
Reciprocating Saw Blade (1 Ea. B-20432, 1 Ea. 723063-A-5), Hex Wrench 3 (783201-3), Plastic Carrying Case (821662-9)
JR103DZ:
Tool Only. Batteries and Charger Sold Separately.
1 Ea. Reciprocating Saw Blade (B-20432, 723063-A-5),
Hex Wrench 3 (783201-3)
Compact eXtreme Technology (CXT)
• Multi-position switch (tool handle and tool body) with lock-off levers for easier operation, maximum
versatility and operator safety
• One-handed, fast toolless blade changes
• Battery protection system provides
over-discharge, temperature and
circuit protection for enhanced
performance, battery cycle
life and overall battery life
• LED job light with
pre-glow and
after-glow
feature
illuminates
work area
Reciprocating Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Capacities:
Wood
2" (50 mm)
Pipe
2" (50 mm)
Length of Stroke
1/2" (13 mm)
Strokes Per Minute
0 - 3,300 SPM
Overall Length
14-3/4" (376 mm)
Net Weight
2.9 lbs (1.3 kg)
JR103DZ
TW060DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346909-5)
Compact eXtreme Technology (CXT)
• Variable speed trigger allows operator to adjust fastening speed based on materials or application
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• LED job light with pre-glow and after-glow feature illuminates work area
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
1/4" Impact Wrench
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Square Drive
1/4"
No Load Speed
0 - 2,600 RPM
Impacts Per Minute
0 - 3,200 IPM
Maximum Torque
44 ft.lbs (60 Nm)
Overall Length
6-3/8" (161 mm)
Net Weight
1.8 lbs (0.8 kg)
1/4" Square Drive,
Variable Speed,
Reversible
TW161DWYE
STANDARD EQUIPMENT INCLUDES:
TW161DWYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Standard Charger (DC10WD), Battery Cover (456128-6),
Hook (346909-5), Plastic Carrying Case (821661-1)
TW161DZ:
Tool Only. Batteries and Charger Sold Separately.
Hook (346909-5)
Compact eXtreme Technology (CXT)
• Auto stop mode stops impact and rotation in 0.2 seconds after fastener is loosened
(when trigger is fully depressed in reverse rotation)
• Brushless DC motor with high power to weight and size ratio
• Variable speed trigger allows operator to adjust fastening speed based on materials or application
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
1/2" Impact Wrench
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Square Drive
1/2"
No Load Speed:
Hard 0 - 2,400 RPM,
Soft 0 - 1,300 RPM
Impacts Per Minute:
Hard 0 - 3,600 IPM
Soft 0 - 2,000 IPM
Maximum Torque
122 ft.lbs (165 Nm)
Overall Length
5-7/8" (150 mm)
Net Weight
1.8 lbs (0.8 kg)
1/2" Square Drive,
Variable 2-Speed,
Reversible
TW161DZ
TW160DWYE
STANDARD EQUIPMENT INCLUDES:
TW160DWYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Standard Charger (DC10WD), Hook (346909-5),
Plastic Carrying Case (821661-1)
TW160DZ:
Tool Only. Batteries and Charger Sold Separately.
Hook (346909-5)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in
manufacturing / production applications
• Variable speed trigger allows operator to adjust fastening speed based on materials or application
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• LED job light with pre-glow and after-glow feature illuminates work area
3/8" Impact Wrench
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Square Drive
3/8"
No Load Speed
0 - 2,400 RPM
Impacts Per Minute
0 - 3,600 IPM
Maximum Torque
118 ft.lbs (160 Nm)
Overall Length
5-5/8" (144 mm)
Net Weight
2.2 lbs (1.0 kg)
3/8" Square Drive,
Variable Speed,
Reversible
TW160DZ
TW141DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346909-5)
Compact eXtreme Technology (CXT)
• Variable speed trigger allows operator to adjust fastening speed based on materials or application
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• LED job light with pre-glow and after-glow feature illuminates work area
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
1/2" Impact Wrench
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Square Drive
1/2"
No Load Speed
0 - 2,600 RPM
Impacts Per Minute
0 - 3,200 IPM
Maximum Torque
100 ft.lbs (140 Nm)
Overall Length
6-3/8" (161 mm)
Net Weight
1.8 lbs (0.8 kg)
1/2" Square Drive,
Variable Speed,
Reversible
