105
EXTENSION HANDLES
194500-1
Description
For Model(s)
• Extension Handles for Autofeed Screwdrivers
• Eliminates climbing a ladder for ceiling work or
constant bending and kneeling when building
decks or sub-floors.
6842
6844 / L
DFR550RFE / Z
DFR750Z
CORD HOLDERS
194679-8
194677-2
Armband Cord Holder
Belt Cord Holder
• Attach to long power cords to keep them secure and to prevent catching
on objects or materials.
• Belt and Armband versions available
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
AUTOFEED SCREWDRIVER QUICK REFERENCE CHART
Model No.
6842
6844 / L
DFR550RFE / Z
DFR750Z
Power
AC
18V Li-Ion
18V Li-Ion
Screw Capacity
1" - 2-3/16"
1-3/4" - 2-15/16"
1" - 2-3/16"
1-3/4" - 2-15/16"
No Load Speed (RPM)
4,700 RPM
3,000 RPM
4,000 RPM
4,000 RPM
Tool Length
15-3/4"
17-1/4" / 39-1/8"
16-3/4" / 43"
18-1/4" / 43"
Tool Weight
4.4 lbs.
4.4 / 6.64 lbs.
5.5 / 6.66 lbs.
5.0 / 6.78 lbs.
Bit Length
6-3/8"
7-1/4"
6-3/8"
7-1/4"
Bit Diameter
These Tools will only accept bits less than 0.19685" (5 mm) in diameter
Square Drive Bit
784645-9
784647-5
784645-9
784647-5
Phillips Bit
784251-0
784253-6
784251-0
784253-6
Extension Handle
194500-1
AUTOFEED COLLATED SCREWS
Size
Application
Thread
Recess
Finish
Interior/Exterior
Master Carton Part No.
Master Carton Qty Job Pack (200 Pcs) Part No.
#6 x 1-1/4”
Drywall to Wood
Coarse
PH2
Phosphate
Interior
F-31021
1,000
-
#6 x 1-5/8"
F-31034
-
#8 x 1-3/4"
Wood to Wood
Fine / Coarse SQ2
Zinc
Interior
F-33205
1,000
F-33205A
#8 x 2"
F-33218
800
F-33218A
#8 x 1-5/8"
Fine / Coarse SQ2 Ultra-Coated
Exterior
F-33276
1,000
F-33276A
#8 x 1-3/4"
F-33289
F-33289A
#8 x 2"
F-33292
800
F-33292A
#8 x 2-1/2"
F-33324
600
F-33324A
#8 x 3"
F-33340
F-33340A
AUTOFEED COLLATED SCREWS
FINISHES
Phosphate
Ideal for INTERIOR applications only, including
wood, metal and drywall. Phosphate limits
corrosion and can be easily painted.
Zinc
Suitable for INTERIOR applications only, including
wood. Zinc coated screws are designed to be
rust resistant but should not be used for
exterior applications.
Ultra Coated
Ultra-Coated screws are designed for INTERIOR or EXTERIOR use and are rust resistant. They are non-toxic, low odor and meet all EPA and OSHA
requirements. They are also self-repairing, rated up to 1,000 hours salt spray exposure, resistant to organic solvents and maintain their mechanical
properties up to 300° C. Ultra-Coated screws are compatible with ACQ and Pressure Treated lumber.
THREAD TYPES
Fine
Ideal for drywall or plaster material to metal as they provide increased holding power versus coarse threaded screws.
Coarse
Ideal for wood to wood or drywall to wood applications. Coarse threaded screws drive quickly but offer less holding power than fine threaded screws.
Fine / Coarse
Ideal for applications requiring quick penetration and strong holding power. Coarse threads near the point fasten the screw quickly,
while the finer threads near the head of the screw provide a secure grip on the material. Ideal for applications such as subfloors.
The use of these screws in certain types of lumber (including cedar) may cause the lumber material to stain or discolour
Phosphate
Zinc
Ultra Coated
DFR550RFE
STANDARD EQUIPMENT INCLUDES:
DFR550RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Charger (DC18RA), 2 Ea. Square Bit 2-162 (784645-9),
Phillips Bit 2-162 (784251-0), Belt Clip (281217-6), Plastic Carrying Case (824807-8)
DFR550Z:
ToolOnly.BatteriesandChargerSoldSeparately.
2Ea.SquareBit2-162(784645-9),PhillipsBit2-162(784251-0),BeltClip(281217-6)
High Torque Model For Driving Screws Up To 2-3/16˝ Long
• Anti-Tilt Mechanism prevents screws from swaying out of the drive position
• Silent Clutch enables smooth gearing engagement for quiet operation and reduced maintenance
• Adjustable Stopper Base can be set for different screw lengths
• Lock On Button for easy continuous operation
• Non-Marring Rubber Contact Tip prevents damage to materials
• Dust Proof Construction enables smooth sliding action of Stopper Base for more efficient operation
• Folding Screw Guide prevents collated screw strip from becoming tangled
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Reversible
1/4˝ Cordless Autofeed Screwdriver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝ (6.5 mm)
Screw Capacity 1˝ - 2-3/16˝ (25 - 55 mm)
No Load Speed
4,000 RPM
Overall Length
16-3/4˝ (424 mm)
Net Weight
5.1 lbs (2.3 kg)
DFR550Z
