STANDARD EQUIPMENT INCLUDES:
1 Ea. Paper Filter Bag (P-70194), 1 Ea. Plastic Disposal Bag (P-70297), PETFleece Filter Element (P-70219),
1˝ (I.D.) x 11-1/2'Anti-Static Suction Hose (P-70487)
• Push-clean filter system clears particulate and debris from clogged filters to maximize filter
efficiency and maintain suction power
• Onboard outlet and automatic start feature enables dust extractor to be operated in conjunction
with power tools
• Variable suction power enables operator to adjust the suction power to the application
• Compact and lightweight polycarbonate shell for ease of transport
• Low noise level (just 59 dB) suitable for use
in sensitive environments including
hospitals, schools, institutions and more!
Portable,
Efficient Dust
Extraction
Technology
7 Gallon L Class Dust Extractor
SPECIFICATIONS
Air Volume
113 CFM
Standard Filter Particulate Rating
1 micron
Gross Container Size
7 Gallons (27 Litres)
Dry Tank Capacity 7 Gallons (27 Litres)
Wet Tank Capacity 7 Gallons (27 Litres)
Static Water Lift
93˝ (235 cm)
AMPS (120V)
8.7 A
Power Cord Length
25´ (7.5 m)
Overall Dimensions (L x W x H)
15-1/2˝ x 15˝ x 22-1/2˝ (39 cm x 38 cm x 57 cm)
Net Weight
24.0 lbs (10.9 kg)
446L
STANDARD EQUIPMENT INCLUDES:
Dust Bag (P-78293), 1 Ea. Plastic Disposal Bag (P-70297),
Flat Filter Element (P-79843),Anti-Static Hose 1-3/8" (P-79865), Crevice Nozzle (P-80005)
L Class Dust Extractor
• Xtract Vac
TM
automatic filter cleaning system clears filter at regular intervals to maximize filter
efficiency and maintain suction power
• Rocker valve isolates each filter during cleaning process to prevent interruption of suction power
• Onboard outlet and automatic start feature enables dust extractor to be operated in conjunction
with power tools
• Variable suction power enables operator to adjust the suction power to the application
12 Gallon L Class Dust Extractor
SPECIFICATIONS
Air Volume
135 CFM
Standard Filter Particulate Rating
2 microns
Gross Container Size
12 Gallons (45.4 Litres)
Dry Tank Capacity 9 Gallons (34.0 Litres)
Wet Tank Capacity 8 Gallons (30.2 Litres)
Static Water Lift
92" (233.7 cm)
AMPS (120V)
12.0 A
Power Cord Length
26.25' (8 m)
Overall Dimensions (L x W x H)
29-1/2" x 15" x 17-3/4"
(750 mm x 380 mm x 450 mm)
Net Weight
27.0 lbs (12.3 Kg)
VC4710
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Portable, Efficient
Dust Extraction
Technology
DUST EXTRACTOR ACCESSORIES
Part No.
Description
Application
For Models
Filter Accessories
P-79843
Nano Fleece Filter Element (2 / Pk)
99.95% Efficiency (0.05% Max. Permeability) ≥ 2 microns (µ)
VC4710
P-79859
HEPA Filter Element (2 / Pk)
99.97% Efficiency (0.03% Max. Permeability) ≥ 0.3 microns (µ)
P-70219
PET Fleece Filter Cartridge
99.97% Efficiency (0.03% Maximum Permeability) ≥ 1 micron (µ)
446L
T-01806
HEPA Filter Cartridge
99.995% - 99.999% Efficiency (0.005% - 0.001% Maximum Permeability) ≥ 0.3 micron (µ)
P-80002
Filter Screen
Replaces filter when vacuuming wet materials
P-80001
Exhaust Fitting
Enables set up of dust free environment with 1-3/8" A/S Suction Hose
Filter & Disposal Bags
P-78293
Nano Fleece Filter Bags (5 / Pk)
Lock Out Nano Fleece Filter Bags for dry material
VC4710
P-70297
Plastic Disposal Bags (5 / Pk)
Disposal bags for semi-wet material or liners with Fleece Filter Bags
VC4710, 446L
P-70194
Paper Filter Bags (5 / pk)
Lock Out Paper Filter Bags for dry material
446L
Anti-Static Suction Hoses
P-70487
1" I.D. Anti-Static Suction Hose
1" I.D. x 11-1/2' Length.
VC4710
446L
P-79865
1-3/8" I.D. Anti-Static Suction Hose
1-3/8" I.D. x 9-1/2' Length. Features P-70421 1-3/8" Hose Joint.
P-70362
1-3/8" I.D. x 9-1/2' Length. Features Quick Connect Coupling.
Dust Extraction / Vacuum Accessories
P-70384
Quick Connect Coupling
Quick Connect Coupling for 1-3/8" A/S Suction Hose
VC4710
446L
P-70378
Quick Connect Tool Adapter
Quick Connect Tool Adapter for 1-3/8" A/S Suction Hose
P-80003
Holders (2 / pk)
Attaches to 446L Dust Extractor for power cord storage
P-80004
Square Brush Nozzle
For vacuuming tasks. 1-3/4" x 2-3/4" brush size
P-80005
Crevice Nozzle
For vacuuming tasks in narrow areas. 12" length
P-70471
Rectangular Brush Nozzle
For vacuuming tasks. 1-3/4" x 5" brush size
P-70465
Floor Nozzle
For vacuuming floors with hard or soft surfaces
P-72942
Extension Tubes
2 x 20-1/2" lengths. 39-1/2" assembled length
P-70346
Curved Tube Handle
Handle for use with Extension Tubes
P-70502
Brush & Nozzle Set 1 (4 pcs)
Includes: Crevice Nozzle + Brush, Rectangular Brush Nozzle, Universal Nozzle
P-70518
Brush & Nozzle Set 2 (3 pcs)
Includes: Square Brush Nozzle, Universal Nozzle, Rubber Tube Nozzle
P-70312
Brush & Nozzle Set 3 (8 pcs)
Includes: Floor Nozzle, Square Brush Nozzle, Universal Nozzle, Crevice Nozzle, Pipe Holder, 19"
Extension Tubes (2 pcs), Curved Tube Handle
Brush & Nozzle Set
Plastic Disposal Bags
Paper Filter Bags
HEPA Filter
Cartridge
PET Fleece
Filter Cartridge
