DRILLS
makita.ca
98
DS4011
STANDARD EQUIPMENT INCLUDES:
Side Handle (152492-0), Drill Chuck (763078-1), Chuck Key (763411-7A)
Improved Motor Design And Cooling For Added Performance
And Durability During A Variety Of Mixing And Drilling Applications
• Increased Continuous Input Rating, Rated Amperage and No Load Speed for added performance
and efficiency
• Improved Motor Cooling for added durability and operational efficiency
• Aluminum Gear Housing
• Rocker switch for easy one handed reversing
• Rear Handle rotates 360
°
with 24 locking positions
• Removable Side Handle
• Lanyard Loop
Reversible
1/2˝ Drill
SPECIFICATIONS
Capacities:
Steel
1/2˝ (13 mm)
Wood
1-7/16˝ (36 mm)
AMPS (120V)
8.5 A
No Load Speed
600 RPM
Overall Length
13-3/8˝ (340 mm)
Net Weight
6.2 lbs. (2.8 kg)
STANDARD EQUIPMENT INCLUDES:
Side handle (152492-0), Drill chuck (763078-1), Chuck key (763432-9)
Unique Design And Handle Positioning For A Variety Of Mixing
And Drilling Applications
• Rocker switch for easy one handed reversing
• 550 RPM with double gear reduction for added torque
• Rear handle rotates 360°
Reversible
1/2˝ Drill
SPECIFICATIONS
Capacities:
Steel
1/2˝ (13 mm)
Wood
1-3/8˝ (36 mm)
No Load Speed
650 RPM
AMPS (120V)
6.3 A
Overall Length
13-3/8˝ (340 mm)
Net Weight
6.4 lbs. (2.9 kg)
6013BR
DS4000
STANDARD EQUIPMENT INCLUDES:
Top Handle (273657-2), Drill Chuck (193319-5), Chuck Key (763434-5)
Unique Design And Handle Positioning For A Variety Of Mixing
And Drilling Applications
• Rocker switch for easy one handed reversing
• Precision ground metal gears withstand the rigors of rapid changes between FWD / REV
• 12˝ pipe handle with rubberized grip for greater control
• Rear handle rotates 360°
Reversible
1/2˝ Drill
SPECIFICATIONS
Capacities:
Steel
1/2˝ (13 mm)
Wood:
Ship Auger
1-1/2˝ (38 mm)
Self-Feed
3˝ (77 mm)
Hole Saw
5˝ (127 mm)
No Load Speed
500 RPM
AMPS (120V)
9.0 A
Overall Length
14-1/4˝ (363 mm)
Net Weight
10.1 lbs. (4.6 kg)
DP4010
STANDARD EQUIPMENT INCLUDES:
Drill Chuck & Key Set (193067-6), Chuck Key No. (763430-3), Grip 36 Complete (153503-4), Depth Gauge (324219-0)
Powerful 6.6 AMP Motor Featuring Higher RPM For More Versatile Drilling
• Lightweight cast aluminum gear housing for durability
• Extra-rigid cylindrical tool housing
• 360° swivel side handle
• Soft rubber grip for vibration absorption and comfortable operation
Variable 2 Speed, Reversible
1/2˝ Drill
SPECIFICATIONS
Capacities:
Steel
1/2˝ (13 mm)
Wood
1-9/16˝ (40 mm)
No Load Speed:
High
0 - 2,900 RPM
Low
0 - 1,200 RPM
AMPS (120 V)
6.6 A
Overall Length
13-5/8˝ (347 mm)
Net Weight
5.1 lbs. (2.3 kg)
Powerful 7 AMP Motor Featuring Higher RPM For More Versatile Drilling
• Lightweight cast aluminum gear housing for durability
• Retractable belt clip
• 360° swivel side handle
• Soft rubber grip for vibration absorption and comfortable operation
Variable Speed, Reversible
SPECIFICATIONS
Capacities:
Steel
1/2˝ (13 mm)
Wood
1-1/2˝ (38 mm)
AMPS (120V)
7.0 A
Overall Length
12˝ (305 mm)
DP4000:
No Load Speed
0 - 900 RPM
Net Weight
5.5 lbs. (2.5 kg)
DP4002:
No Load Speed
0 - 600 RPM
Net Weight
6.0 lbs. (2.7 kg)
0 - 900 RPM
STANDARD EQUIPMENT INCLUDES:
Drill Chuck Set (193822-6),
Chuck Key (763430-3),
GripAssembly (134903-7)
DP4000
0 - 600 RPM
DP4002
STANDARD EQUIPMENT INCLUDES:
Drill Chuck Set (193229-6),
Chuck Key (763434-5),
GripAssembly (134903-7)
DP4000, DP4002
1/2˝ Drills
