Electric
Power Tools
makita.ca
107
STANDARD EQUIPMENT INCLUDES:
Steel Carrying Case (182604-1), GripAssembly (122464-9)
High Capacity Impact Wrench Ideal For Heavy Duty Industrial Applications
• High tech motor for heavy duty applications
• Rocker type reversing switch for easy one handed forward/reverse operation
• Side handle Adjusts 360° for operator convenience at any angle
• Heavy duty rubber bumper in front
Reversible
3/4˝ Impact Wrench
SPECIFICATIONS
Square Drive
3/4˝ Square
Capacities:
Bolt Size 5/8˝ - 7/8˝ (16 mm - 22 mm)
Impacts Per Minute
1,600 IPM
No Load Speed
1,500 RPM
Fastening Torque 433 ft. lbs. (588 Nm)
AMPS (120V)
9.0 A
Overall Length
12-7/8˝ (327 mm)
Net Weight
12.3 lbs. (5.6 kg)
6906
STANDARD EQUIPMENT INCLUDES:
Tool Only.
1/2˝ Square Drive
• Precision machined gears for long life and production usage
• Heavy duty front rubber bumper
• Rocker switch for easy one hande reversing
Reversible
1/2˝ Impact Wrench
SPECIFICATIONS
Square Drive
1/2˝ Square
Capacities:
Bolt Size 1/2˝ - 3/4˝ (12 mm - 20 mm)
Impacts Per Minute
2,000 IPM
No Load Speed
1,700 RPM
Fastening Torque 217 ft. lbs. (294 Nm)
AMPS (120V)
4.0 A
Overall Length
10-1/4˝ (270 mm)
Net Weight
6.2 lbs. (2.8 kg)
6905B
STANDARD EQUIPMENT INCLUDES:
Plastic Carrying Case (824702-2)
High Power To Weight Ratio
• More power and torque than competitors 7.5 AMP models
• Heavy duty aluminum gear housing
• Heavy duty front rubber bumper
• Rocker switch for easy one handed reversing
• Ergonomic soft rubber grip for vibration absorption and comfortable operation
Reversible
1/2˝ Impact Wrench
SPECIFICATIONS
Square Drive
1/2˝ Square
Capacities:
Standard Bolt 1/2˝ - 7/8˝ (12 - 22 mm)
High Tensile Bolt1/2˝ - 5/8˝ (12 -16 mm)
Impacts Per Minute
2,000 IPM
No Load Speed
2,000 RPM
Fastening Torque 258 ft. lbs. (350 Nm)
AMPS (120V)
3.5 A
Overall Length
11-1/8˝ (283 mm)
Net Weight
6.6 lbs. (3.0 kg)
TW0350
STANDARD EQUIPMENT INCLUDES:
Screwdriver (783001-0), Steel Carrying Case (823276-0), Outer Sleeve 22-39 (153909-6), Inner Sleeve (764418-6)
Anti-Slipping Mechanism, Tool Starts When Inner
Sleeve Engages With Bolt Tip
• Handy tip lever for ejecting sheared tips
• Rubber bumper for tool body protection
• Cast aluminum gear housing to withstand high torque levels
of planetary gears (804 Nm)
• Easy to grip D-handle
Weighs Only 10.6 Lbs. For Easy
Maneuverability And Less Operator Fatigue
Shear Wrench
SPECIFICATIONS
Capacities:
7/8˝ (M22), 3/4˝ (M20)
No Load Speed
18 RPM
Fastening Torque 593 ft. lbs. (804 Nm)
AMPS (120V)
12.0 A
Overall:
Height
9-15/16˝ (252 mm)
Length
9-13/16˝ (249 mm)
Power Supply Cord
8.2´ (2.4 m)
Net Weight
10.6 lbs. (4.8 kg)
6922NB
STANDARD EQUIPMENT INCLUDES:
Belt Clip (324284-9), Plastic Carrying Case (824630-1)
Durable Lightweight 1/2˝ Drive Impact Wrench For Industrial Applications
• Heavy duty aluminum gear housing
• Rubber inlay grip reduces vibration
• Tool belt clip
• High power to weight ratio
• Variable speed allows user to have greater control
• Conveniently located forward/reverse switch
Variable Speed, Reversible
1/2˝ Impact Wrench
SPECIFICATIONS
Square Drive
1/2˝ Square
Capacities:
Standard Bolt
3/8˝ - 5/8˝ (10 - 16 mm)
High Tensile Bolt 5/16˝ - 1/2˝ (8 - 12 mm)
Impacts Per Minute
0 - 3,000 IPM
No Load Speed
0 - 3,000 RPM
Fastening Torque 111 ft. lbs. (150 Nm)
AMPS (120V)
2.5 A
Overall Length
9-1/8˝ (233 mm)
Net Weight
3.3 lbs. (1.5 kg)
6953
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
SHEAR WRENCH ACCESSORIES
Bolt Size
Description For Model
Outer
Sleeve
Inner Sleeve
M16
Shear
Wrench
Sleeves
6922NB
764362-7
764420-9
M20
764361-9
764417-8
M22
153909-6
764418-6
5/8"
764362-7
764420-9
3/4"
764361-9
764419-4
